- Page 1 ASSEMBLY INSTRUCTIONS PMT EVO 2.0 S 10°...
- Page 2 SAFETY INSTRUCTIONS REQUIRED MATERIAL REQUIRED TOOLS 6-19 ASSEMBLY PMT // Table of contents // PMT EVO 2.0 S Page 2 // 20...
-
Page 3: General Safety Instructions
In the event of non-compliance with our General Safety Instructions as well as with the installation and mounting of components of the competition, Premium Mounting Technologies GmbH & Co. KG reserves the right to exclude liability. PMT // Safety instructions // PMT EVO 2.0 S Page 3 // 20... -
Page 4: Required Material
Ballast stone Cross and ballast brace Cross brace connector Lightning protection screw Module and ballast clamps Ballast trough V01/V02 as middle and end clamps Rear wall Side wall PMT // Required material // PMT EVO 2.0 S Page 4 // 20... -
Page 5: Required Tools
REQUIRED TOOLS Notwendig Required Optional Optional Tape measure Rubber hammer Chalk line Assembly jig Torque wrench with SW5 hexagon socket attachment PMT // Required tools // PMT EVO 2.0 S Page 5 // 20... - Page 6 5 steps In only to the finished system Required Optional PMT // Assembly instructions // PMT EVO 2.0 S Page 6 // 20...
- Page 7 - 115 mm INFO All PMT floor rails are equipped with an 11 mm thick high-tech protective mat. This ensures free water drainage and pre- vents damage to the roofing from mechanical influences and long-term damage from plasticiser migration. Furthermore, all profiles are equipped with drainage holes on the undersides in order to prevent backwater and frost damage.
- Page 8 ASSEMBLY MIDDLE PART TOWER C AND REAR WALL TOWER H INFO The tower components serve as upper support elements for the modules in all PMT systems, the rear wall tower serves as receiving element for the rear wall. SEQUENCE: Push the middle part tower to the two narrow recesses 1 (to the long end of the rail) with the latching lug pointing away on the floor profile.
- Page 9 NOTE: The cross brace must always be mounted on the tower. Always make sure that the cross and ballast brace the tower has sufficient contact surface (at least 15 mm). PMT // Assembly instructions // PMT EVO 2.0 S Page 9 // 20...
- Page 10 In order to protect the string lines from permanent and harmful environmental influences – in particular UV radiation – all PMT floor rails are equipped with cable duct cover holders. The installation of the cable duct cover is possible after each working step of the system construction.
- Page 11 Deviations from the planning has to be agreed with PMT in writing and be carried out afterwards. Positioning of the ballast components shall be chosen appropriate to permanently prevent slipping, tipping, or wobbling. The ballast must lie over the entire surface;...
- Page 12 Deviations from the planning has to be agreed with PMT in writing and be carried out afterwards. Positioning of the ballast components shall be chosen appropriate to permanently prevent slipping, tipping, or wobbling. The ballast must lie over the entire surface;...
- Page 13 . Observe tightening torque of 10 Nm. ATTENTION All floor and connecting floor rails must be screwed together so that the system is capable of carrying lightning currents. PMT // Assembly instructions // PMT EVO 2.0 S Page 13 // 20...
- Page 14 . Ensure even coverage in the trough ATTENTION Ensure minimum coverage in the trough according to the planning documents! The maximum pouring height must not exceed 70 mm. PMT // Assembly instructions // PMT EVO 2.0 S Page 14 // 20...
- Page 15 For each trough, six evenly distributed screws are to be inserted in the middle. Observe maximum torque of 5 Nm! ATTENTION Ensure minimum coverage in the trough according to the planning documents! The maximum pouring height must not exceed 70 mm. PMT // Assembly instructions // PMT EVO 2.0 S Page 15 // 20...
- Page 16 Observe tightening torque of 10 Nm. (Please note the SERVICE information.) INCORRECT CORRECT NOTE: Make sure that the clamps are not pressed too much and that they are not bent as a result. PMT // Assembly instructions // PMT EVO 2.0 S Page 16 // 20...
- Page 17 M8x16 screw. INCORRECT CORRECT ATTENTION The working direction from east to west with 1 4 … must be observed. PMT // Assembly instructions // PMT EVO 2.0 S Page 17 // 20...
- Page 18 The side cover is a safety-relevant stability component. The omission of the side covers stated in the project report will inevitably lead to the exclusion of liability of Premium Mounting Technologies GmbH & Co. KG. PMT // Assembly instructions // PMT EVO 2.0 S Page 18 // 20...
- Page 19 Changes and deviations from the planning documents must be agreed to Premium Mounting Technologies GmbH & Co. KG in writing! Thanks for choosing a flat roof mounting system from PMT!!! PMT // Assembly instructions // PMT EVO 2.0 S Page 19 // 20...
-
Page 20: Service Hotline
The assembly instructions must be observed during assembly. This assembly instruction can also be found in digital form under www.pmt.solutions/en/downloads or directly scan the QR code with your smart phone. (Requirements: Your mobile terminal must be equipped with an appropriate app) Premium Mounting Technologies GmbH &...
