TrimLine Vehicle Dock with Flex Lock
For Panasonic FZ-G1 Toughpad Tablet Computers
Description
PMT Standard G1 Vehicle Dock with Flex Lock
PMT Standard G1 DPT Vehicle Dock with Flex Lock
PMT Extended G1 Vehicle Dock with Flex Lock
PMT Extended G1 DPT Vehicle Dock with Flex Lock
Note: Extended docks accommodate extended batteries and hand straps
User Guide
www.precisionmounts.com
Part Number
AS7.P001.101
AS7.P001.105
AS7.P001.201
AS7.P001.205
Advertisement
Related Manuals for PMT AS7.P001.101
Summary of Contents for PMT AS7.P001.101
- Page 1 Description Part Number PMT Standard G1 Vehicle Dock with Flex Lock AS7.P001.101 PMT Standard G1 DPT Vehicle Dock with Flex Lock AS7.P001.105 PMT Extended G1 Vehicle Dock with Flex Lock AS7.P001.201 PMT Extended G1 DPT Vehicle Dock with Flex Lock AS7.P001.205...
-
Page 2: Front View
Description of Parts and Layout Note: Pictures used are of a standard dual pass thru (DPT) vehicle dock, however processes and info relate to all PMT FZ-G1 vehicle docks Front View Top Clamp Locating Pin Docking Connector Docking Guide Plate... -
Page 3: Rear View
Description of Parts and Layout Note: Pictures used are of a standard dual pass thru (DPT) vehicle dock, however processes and info relate to all PMT FZ-G1 vehicle docks Rear View Top Clamp Flex Lock Lever Mounting Plate attachment holes (4) 2 each... - Page 4 Description of Parts Continued Rear View Internal/External Antenna Switch -Switch should be towards the outboard side of the dock when using external (RF pass-though) antennas WLAN (WIFI or GPS) (optional) -SMA style connector* WWAN (cellular data) Power USB 3.0 HDMI Serial (optional) 16v dc...
- Page 5 Inserting the Tablet Step 1: Ensure the dock is unlocked To unlock insert key and rotate to the horizontal (unlocked) position and remove the key Step 2: Pull the Flex Lock Lever towards the outside of the dock The Top Clamp will spring up to the open position to allow easy tablet docking Step 3:...
- Page 6 Inserting the Tablet Step 4: Push the Top Clamp down until it clicks. The Flex Lock lever will auto-engage and the tablet is now secure in the dock and ready for use Step 5: For added theft deterrence you may now insert the key and rotate to vertical (locked) position, then remove the key...
- Page 7 Removing the Tablet from Docking Station Step 1: Ensure the dock is unlocked To unlock insert key and to the horizontal (unlocked) position and remove the key Step 2: Pull the Flex Lock Lever towards the outside of the dock The Top Clamp will spring up to the open position to allow easy tablet removal...
- Page 8 Wiring Tip: PMT does not recommend relying on a cigarette socket adaptor for powering vehicle docks. We recommend hard wiring using a good clean ground direct from the...
- Page 9 PMT VESA 75mm x 75mm AS7.P001.001 mounting/interface plate The standard mounting/interface plate that comes with the PMT G1 TrimLine vehicle dock features an industry standard VESA 75mm x 75mm bolt pattern. This allows easy mounting to many pre-existing mounts as well as dedicated mounts from PMT.
