- Page 1 Under Cabinet Range Hoods User Manual Model numbers: OV-1011R / OV-1031 / OV-1012RWH / OV-1032 Scan this QR code to watch the installation video or to visit the product page FOR RESIDENTIAL USE ONLY UM1011R/12RWH...
-
Page 2: Before You Begin
Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 8 to 14. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood. -
Page 3: Table Of Contents
Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4-5 Included Parts ........................... 6 Range Hood Dimensions ........................7 ............................ 7 Installation ............................8 Step 1 - Read the Safety Instructions .................... 8 Step 2 - Unpack Range Hood and Prepare Tools ................ -
Page 4: Important Safety Information
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur. Always contact your service technician or manufacturer about problems that you do not understand. - Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy DO NOT turn on the lights or any type of appliance.
-
Page 6: Included Parts
Included Parts Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding the optimal type of mounting screws and wall anchors to suit your home’s construction. Filter Range Hood Rectangular Vent/Damper... -
Page 7: Range Hood Dimensions
Range Hood Dimensions 12” (30.5 cm) 29.9” (76 cm) 3.1” (8 cm) 9.9” (25.2 cm) 9” (22.9 cm) 4.7” (12 cm) 17.5” (44.5 cm) 3.1” (8 cm) 9.9” (25.2 cm) 27.8” (70.6 cm) Specifications Body Design Stainless Steel Power Rating Model number OV-1011R / OV-1012RWH OV-1031 / OV-1032... -
Page 8: Installation
Installation STEP 1 Read the Safety Instructions It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools Carefully unpack the range hood and parts. -
Page 9: Step 5 - Venting Installation Guidelines
Installation STEP 5 Venting Installation Guidelines The following steps are for exterior ventilation. IMPORTANT: For the most efficient and quiet operation: Vent system must terminate to the outside (roof or side wall). terminate the vent system in an attic or other vertically through the roof through 7 in. - Page 10 Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) A minimum of 7 in. (17.8 cm) round or 3-1/4 × 10 in. (8.3 for electric cook tops. cm × 25.4 cm) rectangular duct must be used to maintain maximum air ow ef ciency.
-
Page 11: Step 6 - Preparations
Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. Determine and mark the center line on the ceiling or wall where the range hood will be installed. Make sure there is proper clearance within the ceiling or wall for exhaust vent. secure in the ceiling or wall. -
Page 12: Step 8 (External Ventilation Only) Attaching Vent/Damper And Panel Piece
Installation For external ventilation, please follow step 8. For internal re-circulation, please follow step 9. STEP 8 (External Ventilation Only) Attaching Vent/Damper and Panel Piece Depending on the exterior venting option chosen (see page 10), pop out the steel panel on either the top or rear of the range hood (see Figure 4). -
Page 13: Step 9 - Electrical Connection
Installation STEP 9 Electrical Connection Depending if using the wiring hole A or hole B, connect cable to range hood wiring (see Figure 7). Connect BLACK to BLACK, WHITE to WHITE and GREEN to GREEN (see Figure 8). DON’T FORGET TO CONNECT THE GROUND! (green wire) Figure 7 SAFETY WARNING: Risk of electrical shock. -
Page 14: Step 10A Wall Installation
Installation For wall installation, please follow step 10A. For cabinet installation, please follow step 10B. STEP 10A Wall installation Mark or drill a small hole on the mounting position according to the dimensions on Figure 9. Insert suitable screws into the holes. Hang the range hood onto the screws. -
Page 15: Range Hood Assembly
Range Hood Assembly PART NAME US cord switch wire damper round damper optional body top & rear speed rocky switch LED rocky switch clamp electric supply box panel piece motor bracket impeller housing LED light aluminum filter — 15 —... -
Page 16: Circuit Diagram
Assembly Circuit Diagram Blower Assembly Number Part Motor Bracket Impeller Housing Electrical Assembly Number Part Electric supply box — 16 —... -
Page 17: Operation
Operation Speed button Light button Power Light Press for low speed. Press to turn on the light. Press for high speed. Press to turn off the light. Position the rocker switch to the middle position to turn off. Troubleshooting Problem Possible Cause If the range hood or LED light Check if the range hood has been plugged in, make sure that all power... -
Page 18: Maintenance
Maintenance Range Hood Cleaning Proper maintenance of the Range Hood will ensure proper performance of the unit. Stainless steel is one of the easiest materials to keep clean. Occasional care will help preserve its appearance. Cleaning tips: Hot water with soap or detergent is all that is usually required. Follow all cleaning by rinsing with clear water. -
Page 19: Use And Care Information
Use and Care Information Operations Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. and loose clothing. NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into fans. combustion is higher when the oil has been used several times. - Page 20 USA: www.myovo.net Canada: www.myovo.ca +1-800-776-7891 TO REGISTER YOUR WARRANTY: USA: myovo.net/register Canada: myovo.ca/registrer TO PURCHASE NEW BAGS AND FILTER USA: myovo.net/product-category/bags-and-filter CANADA: myovo.ca/product-category/bags-and-filter 2044 Autoroute 440 Ouest, Laval, QC, H7S 2M9 UM1011R/12RWH...
