- Page 1 User manual Heat pump NPH; NPT; NPET...
- Page 2 Thank you for using our products. By reading these user manual, you will maximize your experience and get maximized of environmental friendly heating system. ATTENTION: To get factory warranty, please register your ES product to the online warranty system: www.energysave.se...
-
Page 3: Table Of Contents
Contents Safety Precautions ..........................4 Main screen ............................5 • Additional symbols on screen ....................6 Menu ..............................6 Room temperature control .........................8 • I’m cold, what to do? .......................8 Increasing the desired room temperature...................8 • I have changed the room temp setting but would still like to have it more worm....9 Sanitary hot water temperature control.................... -
Page 4: Safety Precautions
Safety Precautions To ensure both your personal safety, as well as the safety of the product, note the symbols below and be sure to understand their correlation to each of the precautions depicted. Please carefully read the user manual before use. The installation, dismantlement and maintenance of the unit must be performed by qualified personnel. -
Page 5: Main Screen
Main screen Main screen settings are used to adjust the room temperature and sanitary hot water. Outdoor temperature Room temperature - pressing on the shown room temperature: • setting the room temperature (if room temperature effect on heating curve is enabled) •... -
Page 6: Additional Symbols On Screen
• Additional symbols on screen The symbols listed below appear in case a special function is active. Night mode function is active Outdoor unit defrosting – normal operation Timer for heating sanitary water is active Timer for heating and cooling is active Legionella function is active Floor curing function is active Electrical utility lock is active... - Page 7 Settings according to the electrical grid requirements OTHER OPTIONS Special settings UNIT REAL TIME DATA Readings of temperature, pressure sensors and other data Note: Detailed descriptions of the menus and settings are on ES web page www.energysave.se or consult with your installer!
-
Page 8: Room Temperature Control
Room temperature control Raising or lowering of the room temperature setting influences both temperature zones (zone 1 and zone 2). • I’m cold, what to do? Increasing the desired room temperature. Note: Room temperature control can only be use if the room temperature sensor is placed in the leaving area and the function ˝room temperature effect on heating curve˝... -
Page 9: I Have Changed The Room Temp Setting But Would Still Like To Have It More Worm
• I have changed the room temp setting but would still like to have it more worm. If the changing of the room temperature did not bring the desired effect, please adjust the heating curve for the particle temperature zone (zone 1 or zone 2). Zone 1 (example: first floor): Press the ˝... -
Page 10: Sanitary Hot Water Temperature Control
Sanitary hot water temperature control • I need more hot water Increasing the desired room temperature. Press the ˝ ˝ symbol to increase the desired sanitary hot water temperature. To confirm press ˝ ˝ Note: To lower the desired sanitary hot water −... -
Page 11: What Is A Heating Curve
Note: One of the most common errors is S10 Water flow switch protection, which means that the water flow true the heat pump is restricted or not enough for a safe operation of the heat pump. There can be different reasons: Dirt separator or filter installed on the hydraulic system is dirty. - Page 12 Introduction Main screen User data menu Indicator light Menu button Name of the heat pump • User data menu Username License duration User data – name, phone number, address, e-mail address Remark - add a remark, like contact data of the installer App version Logging out of the APP •...
- Page 13 Real time data Setting button Top line - favorites. All data put in the Top line will get displayed on the main menu. To move the data to the top line, use the setting button. All line – all the data will be displayed that was not put in the top line.
-
Page 14: Web
• Web page access Web page address: http://www.myheatpump.com Enter username and password. - User name - Password - Confirm Language selection Menus “Real time data” opens another window with the correct working data: “History curve” is a graphic representation of the operation of the heat pump. Date selectin Export to Excel Select the data to be... - Page 15 Example: “Setting parameters” - parameters that can be set on the Main controller can be also set in this menu. Additionally, there is a Quick Setting drop-down menu. To confirm the change of the setting press on Setting parameters, otherwise the change will not be valued.
- Page 16 For further information please visit our website or contact your local ES heat pump dealer. Thank you for you purchase, Your ES Team...
