- Page 1 CAMON EA25 Lawn Aerator ORIGINAL INSTRUCTION MANUAL Manufactured by Tracmaster Ltd Before commissioning the machine, read operating instructions and observe warning and safety instructions.
-
Page 2: Manufacturer Details
CAMON EA25 Lawn Aerator Manufacturer Details Tracmaster Ltd Units 6-7 Winterpick Business Park Hurstpierpoint Road Wineham Henfield BN5 9BJ UNITED KINGDOM Tel: +44 (0)1444 247689 www.tracmaster.co.uk info@tracmaster.co.uk Machine Details CAMON EA25 Lawn Aerator Model: Serial No: A 1 6 -... -
Page 3: Table Of Contents
To Start the EGO Power Unit ....................10 To Stop the EGO Power Unit ....................10 Safety Equipment ........................10 6.4 Operation..........................10 6.5 Procedure for Unexpected Shut Down ................11 Residual Risks of the EA25 Lawn Aerator ................12 Maintenance ..........................13 Schedule ..........................13 Basic Maintenance ......................13 7.3 Gearbox ..........................13 7.3.1 Check Gearbox Oil Level ....................14 EGO Power Unit ........................14... -
Page 4: Introduction
We are confident that you will be more than happy with your machine. Your machine is covered by a comprehensive warranty. However, the lifespan of your CAMON machine depends on a number of factors. It is important that you read this manual carefully and follow the instructions regarding operation, maintenance, and care. -
Page 5: What The Machine Is Designed For
The benefit of aerating a lawn is that it allows air, water and nutrients to reach the roots of the grass, relieves soil compaction, and removes unwanted sub-surface thatch. The tines of the CAMON EA25 Lawn Aerator are designed to be used only on grassed areas where the surface soil is more than 100mm in depth. Failure to use the EA25 Lawn Aerator in soil less than 100mm deep will result in damage to the machine. Prior to operation of the EA25, the operator MUST test the depth of the soil. This can be done simply with a garden fork. -
Page 6: Specifications
CAMON EA25 Lawn Aerator 3.0 Specifications EGO POWER UNIT Power Unit Manufacturer Power Unit Model PU2710E Net Power 3.47kW (4.65hp) @ 3450rpm Maximum Net Torque 9.2 N.m @ 3450rpm Shaft Size ¾” straight IP Rating IPX5 Voltage 56v DC Battery Port Dual Port Speed Control Continuously variable speed 1200-3600 rpm Cooling System Air Cooled Air Cleaner... -
Page 7: Unpacking And Assembly
⑧ ⑨ ⑩ Unpacking Instructions The EA25 Lawn Aerator is usually delivered on a pallet, covered with pallet wrap, and secured with transport brackets which are fixed to the wheels. Carefully remove any outer packaging. Locate and remove any cable ties or straps that secure the Aerator to the pallet. Using 13mm spanners remove the bolts on the transport brackets. Once the brackets are removed, refit the washer and bolt back onto the wheels ensuring they are correctly tightened. -
Page 8: Safety Instructions - Pre-Operation
Grey Button PULLED UP. Once the drive has been engaged it will transfer power through the gearbox, to the tine rods that will then rotate. The surface penetrating tines are held at the end of each tine rod and will be pushed into the ground before being withdrawn as the tine rods rotate. Height Adjustment The depth of the tine penetration of EA25 Lawn Aerator is altered by changing the position of the back axles. Each back axle has three holes (Fig. 2) by which it can be attached to the main chassis frame. Attaching the axles using the lowest position holes has the effect of moving the tines closer to the ground and increasing the depth that the aerator will penetrate. -
Page 9: Tines
Use a 17mm spanner to tighten the tines in place. We recommend checking the tightness of the tines at intervals during operation. Fig. 3 Solid Spiking Tines & Hollow Coring Tines Tine Holder Rod The EA25 Lawn Aerator is supplied with a set of both 10mm solid spikes and hollow corer tines (Fig. 5). You must always Spring Washer use four of the same tines when setting up and operating Washer the Aerator. Solid tines help nutrients to reach soil roots and improve Tine or drainage. -
Page 10: Ego Power Unit Specific Safety Instructions
CAMON EA25 Lawn Aerator Only work in good light and visibility. Do not work in extremes of temperature, or poor weather. Wear the correct personal protection equipment as instructed by this manual. Operator clothing should not be loose and footwear should be enclosed and offer good grip. Know how to stop the machine in an emergency. 5.10 EGO Power Unit Specific Safety Instructions Do not operate the EGO Power Unit in explosive atmospheres, such as in the presence of flammable liquids, gasses or dust. Do not use a battery pack or Power Unit that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of personal injury. - Page 11 Wineham, Henfield BN5 9BJ, UK mark). Includes unique serial number, machine T: +44 (0)1444 247689 weight, power output, and month and year of Machine Type: EA25 Lawn Aerator Weight: 103kg Year ID: March 2025 manufacture. Power: 3.47kW Serial No: A16-80000 It is important that these stickers are in good condition, are legible, and are in the correct positions on the EA25 Lawn Aerator.
