RAK 910422 Installation Manual

f Installation Guide
Installation Guide
Package Contents
&
Figure 1: Medium WisBlock Unify Enclosure package content
Number Name Quantity Material Color
1 Top Cover 1 ABS UL94V-0 White or Grey
2 Bottom Base I1 ABS UL94V-0 White or Grey
Black Friday Sale Nov 25-Dec 3! on Meshtastic, LoRaWAN gateways, and more. Shop now!
4 Screw 4-6 Stainless steel
Assembly Guide
1. Prepare the Lid and Gasket.
First, install the rubber gasket in the groove of the top cover, as shown in Figure 2. Put the four
corners of the gasket into the groove, and then press the middle gently. Ensure that the gasket is not
twisted.
