All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
Worldwide telephone list ..............................A-1 Appendix B. Notices ..............................B-1 Recycling information ................................B-2 Collecting and recycling a disused Lenovo computer or monitor ..................B-2 Disposing of Lenovo computer components ........................B-2 Trademarks ................................... B-3 Turkish statement of compliance ............................B-3 Ukraine RoHS ..................................
Do not open your monitor cabinet or attempt to service this product yourself. If your monitor is not operating properly or has been dropped or damaged, contact your Lenovo authorized dealer, reseller, or service provider. Adjust only those controls that are described in the operating instructions.
This User’s Guide contains detailed information on the ThinkVision ® T27-40 LCD Monitor. For a quick overview, please see the Setup Poster that was shipped with your monitor. T27-40 supports Lenovo Accessories and Display Manager-ThinkColour. Shipping contents The product package should include the following items: Information Flyer ...
Notice for use To setup your monitor, please see the illustrations below. Note: Do not touch the monitor within the screen area. The screen area is glass and can be damaged by rough handling or excessive pressure. 1. Take out the Top cushion and accessories. 2.
Product overview This section will provide information on adjusting monitor positions, setting user controls, and using the cable lock slot. Side and top view Table 1-1 Components side and top view Name Description USB 3.2 Gen 1 Type-C Connect your USB device. downstream port USB 3.2 Gen 1 Type-A Connect your USB device.
Back view Table 1-2 Components back view Name Description Power On/Off button To turn the monitor on or off. Function buttons To use the OSD controls. Cable management slot Used to organize cables by routing them through the slot. VESA mounting holes Use for wall-mounting the monitor through a VESA-compatible wall- (100 mm x 100 mm) mount kit.
Types of adjustments Tilt Please see the illustration below for an example of the tilt range. Swivel With the built-in pedestal, you can tilt and swivel the monitor for the most comfortable viewing angle. Height Adjustment After pressing the top of the monitor, you can adjust the height of the monitor. Chapter 1 Getting started 1-5...
Monitor Pivot - Adjust the monitor height before rotating the monitor screen. (Make sure that the monitor screen ascent to its highest point and it inclines backward at 23.5°) - Then rotate clockwise or anticlockwise until the monitor stops at 90°. User controls Your monitor has controls at the rear which are used to adjust the display.
3. Connect one end of the DP cable to the DP connector on the back of the computer, and the other end to the DP connector on the monitor. Lenovo recommends that customers who require using the DisplayPort input on their monitor purchase the "Lenovo DisplayPort to DisplayPort cable 0A36537".
Page 15
4. Connect one end of the HDMI cable to the HDMI connector on the back of the computer, and the other end to the HDMI connector on the monitor. Lenovo recommends that customers who require to use the HDMI input on their monitor purchase the “Lenovo HDMI to HDMI cable 0B47070”.
Page 16
7. Connect one end of the USB cable to the USB downstream terminal of the monitor, and connect the other end of the USB cable to an appropriate USB port on your device. Note 1: The USB downstream port does not provide power while the monitor is switched off. (To use top port USB, first remove the rubber cover)...
Please take a few moments to register your product and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you.
Chapter 2 Adjusting and using your monitor This section will give you information on adjusting and using your monitor. Comfort and accessibility Good ergonomic practice is important to get the most from your personal computer and to avoid discomfort. Arrange your workplace and the equipment you use to suit your individual needs and the kind of work that you perform.
Health Administration Prolong exposure to computer screens may cause temporary visual fatigue. Factors including working environment, working habit and posture, screen flicker and blue light contribute to this condition. To minimize visual fatigue certain adjustments can be made on the work stations or using suitable computer screens with features that alleviate eye strain. Environment Visual fatigue is affected by the working environment.
Page 20
Exercises for the eye: Alternate looking up and looking down while keeping the body and head upright. Slowly roll your eyes to look to the left and right. Roll eyes to look at objects on the upper right corner and then on lower right. Do same thing to look at objects on the upper left and lower left.
The monitors achieve the requirement of Low blue Light (Hardware Solution). Accessibility information Lenovo is committed to providing greater access to information and technology to people with disabilities. With assistive technologies, users can access information in the way most appropriate to their disability. Some of these technologies are already provided in your operating system;...
Adjusting your monitor image This section describes the user control features used to adjust your monitor image. Using the direct access controls The direct access controls can be used when the On Screen Display (OSD) is not displayed. Table 2-1 Direct access controls Icon Name Description...
