LG MVEM1825 Series Installation Manual
Hide thumbs Also See for MVEM1825 Series:

Advertisement

Quick Links

INSTALLATION MANUAL
MICROWAVE OVEN
Read this installation manual thoroughly before installing the
appliance and keep it handy for reference at all times.
ENGLISH
MVEM1825* MVEM1721* MVEM1621* LMV1764**
www.lg.com
MFL06206516
Copyright © 2022-2025 LG Electronics. All Rights Reserved
Rev.04_052025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVEM1825 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LG MVEM1825 Series

  • Page 1 INSTALLATION MANUAL MICROWAVE OVEN Read this installation manual thoroughly before installing the appliance and keep it handy for reference at all times. ENGLISH MVEM1825* MVEM1721* MVEM1621* LMV1764** www.lg.com MFL06206516 Copyright © 2022-2025 LG Electronics. All Rights Reserved Rev.04_052025...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING INSTALLATION Before Installing Installing the Microwave Oven 15 APPENDIX Checking Operation...
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages.
  • Page 4: Operation

    IMPORTANT SAFETY INSTRUCTIONS • Place the plug into a properly installed and grounded outlet Three-pronged (grounding) plug Properly polarized and grounded outlet • Do not use an extension cord. • Keep the power cord dry and do not pinch or crush it. Failure to follow this instruction may cause a fire hazard.
  • Page 5: Installation

    INSTALLATION INSTALLATION Before Installing • Be sure you have enough space (minimum vertical and horizontal clearance). Before You Start Be sure to read the following safety instructions Read the entire manual before you begin. The model number plate is located on the oven front.
  • Page 6: Included Parts

    INSTALLATION Parts Tools and Materials You will need the following tools and materials for Included Parts the installation: NOTE • Depending on your ventilation requirements, you may not use all of these parts. Power cord clamp bushing (1ea): for the cord hole in a metal upper cabinet Phillips screwdriver (for the screws) 1/4"...
  • Page 7: Step 2: Prepare The Venting System

    INSTALLATION NOTE WARNING • If you have brick or masonry walls, you will need • Avoid electric shock. This appliance must be special hardware and tools. grounded. • The ductwork you need for the installation is not • Improper grounding could result in electric included.
  • Page 8: Roof Venting

    INSTALLATION • After installation, check the outside hood 3 1/4" x 10" duct opening and operation. Wall cap • For the outside hood opening and size refer to the upper cabinet template or rear wall Elbow template. Minimum 6" diameter round duct NOTE 3 1/4"...
  • Page 9: Step 3: Prepare The Venting Blower

    INSTALLATION Cover the countertop or cooktop with a thick, For 3 1/4" x 10" systems protective covering to protect it from damage and dirt. 6 ft 2 ft = 25 ft 1/4" x 10" 90° elbow (1ea) = 40 ft Wall cap (1ea) = 8 ft...
  • Page 10 10 INSTALLATION then one or several blower plate mounting Carefully lift the blower unit out of the screw(s) microwave oven. Use side cutters or tin snips to cut out and Blower unit remove the knockouts from the back plate Back plate .
  • Page 11 INSTALLATION • Ventilation fan openings should be completely exposed to the outside. • After installation, check the air ventilation path. Refer to step 2 for proper vent selection. Improper installation can cause problems such as: • Inability to assemble the blower plate or ventilation motor correctly •...
  • Page 12 12 INSTALLATION Center the rear wall template in the space Drill a 3/8” hole at points J and K on the upper by lining up the plumb line on the wall with cabinet template. the centerline on the template. Then securely If the bottom of the upper cabinet is recessed tape or tack the rear wall template in place.
  • Page 13: Step 5: Install The Mounting Plate

    INSTALLATION Step 5: Install the Mounting Plate NOTE The oven must be connected to at least one wall • Cut out the shaded area marked F on the rear stud. wall template for wall-venting. Center the rear wall template in the space by lining up the plumb line on the wall with the centerline on the template.
  • Page 14 14 INSTALLATION Rotate the microwave oven upward so the top of the oven is against the bottom of the upper cabinet or cabinet frame. Then insert a bolt down through each hole in the upper cabinet bottom. Tighten the bolts until the gap between the upper cabinet and microwave oven is closed.
  • Page 15: Appendix

    APPENDIX APPENDIX Checking Operation Before Using the Oven Plug in the power supply cord. Read your Owner’s Manual, and then check the operation of your oven.
  • Page 16 LG Customer Information Center Centro de Información al Cliente LG Centre de Service à la Clientèle de LG For inquiries or comments, Para consultas o comentarios, visite Pour des questions ou des commentaires, visit www.lg.com or call: www.lg.com o llame por teléfono: visitez www.lg.com/ca_fr ou appelez :...
