Page 1: Table Of Contents
If you are not entirely satisfied with this Assembly product, please return it to your nearest ALDI store within 60 days from Before operation the date of purchase for a full refund or replacement, or take advantage of our after sales support by calling the supplier’s Customer Service Hotline.
Page 2 HCE1400 Fig. 5 Fig. 6 Fig. 7 AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: HCE1400 PRODUCT CODE: 58428 11/2018...
Page 3: Explanation Of Symbols
Explanation of symbols HCE1400 Explanation of Symbols Read the operating instructions to reduce the risk of injury. Wear safety goggles. Wear ear-muffs. The impact of noise can cause damage to hearing. This high pressure cleaner is not suitable for connecting to the drinking water network. Warning! High-pressure jets can be danger- ous if not used properly.
Page 4: Introduction
Introduction HCE1400 I. Introduction Congratulations on choosing to buy a WORKZONE product. ® All products brought to you by WORKZONE are manufactured to the highest ® standards of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty. We hope you will enjoy using your purchase for many years to come.
Page 5: Layout
Introduction/Layout/Scope of delivery HCE1400 In addition to the safety notes contained in the present operating instructions and the special regulations of your country, the generally recognised technical rules for the operation of this high pressure cleaner must be observed. II. Layout (Fig. 1) Handle Holder for mains cable Mains cable...
Page 6: Intended Use
HCE1400 Scope of delivery/Intended use/Safety regulations • Remove the packaging material as well as the packaging and transport bracing (if available). • Check that all contents are included. • Check the high pressure cleaner and accessory parts for transport damage. •...
Page 7 Safety regulations HCE1400 • Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. 2. Electrical safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.
Page 8 HCE1400 Safety regulations • Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. • Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
Page 9 Safety regulations HCE1400 Caution! Residual risks Even if you use this electric power tool in accordance with instructions, certain residual risks cannot be rules out. The following hazards may arise in connection with the equipment’s construction and layout: 1. Lung damage if no suitable protective dust mask is used. 2.
Page 10 HCE1400 Safety regulations breaker (RCD) with a rated leakage current of not more than 30 mA. Fuse: at least 13 ampere. • Before each use, check the high pressure cleaner, cable and plug for damage. • If the power cable for this high pressure cleaner is damaged, it must be replaced by the manufacturer, a customer service agent of the same or a similarly qualified person in order to prevent hazards.
Page 11 Safety regulations HCE1400 • Do not operate the high pressure cleaner with missing, broken or unauthorised parts. • Never leave wand unattended while the unit is running. • Keep work area free of obstacles. • Stand on stable surface and grip gun/lance firmly. Expect the gun to kick back when engaged •...
Page 12: Technical Data
HCE1400 Safety regulations/Technical data m Warning! Do not use appliance without reading the instruction manual. m Warning! This high pressure cleaner has been designed for use with the clean- ing agent supplied or recommended by the manufacturer. The use of other cleaning agents or chemicals may adversely affect the safety of the high pressure cleaner.
Page 13 Technical data HCE1400 Max. permissible pressure 10.5 MPa / 1523 PSI Max. inflow pressure 0.4 MPa / 580 PSI Inflow temperature 5 - 40 °C Working flow rate, water 5 L/min Max. working flow rate, water 6.2 L/min Noise and Vibration Sound pressure level (L 83 dB(A) Uncertainty K...
Page 14: Assembly
HCE1400 Assembly VII. Assembly Warning! Ensure the high pressure cleaner is correctly and completely assembled before use. Mounting of the handle, holder for mains cable and holder for high pressure hose (Fig.1) Mount the handle (1) onto the upper side of the high pressure cleaner and fix it with the two delivered screws by using a screwdriver (not included).
Page 15: Before Operation
Assembly/Before operation HCE1400 Connection of the cleaning agent container (Fig.6) Remove the vario nozzle (10) or patio cleaner (13) from the extension (11). Plug the cleaning agent container into the extension (11). VIII. Before operation It is recommend for the power supply to this high pressure cleaner either to be connected via a residual current device (RCD) circuit-breaker, which interrupts the power flow as soon as the leakage current to earth exceeds 30 mA for 30 ms, or for it to be equipped with an earth tester.
Page 16: Operation
HCE1400 Before operation/Operation Warning! Water that has passed through the non-return valve is not drinkable. Warning! If any cleaning agent comes into contact with your skin or into your eye, rinse immediately with lots of clean water. Then consult a doctor or follow the steps described on the safety data sheet or provided by the manufacturer of the clean- ing agent.
Page 17 Operation HCE1400 Press the security switch (B) to unlock the gun starting lever (A). The nozzle operates by pressure and the motor switches back on. Releasing the gun starting lever (A) causes the high pressure cleaner to switch off. The system remains pressurised. After using the high pressure cleaner press the security switch (B) to lock the gun starting lever.
Page 18: Maintenance And Cleaning
HCE1400 Maintenance and cleaning/Troubleshooting X. Maintenance and cleaning Pull out the power plug before every maintenance operation. This also includes connecting to the water supply or trying to eliminate leaks. There is a risk of electro- cution or of injury from moving parts. Cleaning It is recommended to clean the high pressure cleaner after each use.
Page 19: Storage And Transport
Troubleshooting/Storage and transport/Disposal and recycling HCE1400 XII. Storage and transport Storage • Clean up the high pressure cleaner before storing. • Drain all the water from the high pressure cleaner. • Disconnect the unit from the water supply. • Store all accessories as shown in Fig. 7. •...
Page 20: Warranty Details
HIGH PRESSURE CLEANER Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.
Page 21: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.
Page 22 Overview Utilisation Pack contents/parts HCE1400 Fig. 1 Fig. 2 Contents of Box High pressure cleaner Water inlet connector 3m High pressure hose Vario spray nozzle (already mounted to the extension handle) Fig. 3 Extension handle Spray gun Patio cleaner Cleaning agent container Mounting screws Nozzle cleaning needle Fig.
