Sofirn LT1S Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Sofirn LT1S Manual
Thank you for purchasing Sofirn products.
if you need assistance.
Send email to us@sofirnlight.com (amz us order)
eu@sofirnlight.com (amz eu order)
sofirnlight@gmail.com (website order)
Sofirn LT1S is a powerful, versatile Lantern for indoor use and various outdoor activities
like camping, hiking, fishing. It uses one 21700 battery and features a USB-C port for
convenient charging, 2700K LED*18, 6500K LED *18 and Red LED*4 with up to 500 lumen.
It was born from LT1, they share the same diffuser but LT1S has buck driver, smaller size,
furthermore, LT1S enables RED led mode.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT1S and is the answer not in the manual?

Questions and answers

Related Manuals for Sofirn LT1S

Summary of Contents for Sofirn LT1S

  • Page 1 It uses one 21700 battery and features a USB-C port for convenient charging, 2700K LED*18, 6500K LED *18 and Red LED*4 with up to 500 lumen. It was born from LT1, they share the same diffuser but LT1S has buck driver, smaller size, furthermore, LT1S enables RED led mode.

  • Page 2: Specifications

    ANSI/NEMA FL1 Chart Mode Turbo High Medium Moon 1hz Strobe Luminous Flux [lm] 500 lm 150 lm 50 lm 10 lm 1 lm (6000K-2700K) Runtime 2h 20min 90h 3min 555h (6000K-2700K) Runtime 2h 30min (Red Light) Beam Distance [m] 18 m 11 m (6000K-2700K) Peak Intensity [cd]...

  • Page 3: Battery Specifications

    It also turns off automatically if the voltage gets too low. Please recharge the battery.  Advanced Temperature Regulation (ATR) technology: As the temperature rises, LT1S is programmed to automatically step down and step up the brightness. These thresholds are set at 45°C, 55°C and 65°C.
  • Page 4 The LT1S can also operate as a directional light (one side emitters light up, the other side don’t); double click to activate, additional double clicks cycle through: one side on - the other side on - both on.

  • Page 5: Safety Instructions

    The LT1S can also operate as a directional light (one side emitters light up, the other side don’t); double click to activate, additional double clicks cycle through: one side on - the other side on - both on.

  • Page 6: Troubleshooting And Maintenance

    Troubleshooting and Maintenance  Disassembling the sealed head can damage the flashlight and voids the warranty.  Sofirn, Ltd. recommends using high-quality brand batteries. Damage by battery leakage voids the warranty.  Remove the battery if the flashlight will not be used for an extended period of time.
