LI-ION CORDLESS BRUSH CUTTER

AND GRASS TRIMMER

INSTRUCTION MANUAL

SAVE THIS MANUAL !

You will need this manual for safety instructions, operating procedures and warranty.

Put it and the original sales receipt in a safe dry place for future reference.

20V

LITHIUM-ION

Table of Contents

Need help?

Do you have a question about the MP20V 87376 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOLSEN TOOLS MP20V 87376

Page 1 87376 LI-ION CORDLESS BRUSH CUTTER AND GRASS TRIMMER INSTRUCTION MANUAL LITHIUM-ION LITHIUM-ION SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/or serious injury. WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 3: Personal Safety
SAFETY Personal safety 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Page 4 SAFETY Battery Tool Use and Care 1. Recharge only with the charger speciﬁed by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of ﬁre when used with another battery pack. 2. Use power tools only with speciﬁcally designated battery packs. Use of any other battery packs may create a risk of injury and ﬁre.
Page 5: Battery Charger Safety
SAFETY Battery Safety WARNING This battery can only be used in the machines included in the TOLSEN MP20V lithium-ion power platform system. This battery can only be used cooperatively with the designated battery charger. Li-lon batteries, if incorrectly used, stored or charged will cause a ﬁre, burn and explosion hazard. Failure to follow these instructions may cause overheating or ﬁre.
Page 6 SAFETY Note: Symbology CE conformity Read the instruction manual before using Wear hearing protection while operating the tool Wear hand protection Always use breathing apparatus when machining materials which generate dust. Wear ear protection. Operating environmental temperature Max 45 º Do not incinerate battery pack Do not expose to water Keep all bystanders at least 50 feet away.
Page 7: Specifications
SPECIFICATIONS SPECIFICATIONS Rated voltage 40VDC(2x20V) Output power 450W No-load speed : 4000 / 5000/min Cutting capacity for grass(diameter) 16"(400mm) Cutting capacity for brush(diameter) 10"(255mm) Trimmer line Ø2.0mm Net weight 5.2kg(11.4lbs)
Page 8 FUNCTIONS FUNCTIONS Safety lock button Switch button Aluminum tube (top) Aluminum tube (bottom) Handle Guard cover Cutting head assembly Cut-oﬀ knife...
Page 9 SETUP INSTALLING SHIELD & BLADE Fit the metal shield to the gear box housing.Using three screws and secure to box housing.Fit the lining to the gear box housing.Secure metal blade between upper and lower plate with nut. Make sure that cotter pin is installed.
Page 10: Rules For Safe Operation
SETUP RULES FOR SAFE OPERATION WARNING DANGER All models trimmers and brush cutters can throw small stone, metal or small objects as well as the material being cut. Read these "Rules for Safe Operation" with care.Follow the instrictions in your operator's manual. Read the operator's manual caretully.
Page 11: Cutting With A Nylon Head
SETUP CUTTING WITH A NYLON HEAD WARNING DANGER The proper debris shield must be in place on the unit when nylon cutting line is used, The cutting line can ﬂap around if too much line is exposed.Always use the plastic debris shield with cut-oﬀ knife when using nylon cutting heads.
Page 12 SETUP DEBRIS TRIMMING: This is feeding the trimmer carefully into TRIMMING DEBRIS the material you wish to cut. Tilt the head slowly to direct debris away from you. If cutting up to a barrier KNIFE SIDE RAISED such as fence, wall or tree, approach from an angle where any debris ricocheting oﬀ...
Page 13: Cutting With A Blade
SETUP CUTTING WITH A BLADE CUTTING WITH A BLADE 3-tooth metal blade and 8-tooth metal blade are provided with the machine Use of saw blade with this machine is prohibited. WARNING DANGER WARNING DANGER DO NOT USE A BRUSH CUTTER FOR CUTTING TREES. Do not cut with dull, cracked or damaged metal blade.
Page 14: Maintenance
MAINTENANCE MAINTENANCE CAUTION: Do not let brake ﬂuids, gasoline, petroleum-based materials touch the plastic parts. Chemicals can cause damage to the plastic, and make the plastic unserviceable. CAUTION: Do not use strong solvents or detergents on the plastic housing or components. WARNING Remove the battery pack from the machine before maintenance.
Page 15: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING problem possible causes Likely Solutions Tool will not 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no start. obstructions, clean battery contacts on tool, connected. reinsert the Battery Pack according to its shape 2.
Page 16: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 87376 LI-ION CORDLESS BRUSH CUTTER AND GRASS TRIMMER Complies with the essential health and safety requirements of the following Directices: council directive 2006/42/EC Standards and technical speciﬁcations referred to:...
