Preamble: Wood cooker allow you to cook on the stove and heat living spaces during certain periods or to supplement insufficient
centralized heating. They are ideal for holiday or weekend apartments or as additional heating all year round. As fuel, they use wood
logs. The cooker is made up of enamelled and zinc-plated sheet steel plates and enameled cast iron parts (doors, front panel and
plate frame). The fireplace is equipped with a panoramic door with ceramic glass (resistant up to 700°C) which allows a pleasant
view of the fire and which protects against the escape of smoke and sparks.
The fireplace is lined on the inside with individual cast iron plates and its interior includes a flat grid. Below the oven door is a food
warming tray with its closing door: never place any flammable objects or materials there. Heating of the ambient environment is done
by radiation; heat is radiated into the ambient environment through the hot external surfaces of the cooker.
The cooker is equipped with primary and secondary air regulators to regulate combustion.
•
Before using the device, read the instructions and recommendations carefully.
•
The device must be installed in compliance with the national regulations in force in the country where the installation is
carried out.
•
Installation by a professional is strongly recommended.
•
Never obstruct the air inlets provided.
•
The device must be connected to a chimney that does not serve other devices. It is unsuitable for operation on multiple
conduits.
•
Never make unauthorized modifications to the device.
•
The device is not designed to operate with the door open.
•
All surfaces of the device are active (hot) surfaces; it is imperative to take all precautions to avoid burns.
•
Take all precautions to keep children and the elderly sufficiently away to avoid accidents.
•
Ensure that the smoke damper is functioning correctly (direct draft or by circulation) by operating the control lever located
on the front.
OPERATING THE DEVICE
•
Always follow the instructions.
•
When lighting for the first time, only carry out limited loading to check that everything is working properly. Gradually increase
fuel loads over several days.
•
Do not use the device as an incinerator.
•
Use only recommended fuel.
•
After a long period of shutdown, ensure that the duct is not obstructed, as well as the connection pipe and the smoke
passages in the appliance.
LIGHTING
IMPORTANT: it is inevitable that an unpleasant odor will be produced at the first lighting (following the drying of the tights of the
cabled cord of the seal and the protective varnishes). This disappears after a short period of use. It is therefore necessary to ensure
good ventilation of the premises. When lighting for the first time, we advise you to load a reduced quantity of fuel and gradually
increase the heat output of the appliance.
To carry out a correct first ignition of products treated with high temperature varnishes, you must know the following:
the materials used for the manufacture of the devices in question are not homogeneous, indeed coexist elements in cast iron, steel,
refractory and earthenware;
the temperature to which the body of the device is subjected is not homogeneous: from sector to sector we record temperatures
which vary from 300°C to 500°C.
throughout its lifespan, the device is subject to alternating cycles of switching on and off during the same day and to cycles of intense
use or absolute rest during the seasons;
INSTRUCTIONS FOR THE USER
Advertisement
Table of Contents
Related Manuals for Godin DIVOMES
Summary of Contents for Godin DIVOMES
- Page 1 INSTRUCTIONS FOR THE USER Preamble: Wood cooker allow you to cook on the stove and heat living spaces during certain periods or to supplement insufficient centralized heating. They are ideal for holiday or weekend apartments or as additional heating all year round. As fuel, they use wood logs.
-
Page 2: Standard Operation
(Figure 1). The best combustion (min. emissions) is obtained when, when loading the wood, most of the combustion air passes through the secondary air damper. The regulation of the dampers necessary to obtain the nominal heat output with a flue depression of 10-12 Pa is as follows: DIVOMES PROMES PRIMARY AIR... -
Page 3: Operation During Transition Periods
In the case of brass parts that have become bluish due to overheating, use a suitable cleaning product to eliminate this problem. IMPORTANT: Only use spare parts expressly authorized by the GODIN company. If necessary, please contact your qualified dealer. -
Page 4: Cleaning The Glass
This operation, which can only take place with the cooker cold, should be carried out by a chimney sweep who at the same time can control the appliance. The smoke collection compartment can be cleaned through the small door under the oven (after unscrewing the screws that secure the small door to the front of the cooker (Figure 8), check that the position of the smoke deflector is as indicated (Figure 9), or from the top. - Page 5 Check the good condition of the seals which, if they were no longer in perfect condition, would not guarantee the proper functioning of the device. It would therefore be necessary to replace them. If the room where the appliance is located is damp, place absorbent salts inside the appliance hearth. Protect raw cast iron parts with neutral vaseline to maintain their aesthetic appearance intact over time.
-
Page 6: Emergency Response
when, on the other hand, the lever is pulled outwards, the combustion gases rotate around the oven, thus increasing the internal temperature of the oven uniformly (cooker function – baking and heating – OVEN USE). IMPORTANCE OF FUEL The permitted fuels are firewood logs. Only dry wood logs must be used (maximum water content 20%). A maximum of 2-3 logs of wood can be loaded at a time. - Page 7 b. Close the combustion air regulators Extinguish the fire using carbon dioxide (powdered CO2) extinguishers d. Call the fire brigade immediately. DO NOT USE WATER JETS TO EXTINGUISH THE FIRE. Once the drain pipe is turned off, have it checked by a specialist to locate any cracks or leaky points.
