USER GUIDE AND
INSTALLATION
CAMPER CONVERSION
KIT FOR VANS
© C O P Y R I G H T R O A D L O F T 2 0 2 4
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAMPER CONVERSION KIT and is the answer not in the manual?

Questions and answers

Related Manuals for ROADLOFT CAMPER CONVERSION KIT

Summary of Contents for ROADLOFT CAMPER CONVERSION KIT

  • Page 1 USER GUIDE AND INSTALLATION CAMPER CONVERSION KIT FOR VANS © C O P Y R I G H T R O A D L O F T 2 0 2 4...

  • Page 2: Table Of Contents

    Your first installation? Take the time to familiarize yourself with the steps to ensure correct use. We guarantee that you will quickly become an expert in the installation of your RoadLoft conversion kit. For any questions, contact us : Email : info@roadloft.com...

  • Page 3: Welcome In The Roadloft Community

    This is why your set is designed from quality eco- responsible materials, made with meticulousness by our team of experts to accompany you on all your adventures. We sincerely hope that your RoadLoft set will bring you more spontaneity and make you travel in complete freedom.

  • Page 4: List Of Parts

    Brackets, 10 screws, a table, a Honda Odyssey 2005+, Sienna table pole and a Bookcase 2005 + kits have plastic legs. connector Refer to Annex 1. Solo kit : 1 piece of the bench User guide | Roadloft 2024 | Version 2_EN...

  • Page 5: List Of Tools

    Since you may decide to keep these sections assembled when storing your kit, these steps may be optional for future installations in your vehicle. User guide | Roadloft 2024 | Version 2_EN...
  • Page 6 Repeat the steps for the second connector piece. Depending on your kit version, you may need to screw it from underneath the structure. Kits made after 2025, screw from under. For those made before 2025, screw over. User guide | Roadloft 2024 | Version 2_EN...
  • Page 7 2. Open a drawer and insert three screws through the back of box A into the inserts of box B (see next image for reference). User guide | Roadloft 2024 | Version 2_EN...
  • Page 8 If you are installing the Duo Mode only or if you have Odyssey 2005-2017, kia Carnival, Kia Sedona or Nissan NV200 that doesn’t allow for the solo mode skip to the page 11. User guide | Roadloft 2024 | Version 2_EN...
  • Page 9 3. If you’ve selected Scenario 4 or 7, move the drawer lock to the opposite side. To do this, unscrew the lock, place it on the other side, and reattach it using the same screws. User guide | Roadloft 2024 | Version 2_EN...
  • Page 10 5. Install the table supports on the central module, on the selected half opposite the U- bracket. Screw from the inside of the box, using one screw and one washer per hole. User guide | Roadloft 2024 | Version 2_EN...
  • Page 11 Vehicles listed above need kitchen drawer legs to support the boxes. Refer to Annex 3. 4. Lock the boxes in place by sliding the drawer locks toward the central module. User guide | Roadloft 2024 | Version 2_EN...
  • Page 12 7. Adjust the position of the bench by sliding the bookcase box into the attachment points on both the bench and the center module. If needed, slightly lift the bench box to fully insert the bookcase box into place. User guide | Roadloft 2024 | Version 2_EN...
  • Page 13 If the edges are not at the same level, adjust the height of the leveling pads. 10. Lock the bookcase section. User guide | Roadloft 2024 | Version 2_EN...

  • Page 14: Opening The Drawers

    Make sure to remove your finger from the lock when opening the drawer. User guide | Roadloft 2024 | Version 2_EN...

  • Page 15: Drawer Lock

    Ford Transit, and Nissan NV200. The drawers are equipped with a lock that allows them to stay securely open when needed. To lock the drawers, slide the black piece to the side then down. User guide | Roadloft 2024 | Version 2_EN...

  • Page 16: Setting Up The Table

    Screw the leg into the tabletop, then insert the lower end into the slot in the bookcase section. Turn the key to tighten the leg and secure the table in place, preventing it from rotating. User guide | Roadloft 2024 | Version 2_EN...

  • Page 17: Recommended Use Of Your Kit

    72 hours, remove it from the cover. MAINTENANCE Conversion kit: Store in a dry place. Store flat. Mattress and Curtain Cover: Machine wash gentle cycle in cold water. Hang to dry. User guide | Roadloft 2024 | Version 2_EN...

  • Page 18: Warranty

    Get into nature, while respecting it WARRANTY Visit our website Roadloft.com for any question related to the warranty. YOUR REVIEW HELPS US If you would like to help us, we would very much appreciate your feedback on our Facebook page and our Google page. Thanks in advance! Your opinion is very important to us.

