- Page 1 79618 4-IN-1 MULTI-FUNCTION PETROL GARDEN TOOL 32.6cc INSTRUCTION MANUAL SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Specifications
SPECIFICATIONS INTRODUCTION Thank you for your purchasing the brush cutter of our company. The present manual explains how to handle the brush cutter well. Before using it, please read this operator's manual carefully, operate the machine correctly and engage in your task with safely.By the way, due to changes of specifications, all details of your machine may not agree with this manual. -
Page 3: Graphic Warnings
SAFETY GRAPHIC WARNINGS Because a trimmer/cutter is a high-speed, fast cutting power tool, special safety precaution must be observed to reduce the risk of personal injury.Read this manual carefully. Be familiar with the controls and the proper use of the unit. Know how to shut it off, and how to unhook a harnessed unit quickly. -
Page 4: Safety Rules & Precautions
SAFETY SAFETY RULES & PRECAUTIONS Proper safety precautions must be observed. Like all power equipment.this unit must be handled carefully. DO NOT EXPOSE YOURSELF OR OTHERS TO DANGER. Follow these general rules. Do not permit others to use this machine unless they are thoroughly responsible and have read, and understand the machine manual and are trained in its operation. - Page 5 SAFETY • Clean the machine completely, especially, the fuel tank, its surroundings, and the air cleaner. • When refueling, be sure to stop the engine and contirm that it is cooled down.. Never refuel when the engine is running or hot. When gasoline spills, be sure to wipe it up completely dispose of those materials before starting the engine.
- Page 6 SAFETY Befor Operation Checks WARNING! For your safety, and to maximize the service life of your equipment, it is very important to take a few moments before you operate the engine to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it. Before beginning your pre-operation checks, be sure the engine stop switch is in the OFF position.
-
Page 7: Operation
SETUP OPERATION Using SET UP THE EQUIPMENT - JOINT ATTACHMENT Assemble the poles with coupler. INSTALLING HANDLE 1. insert the barrier handle to the top handle 2. Fasten the 4 internal hexagonal screws with spanner. Engine Starting And Stopping Procedures STARTING COLD ENGINE Move the stop switch to "START"... -
Page 8: Fuel & Oil Mixture
SETUP FUEL & OIL MIXTURE •Never fill the fuel tank to the very top •Never add fuel to the tank in a closed non-ventilated area •Do not add fuel to this until close to an open fire or sparks •Be sure to wipe off spiled fuel before attermptng tostart engine •Do not attempt to refuel a hot engine Fuel used for this model is a mixture of unleaded gasoline and approved engine lubricant. -
Page 9: Preparing For Operations
SETUP PREPARING FOR OPERATIONS IMPORTANT: Failure to follow proper fuel mix instructions may cause damage to the engine. 1. one month mixture, mix only the amount needed for the job you are to do. Do not use fuel that has been stored longer than two months. -
Page 10: Maintenance And Care
MAINTENANCE MAINTENANCE & CARE AIR FILTER • Accumulated dust in the air filter will reduce engine efficiency. Increase fuel consumption and allow abrasive particles to pass into the engine. Remove the air filter as o en as necessary to maintain in a clean condition. - Page 11 TROUBLESHOOTING TROUBLE SHOOTING • Clean or replace the plug if fouled with heavy oily depcsits. • Replace the plug if the center electrode is wom rounded at the end. • Spark gap 0.6-0.7mm (.023".028") • Fastening torque = 145-155kg. cm (125-135in.lb) WARNING: Always cover the metal blade with the transportation guard while transportation and storage.
-
Page 12: Troubleshooting
TROUBLESHOOTING FAILURE TO START symptom probable cause remedy cylinder spark fuel these is no fuel in tank Add fuel in tank Clean plug system fuel filter obstruct fuel filter compress pressure spark abnormality normal normal fuel is too dirtythere is instead fuel instead fuel fuel... -
Page 13: Low Output
TROUBLESHOOTING LOW OUTPUT symptom probable cause remedy flameout when speedup fuel filter obstruct, clean fuel filter clean fue the smoke is thin, carburetor fall short of fuel lroad,adjust carburetor clean spout backward muffler fouled with oily the oily deposits deposits compress press is shortage piston, piston ring cylinder replace piston、... - Page 14 SETUP GRASS TRIMMER OR BRUSH CUTTER SET UP Fit the metal shield to the gear box housing.Using three screws and secure to box housing.Fit the lining to the gear box housing.Secure metal blade between upper and lower plate with nut. Make sure that cotter pin is installed.
- Page 15 SETUP Hold the device with the right hand at the rear handle and with the le hand at the front handle. Try to hold the device at a comfortable level at your hip and always use both hands. Always make sure you maintain a steady firm, stance to maintain balance at all times.
- Page 16 SETUP OPERATION OF POLE HEDGE TRIMMER WARNING! This product is equipped with extremely sharp blades, and when used improperly these blades can be extremely dangerous. Improper handling can cause accidents, which may lead to serious injury or death. For this reason, you should always be careful to follow the following instructions when using your trimmer.
- Page 17 MAINTENANCE MAINTENANCE OF POLE HEDGE TRIMMER TRANSMISSION The reduction gears are lubricated by multipurpose grease in the transmission. Grease should be added every 25 hours of use or more o en depending on the job condition. When adding lubricant, use a grease gun to insert lubricant into the three grease nipples located on the transmission. HEDGE TRIMMER BLADE: •When refilling the tank or resting, it is o en a good idea to use the time to oil the cutting blades.
- Page 18 SETUP INSTALLING THE GUIDE BAR AND SAW CHAIN Chain Tension Set Up The saw chain has very sharp edges. Use protective gloves for safety. Always pay attention to the chain tension. A slackened chain will increase the risk of backlash. If slackened, the chain could spring out of the guide, could cause injury to the operator and as well as damage to the unit.
- Page 19 SETUP Operation Of Pole Saw WARNING 1.Always wear work gloves made of leather or some other sturdy material when using the pole saw. 2.Falling branches may fall onto the face or into the eyes, resulting in injuries, scratches, and cuts, and for this reason you should always be sure to wear a helmet and face protector when using your pole saw.
- Page 20 SETUP OPERATION 1. Always be sure to turn off the engine before changing the angle of the blades, removing branches which have become stuck in the blades, or at any other time when coming into close proximity with the blades. 2.
- Page 21 SETUP SAW CHAIN WARNING! It is very important for smooth and safe operation to keep the cutters always sharp. Your cutters need to be sharpened when: 1. Sawdust becomes powder-like. 2. You need extra force to saw in. 3. The cut way does not go straight. 4 .Vibration increases.
-
Page 22: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79618 4-IN-1 MULTI-FUNCTION PETROL GARDEN TOOL Complies with the essential health and safety requirements of the following Directices: EC Council Directive 2006/42/EC Machinery Standards and technical specifications referred to:... - Page 23 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld MADE IN CHINA...
