Page 1
Under cabinet Range Hood User Manual Model Numbers: OV-1001 / OV-1013 Scan this QR code to watch the installation video or to visit the product page FOR RESIDENTIAL USE ONLY Patent pending UM-UNDCCT-1...
Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 to 6 and Installation Instructions are on pages 9 to 17. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood.
Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 7 Range Hood Dimensions ........................8 ............................ 8 Installation ............................9 Step 1 - Read the Safety Instructions .................... 9 Step 2 - Unpack Range Hood and Prepare Tools ................
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur. Always contact your service technician or manufacturer about problems that you do not understand.
Page 5
Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy DO NOT turn on the lights or any type of appliance.
Page 6
Important Safety Information WARNING: TO REDUCE RISK OF A RANGE 7. Two installers are recommended because of TOP GREASE FIRE: 8. This product is equipped with a thermostat air, be sure to duct air outside. Do not vent which may start blower automatically. To exhaust air into spaces within walls or ceilings reduce the risk of injury and to prevent power or into attics, crawl spaces, or garages.
Included Parts Range Hood Vent-round Vent-rectangle Metal Cover Rectangle bracket 3 + 1 pieces wire connector 2 Filters 9 + 1 Mounting Screws (8 mm) Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material.
Range Hood Dimensions 8.3 cm (3 1/4 in.) Specifications Body Design Stainless Steel Power Rating (cETLus Listed) 141 W 201 W Total Input Power (135 W + 2 × 3 W) (195 W + 2 × 3 W) Motor Input Power 135 W 195 W Amperage...
Installation STEP 1 Read the Safety Instructions It is very important to read the safety instructions on pages 4, 5 and 6. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools Carefully unpack the range hood and parts.
Installation STEP 5 Venting Installation Guidelines The following steps are for exterior ventilation. IMPORTANT: For the most efficient and quiet operation: Vent system must terminate to the outside (roof or side wall). terminate the vent system in an attic or other vertically through the roof through 6 in.
Page 11
Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) A minimum of 6 in. (15 cm) round or 3-1/4 × 10 in. (8.3 cm for electric cook tops. × 25.4 cm) rectangular duct (purchased separately) must be used to maintain maximum air ow ef ciency.
Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. Determine and mark the center line on the ceiling or wall where the range hood will be installed. Make sure there is proper clearance within the ceiling or wall for exhaust vent. secure in the ceiling or wall.
Installation A metal cover is included, to protect the motor. To install, loosen and remove the 4 screws, then put the metal cover on and tighten the screws. Figure #3 STEP 9 Attaching Vent There are 3 venting ways, with 2 type of damper options, one is 6 in. round (15 cm), another is 3 1/4 × 10 in. (8.3 cm × 25.4 cm) rectangle.
Page 14
Installation Top venting using rectangular damper If you require rectangular top (vertical) venting simply install the rectangular damper provided (See Figure #8, #9 and #10). Use screws 4 × 8 mm to connect damper. Figure #8 Figure #9 Fix rectangle damper to the top by screws 4 ×...
Installation STEP 10 Installing the Hood Method 1: Attaching the unit to the wall The following drawings show the mounting dimensions of the 30 in. (750 mm). Mark or drill 4 small holes on the mounting position according to the dimensions on Figure #14. Insert 4 drywall anchors into the holes, and 2 screws into the top holes.
Installation STEP 11 Venting Depending on exterior ventilation chosen (see page 10), either exit the ducting through the ceiling or wall. tape product is recommended. Connect ductwork to damper. Use Duct Tape to ensure joint is sealed and air tight. IMPORTANT: It is the customer’s responsibility to contact a qualified electrical installer.
Installation STEP 12 Install Filters Figure #18 Cleaning Filters IMPORTANT: Drain oil from spacers, filters, oil tunnels, oil containers before oil and residue overflow! Dry thoroughly before replacing and follow directions for installation in reverse. Filters should be cleaned after every 30 hours of use. Canada Scan this QR code to Scan this QR code to...
Operation Light Function Auto Decrease Increase Power Shut-off Speed Speed On / Off Speed Settings 5 Built-in color temperature function (2700K / 3000K / 3500K / 4000K / 5000K) Press the button once and the motor starts to operate at one speed (minimum speed). ** Before you start, make sure the hood is turned off** Press the button second / third / fourth time and the...
Maintenance Replacing the Light Pucks IMPORTANT: ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION ON THE APPLIANCE. Make sure the range hood is unplugged or turn OFF Replace with a 12 Volt, 3 Watt max, LED lights. breaker.
Range Hood Assembly Number Part Vent (rectangle) Vent (round) Rectangle bracket Housing assembly Motor bracket Slot Motor Wheel Metal ring Metal cover Filter (1 set with 2 pieces) LED puck lights Screw bag Terminal cap Cover of control box Control board Control button Control box Bracket of control...
Assembly Circuit Diagram Blower Assembly Number Part Ring Blower Propeller Motor Bracket of motor Electrical Assembly Number Part Bracket of electronic box Base of electronic box Capacitor Shielding plug-in Cover of electronic box — 21 —...
Troubleshooting Problem Cause Solution Light on, but motor does not The motor blocked Get rid of the blocking work The capacitor is damaged Have capacitor replaced The motor bearings are jammed Have motor replaced or damaged Light does not work, motor does Beside the mentioned above, check the following: not work Light is damaged...
Use and Care Information Operations Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. and loose clothing. NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into fans. combustion is higher when the oil has been used several times.
Page 24
TO REGISTER YOUR WARRANTY: USA: myovo.net/register Canada: myovo.ca/registrer TO PURCHASE NEW ACCESSORIES, PARTS AND FILTERS USA: myovo.net - CANADA: myovo.ca 2044 Autoroute 440 Ouest, Laval, QC, H7S 2M9 +1-800-776-7891 UM-UNDCCT-1...