  • Page 19: Annex 1: Installation Of Bench Legs

    2 x ½ '’ back side at corner 2011-2017 4 x 5 '’ front side Honda Odyssey 2 x ½’’ back side, drawer side 2018 + 2 x 1 ¾’’ back side, center User guide | Roadloft 2024 | Version 2_EN...
  • Page 20 2. Insert the assembled parts A and B into the designated slots beneath the bench. Note: the drawer has been removed in the picture, but this step is not necessary to install the legs. User guide | Roadloft 2024 | Version 2_EN...
  • Page 21 6. Assemble parts C and D of the long legs. To do this, insert the hooks on part C into the central hole of part D. User guide | Roadloft 2024 | Version 2_EN...
  • Page 22 E into the bench box to secure it in place. Use one screw and one washer per hole. 9. In Duo mode, repeat steps 6 to 8 for the two remaining legs located at the center of the bench. User guide | Roadloft 2024 | Version 2_EN...
  • Page 23 13. Repeat steps 10 to 12 for the two 1" legs in duo mode. Remember that in duo mode, the 1" legs must be placed at the ends of the bench, towards the drawer opening. User guide | Roadloft 2024 | Version 2_EN...
  • Page 24 4 B, 4 C, 8 screws and 8 washers 1. Assemble parts A and B of the leg. To do so, insert the hooked part of part A into the hole in the center of part B. User guide | Roadloft 2024 | Version 2_EN...
  • Page 25 Use one screw and one washer per hole. 4. Repete steps 1 to 3 for the 4 legs in solo mode on one piece or the 4 legs in duo mode at end of full bench. User guide | Roadloft 2024 | Version 2_EN...

  • Page 26: Annex 2: Leveling Pads On Central Module And Fixing Straps

    3 under 2 fixing straps on the sides 2 fixing straps 2 fixing straps back of below kitchen below kitchen vehicule - boxes boxes Attach to See Annex 6 See Annex 6 anchor User guide | Roadloft 2024 | Version 2_EN...
  • Page 27 2 fixing 2 fixing straps straps straps on the sides on the sides below the back of back of bench See vehicule- vehicule - Annex 6 Attach to Attach to anchor anchor User guide | Roadloft 2024 | Version 2_EN...

  • Page 28: Annex 3: Kitchen Drawers Legs Size

    10 ⅞ ‘’ 11 ¼ ‘’ Honda Odyssey 2005-2010 9 ¾ ‘’ Honda Odyssey 2011-2017 Kia Carnival 10 ⅛ ‘’ Kia Sedona 11 ¾ ‘’ This is how to measure the kitchen drawers legs: User guide | Roadloft 2024 | Version 2_EN...

  • Page 29: Annex 4: Kitchen Drawers Legs Assembly

    The leg is now secure and should stay in place when you lift the drawer unit up. Go back to Step 3 in the main installation process. User guide | Roadloft 2024 | Version 2_EN...

  • Page 30: Annex 5: Solo Mode Installation Scenarios

    Get into nature, while respecting it ANNEX 5 - Solo mode installation scenarios Scenario 1 Scenario 2 Scenario 3 Scenario 4 Scenario 5 Scenario 6 Scenario 7 Scenario 8 User guide | Roadloft 2024 | Version 2_EN...
  • Page 31 Scenario 2 Placement of the U-bracket - Placement of the U-bracket - bench central module Scenario 3 Placement of the U-bracket - Placement of the U-bracket - central module bench User guide | Roadloft 2024 | Version 2_EN...
  • Page 32 (place lock on other side) Scenario 5 Placement of the U-bracket - Placement of the U-bracket - central module bench Scenario 6 Placement of the U-bracket - Placement of the U-bracket - central module bench User guide | Roadloft 2024 | Version 2_EN...
  • Page 33 Placement of the U-bracket - Placement of the U-bracket - central module bench (place lock on other side) Scenario 8 Placement of the U-bracket - Placement of the U-bracket - central module bench User guide | Roadloft 2024 | Version 2_EN...

  • Page 34: Annex 6: Strap System

    HONDA ODYSSEY ONLY Tighten the strap by pulling on the loose end until it is fully taut. Go back to step 7 in the main installation process User guide | Roadloft 2024 | Version 2_EN...
  • Page 35 3. Leave the strap installed after anchoring and proceed to installing the drawers. 4. Insert the two rear boxes (sink drawer and burner drawer) in the fastening system of the central module. User guide | Roadloft 2024 | Version 2_EN...
  • Page 36 8. This will give you access to the slot to attach the strap to the drawer. Take the upper part of the strap (the tip) and insert it from below the drawer. User guide | Roadloft 2024 | Version 2_EN...
  • Page 37 If your kit includes attachment straps, first secure the straps to the vehicle’s anchor points. Then, pull the straps to tighten them and ensure the module is held firmly in place. Go back to step 6 in the main installation process User guide | Roadloft 2024 | Version 2_EN...
