- Page 1 FAR-INFRARED PRE-HEATER PHN-1520 / PHN-3040 Instruction manual Date prepared: JAN. 2019 The 3 edition JAPAN BONKOTE CO., LTD...
-
Page 2: Table Of Contents
Table of contents 1. PREFACE ....................... 1 2. NOTES FOR SAFETY .................. 1 3. FEATURES ...................... 2 4. PARTS NAME ....................2 5. HOW TO USE CONTROLLER 5-1. Temperature Setting ................3 5-2. Auto-Tuning Setting ................3 5-3. Temperature Adjustment ..............4 5-4. -
Page 3: Preface
1. PREFACE Thank you very much for your purchasing “ PHN Series “. Please read this Notes for Safety before use, and use this machine properly. After reading this manual, please keep it. 2. NOTES FOR SAFETY ＣＡＵＴＩＯＮ！ Be sure to read this manual before using this machine. ⚫... -
Page 4: Features
3. FEATURES Far-infrared radiation heater can heat the entire PCBs uniformly. The temperature is adjustable. 4. PARTS NAME === PHN-1520 === Stay bar Aluminum case Ceramic heater Fuse holder Power cord Power switch Temperature controller === PHN-3040 === Stay bar... -
Page 5: How To Use Controller
5. HOW TO USE CONTROLLER Screen description: PV (process value) : Indicating the heater temperature ① SV (setting value) : Indicating the set temperature / each parameter value ② MODE key : Switching the screens ③ AT (auto tuning) key : Start &... -
Page 6: Temperature Adjustment
5-3 How to adjust the temperature Adjusting temperature difference of the machine and standard thermometer. Press MODE key once to indicate “__PuS” on the (PV) display. Refer to Fig.1) Adjust the temperature by using UP (△) or Down (▽) keys. Press MODE key 5 times to return to the normal operation mode. -
Page 7: Maintenance
Then, wipe it with alcohol. DO NOT put extra pressure or strong shock to the heater while cleaning. ＊ DO NOT use metal tools to scrub the stains. ＊ 7. SPECIFICATIONS PHN-1520 PHN-3040 Heating method Far-infrared radiation (Ceramic heater) 0 ~ 40℃ Ambient temperature... -
Page 8: Warranty
8. WARRANTY Our products are shipped after severe factory tests and inspections. BONKOTE warrants the products to be free of manufacturing defects or shipping damage for a period one year with exception of replacements parts. The warranty also does not cover product wear due to use or misuse.