Using the On-Screen Display (OSD) controls The settings adjustable with the user controls are viewed through the On-Screen Display (OSD), as shown below. To use the controls: 1. Press to open the main OSD menu. 2. Use to move among the icons. Select an icon and press to access that function.
Page 24
Table 2-2 OSD functions Controls and Description OSD Icon on Main Menu Submenu Adjustments Brightness Adjusts overall screen brightness Adjusts intensity of red, green, and blue. sRGB BT.709 Neutral Warm Cool Color mode Custom Red: Increases or decreases the saturation of ‘red’...
Page 25
Controls and OSD Icon on Main Menu Submenu Description Adjustments Note: Following functions will be always on USB always on USB data transfer Power delivery Auto Full range 0-255 Only HDMI Video range Limited range 16-235 ...
Selecting a supported display mode The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer documentation for details on how to change display modes. The image size, position and shape might change when the display mode changes. This is normal and the image can be readjusted using automatic image setup and the image controls.
Image rotation Before rotating the monitor, you should set-up your computer to rotate the image. Rotating the image may require special rotation software or you may find that your computer is preloaded with video graphic drivers that allows image rotation. Check the Graphic Properties setting on your computer to see if this feature is available.
Caring for your monitor Be sure to turn off the power before you perform any maintenance on the monitor. Do not: Apply water or liquid directly to your monitor. Use solvents or abrasives. Use flammable cleaning materials to clean your monitor or any other electrical equipment. ...
Wall Mounting (Optional) Refer to the instructions that come with the VESA compatible base mounting kit. 1. Place the monitor face down on a non-abrasive surface on stable flat table. 2. Remove the stand. 3. Attach the mounting bracket from the wall mounting kit to the monitor. 4.
Chapter 3 Reference information This section contains monitor specifications, instructions to manually install the monitor driver, troubleshooting information, and service information. Monitor specifications Table 3-1. Monitor specifications Height 537.81 mm (21.17 in.) Dimensions Depth 195.00 mm (7.68 in.) Width 611.91 mm (24.09 in.) Weight Unpacked 6.51 kg...
Page 31
Size ratio 16:9 Aspect Ratio Communications VESA DDC/CI Operation 5000 m (16404 ft.) Altitude Test Supported Display Modes Horizontal frequency VGA: 30 to 83 kHz (VESA Standard modes HDMI: 30 to 140 kHz between noted ranges) DP: 30 to 140 kHz Vertical frequency VGA: 48 to 75 Hz HDMI: 48 to 120 Hz...
Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-2. Troubleshooting Problem...
Page 33
Table 3-2. Troubleshooting (continued) Problem Possible cause Suggested action Reference Press any key on the Screen is blank and The monitor is in “Understanding power keyboard or move the power indicator is Standby/Suspend management” on page mouse to restore steady amber or mode 2-10...
Turn on the monitor and then the system unit. Allow your computer to start the Windows operating system. From the Lenovo website https://pcsupport.lenovo.com/solutions/t27_40, find the corresponding monitor driver and download it to a PC to which this monitor is connected (such as a desktop).
Customer Support Centre, please see Appendix A, “Service and Support” on page A-1. Service parts The following parts are for use by Lenovo service, or Lenovo authorized dealers to support the customer warranty. Parts are for service use only. The table below shows information for model 64A5MAR6WW.
Product replacement assistance or exchange of defective components also is available during the warranty period, assistance for replacement or exchange of defective components is available. In addition, if your option is installed in a Lenovo computer, you might be entitled to service at your location. Your technical support representative can help you determine the best alternative.
Page 37
Finland Warranty service and support: +358-800-1-4260(Finnish) France Warranty service and support (hardware): 0810-631-213(French) Warranty service and support: 0800-500-4618 (toll-free) (German) Germany Lenovo Business Partner (Greek) Greece Dial 999-9190, wait for operator, and request to reach 877-404-9661 Guatemala (Spanish) Dial 800-0123(Spanish)
Page 38
020-513-3939 (Dutch) Netherlands 0508-770-506 (English) New Zealand 001-800-220-2282 (Spanish) Nicaragua 8152-1550(Norwegian) Norway Lenovo Customer Support Center: 001-866-434(Toll-Free) (Spanish) Panama 0-800-50-866 (OPCION 2) (Spanish) Peru 1-800-8908-6454 (GLOBE subscribers) Philippines 1-800-1441-0719 (PLDT subscribers) (Tagalog, English) Laptops and tablets branded with logo Think: 48-22-273-9777...
Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.
Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo ThinkCentre ThinkPad ThinkVision Microsoft, Windows, and Windows NT are trademarks of the Microsoft group of companies. Other company, product, or service names may be trademarks or service marks of others.
