Sealey SCR791 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure health & safety, local authority and general workshop practice regulations are strictly adhered to when using this
‰
equipment.
Familiarise yourself with product application and limitations, as well as the specific potential hazards peculiar to this product.
9
Maintain creeper in good condition. Use an authorised service agent.
9
Replace or repair damaged parts. Use only genuine parts only. Non authorised parts will invalidate warranty.
9
WARNING! Use the creeper on level and solid ground, preferably concrete.
‰
DO NOT use the creeper for any purpose other than that for which is designed.
8
DO NOT stand on the creeper.
8
DO NOT get the creeper wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT clean the creeper with any solvents which may damage the paint surface or padded areas.
8
2. INTRODUCTION
Powder coated tubular steel construction with padded vinyl cushions. Super-stable design with six smooth-rolling Ø50mm ball-bearing
swivel castors. Converts to seat mode in seconds. 180kg Capacity in creeper mode and 130kg capacity in seat mode.
CREEPER
MODE
3. SPECIFICATION
Model No: ...........................................................SCR791
Capacity: ...................................... 180kg (creeper mode)
.......................................................... 130kg (seat mode)
Nett Weight: ........................................................... 5.8kg
Wheels: .........................................................6 x Ø50mm
4. ASSEMBLY
Refer to Parts (FIG.1)
4.1. ATTACH ASSEMBLIES 1,2,3.
4.1.1. Using bolts (11) washers (7) and nuts (12) assembly all three
pre-built sections (1, 2, 3).
4.2. ATTACH THE 6 CASTOR WHEELS
4.2.1. Fix the 6 castor wheels (8) to the creeper frame using grub screws
(13) and washers (14) shown fig.1.
© Jack Sealey Limited
COMPACT STEEL CREEPER/SEAT WITH 6
WHEELS
SCR791
MODEL NO:
HEADREST
CASTORS
Original Language Version
SEAT
MODE
FIG.1
SCR791 Issue 2 (2) 20/01/25