-
Page 12: Safety Instructions Starting And Operating
COMPONENTS OF THE MACHINE. WE RECOMMEND THE GRASS IS CUT PRIOR TO AERATING. Do not operate the EA25 Lawn Aerator on wet lawns or in wet weather. Hollow tines should only be used on moist ground conditions. Hardcore or rubble located under the surface of the turf will cause damage to the machine. -
Page 13: Procedure For Unexpected Shut Down
A VERTICAL POSITION. THE TINES MUST BE VERTICAL FOR MAXIMUM AERATING DEPTHS AND EFFICIENT PROPULSION TO BE ACHIEVED. Operate the machine only in daylight or in good artificial light. Always be sure of footing on slopes. Do not work the EA25 Lawn Aerator on slopes of more than 10 degrees. Always work across the slope, not up and down it. Walk never run. Never operate the machine with defective or missing guards, or without safety devices, for example deflectors and or catchers in place. -
Page 14: Residual Risks Of The Ea25 Lawn Aerator
CAMON EA25 Lawn Aerator Residual Risks of the EA25 Lawn Aerator The EA25 Lawn Aerator is designed to be pushed by the operator during transportation and whilst it propels itself during operation it does not have a driven axle. It has no brake system and therefore the operator must hold firmly onto the machine at all times when the machine is on sloped areas. Page 12 www.tracmaster.co.uk... -
Page 15: Maintenance
Ensure the wheels are held securely and the bolt that holds the wheels onto the axles is in place. Gearbox Important! Before checking the Fig. 9 gearbox oil level the EA25 Lawn Spirit Aerator needs to be tilted back to Level ensure that the gearbox is level. The front wheels should be raised approximately 40mm off the ground (Fig. 9). You can place a spirit level on the... -
Page 16: Check Gearbox Oil Level
CAMON EA25 Lawn Aerator 7.3.1 Check Gearbox Oil Level It is recommended that the gearbox oil Dipstick Fig. 10 is changed every 12 months. Open the drain plug (Fig. 10) on the gearbox and the filling plug, and drain the oil into a suitable container or use a... -
Page 17: Troubleshooting
CAMON EA25 Lawn Aerator Troubleshooting 7.6.1 Machine Have all serious malfunctions on the machine and EGO Power Unit repaired by an authorised Tracmaster or EGO agent. Problem Possible Cause Remedy No drive to tines. Broken chain. Replace chain. Pull back on handlebar Poor depth and Operator is pushing the during operation to ensure propulsion. machine. tines are vertical. 7.6.2 EGO Power Unit... - Page 18 CAMON EA25 Lawn Aerator Stop the power unit, and adjust the speed again. If the surrounding is too noisy, The speed makes it is difficult to recognize no changes Measure the speed changes. when turning difference to further check if the continuously necessary. variable lever. Contact EGO customer Other unidentified causes.
-
Page 19: Transportation, Storage And Handling
CAMON EA25 Lawn Aerator 8.0 Transportation, Storage and Handling Transportation Use ramps where possible to manoeuvre the EA25 Lawn Aerator into a transportation vehicle. The EA25 Lawn Aerator must be fixed securely using straps and by placing chocks behind the wheels. Always transport the EA25 Lawn Aerator horizontally and not tilted at an angle. Storage Always allow the EGO Power Unit to cool down prior to storage. Always clean the machine and dry thoroughly prior to storage and ensure all lubrication points have been re-greased. Always remove the battery packs when storing the machine. Do not store the Aerator in wet rooms, where fertiliser is stored, or in stables as heavy corrosion may occur. Always store the machine in a horizontal position. -
Page 20: Spare Parts
CAMON EA25 Lawn Aerator 9.0 Spare Parts The spare parts diagrams and part numbers for the CAMON EA25 Lawn Aerator can be found on our website or by contacting our spare parts department. Spare parts can be ordered via the following methods: Website: www.tracmaster.co.uk Phone: +44(0) 1444 247689 Email: spares@tracmaster.co.uk Or via your local Authorised Dealer. Page 18 www.tracmaster.co.uk... -
Page 21: Service Record
CAMON EA25 Lawn Aerator 10.0 Service Record To ensure your machine is kept in peak condition we recommend that your CAMON EA25 Lawn Aerator is serviced at regular intervals. Contact Tracmaster on 01444 247689 to find out who your local Authorised Tracmaster Dealer. is, or check our Dealer Locator online at www.tracmaster.co.uk. Company: Company: Date: Date: Company Company Stamp: Stamp: (or address (or address & authorised &... -
Page 22: Ec Declaration Of Conformity
CAMON EA25 Lawn Aerator 11.0 EC Declaration of Conformity Tracmaster Ltd declares that the machinery stipulated below complies with all the relevant provisions of: Machinery Directive 2006/42/EC EMC Directive 2004/108/EC and the National Laws and Regulations adopting these directives and other relevant directive. Manufacturer: Tracmaster Ltd Units 6-7 Winterpick Business Park Hurstpierpoint Road Wineham Henfield BN5 9BJ UNITED KINGDOM Machine Description: Lawn Aerator Type: CAMON EA25 Harmonised Standards applied (including parts of): Safety of machinery: Safety distance to prevent danger zones EN 294:1992 being reached by the upper limbs. -
Page 23: Warranty Information
CAMON EA25 Lawn Aerator 12.0 Warranty Information The Warranty applies to any part of the machine, except the Power Unit, which presents manufacturing or assembly defects in the opinion of Tracmaster Ltd. The Warranty covers the original purchaser of the machine from the date of sale for the warranty period. - Page 24 CAMON EA25 Lawn Aerator Original Instruction Manual Rev. 05/2025.A © 2025 Tracmaster Ltd Tracmaster Ltd Units 6-7 Winterpick Business Park | Hurstpierpoint Road | Wineham | Henfield | BN5 9BJ | UK Tel: +44 (0)1444 247689 | www.tracmaster.co.uk | info@tracmaster.co.uk...
