PRE-PLUMBED SEWAGE PUMP
SYSTEM - 30 GAL.
INSTRUCTION AND OPERATING MANUAL
READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL
Save these instructions for future reference. Failure to read and follow
the warnings and instructions within this instruction manual could result
in property damage, serious injury or death.
Mainlinecollection.com
Specifications
Power Supply Requirements
AMP Rating
Temperature Rating
Discharge
IMPORTANT!
BEFORE USING THIS PRODUCT.
FloodStop® PumpTech Support: 1-833-786-7779
115 VAC, 60 Hz
7.4 Amps
32°F to 131°F
2" NPT
MODEL MLFS22502
Advertisement
Table of Contents
Related Manuals for MAINLINE FLOODSTOP MLFS22502
Summary of Contents for MAINLINE FLOODSTOP MLFS22502
- Page 1 PRE-PLUMBED SEWAGE PUMP SYSTEM - 30 GAL. INSTRUCTION AND OPERATING MANUAL Specifications Power Supply Requirements 115 VAC, 60 Hz AMP Rating 7.4 Amps Temperature Rating 32°F to 131°F Discharge 2” NPT MODEL MLFS22502 IMPORTANT! READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL BEFORE USING THIS PRODUCT.
-
Page 2: Safety First
SAFETY FIRST! This instruction manual contains very important information for you to know and understand. This information is provided for your safety and to help prevent equipment problems from occurring. Please observe all safety information labeled danger, warning, caution, and notice. WARNING INDICATES A POTENTIALLY HAZARDOUS SITUATION WARNING WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH, SERIOUS... -
Page 3: Pre-Installation
PERFORMANCE GPH of Water @ Total Feet of Lift Max. MODEL Lift 0 ft. 5 ft. 10 ft. 15 ft. 18 ft. MLFS22402 MLFS22404 6500 5000 42000 2400 18 ft. MLFS22405 MLFS22406 MLFS22403 4/10 6000 4500 3300 15 ft. PRE-INSTALLATION APPLICATION •... -
Page 4: Installation
INSTALLATION 1. Set the pump on a solid, level surface in the bottom of the sump pit. If necessary, use bricks / blocks to provide a solid base. Avoid placing the pump on loose gravel, earth or sand. 2. Install discharge plumbing according to state and local codes. It is highly recommended that rigid PVC is used for the discharge line. -
Page 5: Troubleshooting
TROUBLESHOOTING CAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION WARNING WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR INJURY OR PROPERTY DAMAGE. PROBLEM POTENTIAL CAUSE POSSIBLE SOLUTION Pump Will Not Run 1. Blown fuse, tripped breaker or 1. Check all electrical connections. tripped GFCI Check for blown fuses, tripped GFCI 2. -
Page 6: Terms And Conditions Of Sale
TERMS AND CONDITIONS OF SALE Orders for this product are expressly made conditional on buyer’s assent to company’s terms and conditions of sale, which can be found by scanning the QR code below, or are available upon request by mail. Any terms and conditions in any of buyer’s documents that are inconsistent with or add to seller’s terms and conditions of sale are hereby rejected and are not binding upon company. - Page 7 NOTES __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ Mainlinecollection.com FloodStop® PumpTech Support: 1-833-786-7779...
- Page 8 Fax: 901-853-5008 www.ipscorp.com Warranty See warranty information for more details. All dimensions listed are nominal. MAINLINE ® reserves the right to make product and material changes at any time without notice. 83613-01 Contact your sales representative for more information or visit our website at mainlinecollection.com...
- Page 9 Corporation’s (<IPS Corp.=) warrants product’s Product’s product’s product’s (<IPS Corp.=) <life system=*...
- Page 10 Corporations’ Truebro’s...
