ROADLOFT CAMPER CONVERSION KIT User Manual And Installation Manual

For pickup truck
Hide thumbs Also See for CAMPER CONVERSION KIT:

Advertisement

Table of Contents

CAMPER CONVERSION KIT
FOR PICKUP TRUCK
© C O P Y R I G H T R O A D L O F T 2 0 2 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAMPER CONVERSION KIT and is the answer not in the manual?

Questions and answers

Related Manuals for ROADLOFT CAMPER CONVERSION KIT

Summary of Contents for ROADLOFT CAMPER CONVERSION KIT

  • Page 1 CAMPER CONVERSION KIT FOR PICKUP TRUCK © C O P Y R I G H T R O A D L O F T 2 0 2 4...

  • Page 2: Installation

    Your first installation? Take the time to familiarize yourself with the steps to ensure correct use. We guarantee that you will quickly become an expert in the installation of your RoadLoft conversion kit. For any questions, contact us : Email : info@roadloft.com...
  • Page 3 This is why your set is designed from quality eco- responsible materials, made with meticulousness by our team of experts to accompany you on all your adventures. We sincerely hope that your RoadLoft set will bring you more spontaneity and make you travel in complete freedom.
  • Page 4 (A and C) table (B) 1 right side storage unit 1 left bed unit (E) with table (L-shaped) (D) 1 right bed unit (F) 1 kitchen drawer - burner (G) User guide | Roadloft 2024 | Version 1 EN...
  • Page 5 1 kitchen unit with drawer and sink (I) 2 folding bed panels 2 removable storage units 1 panel to complete the 1 sectional mattress bed's foot 1 pole and table feet User guide | Roadloft 2024 | Version 1 EN...
  • Page 6 Identification Hardware Images Quantity 1/2" long butterfly screw 1" long butterfly screw 1'’3/8 long butterfly screw Cam-buckle tie-down strap.

  • Page 7: List Of Required Tools

    Your two hands or a 3/16" Allen key. INSTALLATION STEPS Installation of the units in the bed. 1. Insert unit A (left corner storage) at the back of the bed. 2. Install unit B (left side storage). User guide | Roadloft 2024 | Version 1 EN...
  • Page 8 3.2 Install unit D (right side storage unit in an "L" shape). 3.2 To do this, insert the "male" part of unit C into the "female" part of unit D. User guide | Roadloft 2024 | Version 1 EN...
  • Page 9 5. Install the right bed unit F (the one with the bed support on the left) by inserting the black plastic piece from box F into the black plastic "U" of box D.. User guide | Roadloft 2024 | Version 1 EN...
  • Page 10 6.1 Align the two bed units E and F. 6.2 Secure with 2 butterfly screws that are 1 3/8" long (screws Z). Here’s what the result of the previous steps looks like. User guide | Roadloft 2024 | Version 1 EN...
  • Page 11 8. Install the burner kitchen drawer G on the left. 8.1 To do this, insert the "male" side of unit B into the "female" side of unit G. 8.2 Secure with a 1" long butterfly screw (screw User guide | Roadloft 2024 | Version 1 EN...
  • Page 12 10. Install the metal U between the kitchen units G and H. 10.1 Secure the metal U in units G and H with 4 butterfly screws that are 1/2" long (screws X). User guide | Roadloft 2024 | Version 1 EN...
  • Page 13 12.1 Insert the end of the unknotted rope into the bottom hole of box B from the inside. 12.2 Ensure that the knot is positioned inside the box. User guide | Roadloft 2024 | Version 1 EN...
  • Page 14 15. Tie a knot to secure the elastic and prevent it from coming out. 16. Tie a knot to secure the elastic and prevent it from slipping out. User guide | Roadloft 2024 | Version 1 EN...
  • Page 15 Here is the positioning of the foldable bed panels in backrest mode. Installation of the removable storage boxes 18. Attach the supports of the removable storage box to boxes A and B. Repeat for boxes C and D. User guide | Roadloft 2024 | Version 1 EN...
  • Page 16 You will notice that the unit I is removable. You can move it to your picnic table to have everything within reach, or place it inside your vehicle's cabin to set up the bed across its full width. User guide | Roadloft 2024 | Version 1 EN...
  • Page 17 22. Take the foldable bed panel and unfold it to create the bed surface. 23. Adjust the position of the bed support so that the heads fit perfectly into the holes of the foldable bed panel. User guide | Roadloft 2024 | Version 1 EN...
  • Page 18 24. Lift the flap that covers the cutout of the side storage box. 25. Rotate the table to support the flap via the box. 26. Move the table closer or farther away according to your comfort. User guide | Roadloft 2024 | Version 1 EN...
  • Page 19 Use of the outside table 28. Insert the part with the hook latch into the other part from the top. This is how it should look like. Guide d'utilisation | RoadLoft 2024 | Version 2_FR...
  • Page 20 29. Insert the white ring with the larger notch. 30. Insert the second white ring, which will remain on top. 31. Secure the bottom white ring by sliding the lock into the slot, ensuring that the top hook holds the white ring in place.
  • Page 21 32. Insert the pole. 33. Secure the pole with screws, 34. Screw the table onto the pole. This is how it should look like.

  • Page 22: Recommended Use

    Always secure kitchen compartments G and H to the vehicle. MAINTENANCE Conversion kit: Store in a dry place. Store flat. Mattress cover: Machine wash on a delicate cycle in cold water. Hang to dry. Re-waterproof after each wash. User guide | Roadloft 2024 | Version 1 EN...

  • Page 23: Warranty

    Get into nature, while respecting it WARRANTY Visit our website Roadloft.com for any question related to the warranty. YOUR FEEDBACK IS IMPORTANT TO US If you would like to help us, we would very much appreciate your feedback on our Facebook page and our Google page. Thanks in advance! Your opinion is very important to us.
