- Page 1 INSTRUCTION MANUAL Pneumatic Framing Nailer AN923 AN943 WARNING: Please read the instructions and warnings for this tool carefully before use. Failure to do so could lead to serious injury.
-
Page 2: Specifications
Read instruction manual. Vibration The vibration emission value determined according to Wear safety glasses. EN ISO 11148: Model AN923 Vibration emission (a ) : 4.0 m/s Uncertainty (K) : 1.5 m/s Wear ear protection. Model AN943 Vibration emission (a ) : 3.5 m/s... -
Page 3: Save All Warnings And Instructions For Future Reference
Projectile hazards Pneumatic nailer/stapler safety warnings The fastener driving tool shall be disconnected when unloading fasteners, making adjust- WARNING: Read all safety warnings and all ments, clearing jams or changing accessories. instructions. Failure to follow the warnings and instruc- During operation be careful that fasteners pene- tions may result in serious injury, electric shock and/or fire. - Page 4 10. On rooftops and other high locations, drive This tool is not intended for use in potentially fasteners as you move forward. It is easy to lose explosive atmospheres and is not insulated from coming into contact with electric power. your footing if you drive fasteners while inching backward.
-
Page 5: Parts Description
When using pneumatic tools, do not exceed friction-related wear. Wipe off all dust from the parts. the maximum operating pressure ps max. Ask Makita authorized service center for peri- 10. Pneumatic tools should only be powered odical inspection of the tool. -
Page 6: Installation
• Use an air hose as large a diameter and as short INSTALLATION as possible to assure continuous, efficient nailing operation. With an air pressure of 0.49 MPa (4.9 bar), an air hose with an internal diameter of over Selecting compressor 8.5 mm (5/16") and a length of less than 20 m (6.6 ft.) is recommended when the interval between each nailing is 0.5 seconds. -
Page 7: Functional Description
Installing the hook FUNCTIONAL DESCRIPTION CAUTION: • Always lock the trigger and disconnect the hose before adjusting or checking function on the tool. Nose adapter (Accessory) CAUTION: • Always lock the trigger and disconnect the hose before installing or removing the nose adapter. When nailing workpieces with easily-marred surfaces, use the nose adapter. -
Page 8: Connecting The Air Hose
► 1. Nail stopper Load nails so that they get parallel to the driver guide. Connecting the air hose ► 1. Pusher Pull the pusher lever to the rear to engage the pusher to the last nail. ► 1. Air socket 2. Air fitting Unloading the nailer Lock the trigger. - Page 9 This tool is equipped with the change lever. You can Single sequential actuation select either the single sequential actuation mode or the contact actuation mode with it. You can also lock the Place the contact element against the workpiece and trigger by setting it to the trigger lock position.
-
Page 10: Maintenance
Avoid storing nails in a very humid or hot place or place Jammed nailer exposed to direct sunlight. Humid Nail ► 1. Hammer 2. Small rod 3. Ejection port 4. Driver MAINTENANCE CAUTION: • Always lock the trigger, disconnect the hose and remove the nails from the magazine before CAUTION: clearing a jam. - Page 11 Make sure that the trigger is locked when the change Maintenance of the compressor, air lever is set to the position. set and air hose ► 1. Trigger lock 2. Change lever ► 1. Drain cock When the tool is not to be used for an extended period of time, lubricate the tool using pneumatic tool oil and store the tool in a safe place.
-
Page 12: Optional Accessories
Thinner • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
