Sony MVC-CD1000 Service Manual

SERVICE MANUAL
Ver 1.0 2000. 07
Level 2
On the SY-060 board and the DDX-G2000 COMPLETE ASSEMBLY (Including the MD-082 Board)
This service manual provides the information on the premised of the circuit board replacement service and not intended
repair inside the SY-062 board in case of trouble. It is also premised that the mechanism deck DDX-G2000 COMPLETE
ASSEMBLY (including the MD-082 board) shall be exchanged as an assembly in case of trouble.
Therefore, disassembling procedure and exploded view of the DDX-G2000 COMPLETE ASSEMBLY are not shown. The
block diagram, schematic diagram, printed wiring board and electrical parts list of the SY-062 board are also not shown.
Note that the following pages are lacking intentionally.
SY-062 board
Block diagram ............................... Page 3-19 to 3-22
Schematic diagram ....................... Page 4-15 to 4-22
Printed wiring board ..................... Page 4-11 to 4-14
Electrical parts list ........................ Page 6-16 to 6-18
The above-described information is shown in service manual Level 3.
System Data compression
system
Image device
Movie: MPEG1
1/2.7 type color CCD
Still:
Lens
JPEG, TIFF, GIF (in TEXT
10× zoom lens
mode)
f = 1/4 – 2 3/8 in (6.0 –
Audio (with still image):
60.0 mm) (1 9/16 – 15 3/8 in
MPEG AUDIO (Monaural)
(39 – 390 mm) when
Recording medium
converted into a 35 mm still
8 cm CD-R
camera)
Flash
F = 2.8
Recommended recording
Exposure control
distance:
Automatic exposure
23 5/8 in to 8 1/3 feet (0.6 m
White balance
to 2.5 m)
Automatic, Indoor, Outdoor,
One-push
MVC-CD1000
This service manual contains information for japanese model as well.
DDX-G2000 COMPLETE ASSEMBLY
Disassembly ................................. Page 2-12 to 2-13
Exploded view .............................. Page 6-8
MD-082 board
Block diagram ............................ Page 3-23 to 3-28
Schematic diagram .................... Page 4-27 to 4-36
Printed wiring board ................... Page 4-23 to 4-26
Electrical parts list ...................... Page 6-11 to 6-16
SPECIFICATIONS
Input and Output
Drive
Read: Maximum ×8
connector
Write: × 4
A/V OUT (MONO) jack
Readout
(Monaural)
Noncontact optical readout
Minijack Video:
(using semiconductor laser)
1 Vp-p, 75Ω , unbalanced,
Laser
sync negative
Wavelength: 777 to 787 nm
Audio: 327 mV (at a 47 kΩ
NA: 0.5
load)
Maximum output: 23 mW
Output impedance: 2.2 kΩ
Emission duration: 600 ns
DIGITAL I/O jack
4-pin connector
External flash jack
Minijack
US Model
Canadian Model
AEP Model
UK Model
Australian Model
Japanese Model
LCD screen
LCD panel
TFT (Thin Film Transistor
active matrix) drive
LCD size
2.5 type
Total number of dots
123 200 (560×220) dots
Viewfinder
LCD panel
TFT (Thin Film Transistor
active matrix) drive
Total number of dots
180 000 (800×225) dots
— Continued on next page —
DIGITAL STILL CAMERA
E Model
