Backyard YardLine BERKDALE GABLE Manual

8' x 14' (244 x 426,7 cm)
Hide thumbs

Advertisement

Table of Contents

A Backyard Products Company
BERKDALE GABLE 8' x 14' (244 x 426,7 cm)
ACTUAL FLOOR SIZE IS 96" x 168" (243,8 x 426,7 cm)
READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
• BUILDING RESTRICTIONS AND APPROVALS
Be sure to check local building department and homeowners association for specific restrictions and/ or requirements before building.
• ENGINEERED DRAWINGS
Contact our Customer Service Team if engineered drawings are needed to pull local permits.
• SURFACE PREPARATION
To ensure proper assembly you must build your shed on a level surface.
Recommended methods and materials to level your shed are listed on page 10.
• CHECK ALL PARTS
Inventory all parts listed on pages 3-7.
• ADDITIONAL MATERIALS
You will need additional materials to complete your shed. See page 8 for required and optional materials and quantities.
***CONTACT OUR CUSTOMER SERVICE TEAM
IF ANY PARTS ARE MISSING OR DAMAGED***
Call: 1-734-242-6900 email: customerservice@backyardproducts.com
KEEP THIS MANUAL FOR FUTURE REFERENCE
STANDARD WALL LAYOUT:
WINDOWS LOCATED ON
RIGHT GABLE WALL
I M PO RTANT!
BEFORE YOU BEGIN
- Order form and warranty at back of manual -
OPTIONAL WALL LAYOUT:
WINDOWS LOCATED ON LEFT
GABLE WALL
16769-A
09/12/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YardLine BERKDALE GABLE and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard YardLine BERKDALE GABLE

Summary of Contents for Backyard YardLine BERKDALE GABLE

  • Page 1 16769-A 09/12/2024 A Backyard Products Company BERKDALE GABLE 8' x 14' (244 x 426,7 cm) ACTUAL FLOOR SIZE IS 96" x 168" (243,8 x 426,7 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE STANDARD WALL LAYOUT: OPTIONAL WALL LAYOUT: WINDOWS LOCATED ON...
  • Page 2 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver Caulk Gun 1/8" Drill Bit Tin Snips 1/4" Drill Bit (for drip edge) 5/16" Drill Bit Paint Tools 1/2" Drill Bit Chalk Line #2 Philips Drive Bit Safety Glasses Hammer Clamps...

  • Page 3: Parts List

    PARTS IDENTIFICATION AND SIZES WOOD SIZE CONVERSION CHART Part identification letters are stamped on some parts. Treated lumber is stamped: Nominal Board Size Actual Size 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 4 TRIM Left 3/8 x 4-3/4 x 64" (1 x 12,1 x 162,6 cm) Right 3/8 x 4-3/4 x 64" (1 x 12,1 x 162,6 cm) 2 x 4 x 64" (5,1 x 10,2 x 162,6 cm) 3/8 x 4-3/4 x 64-5/8" (1 x 12,1 x 138,7 cm) Left Right 3/8 x 4-3/4 x 64-5/8"...
  • Page 5 WALL PANELS & DOORS NOTE: Panel parts are not stamped. 3/8 x 11-7/8 x 35-3/4" (1 x 30,2 x 90,8 cm) 3/8 x 3-3/4 x 72" 3/8 x 48 x 84" 3/8 x 23-7/8 x 84" (1 x 9,5 x 182,9 cm) (1 x 121,9 x 213,4 cm) (1 x 60,6 x 213,4 cm) Painted...
  • Page 6 FLOOR PARTS Floor panels are 5/8" (1,6 cm) thick. NOTE: Panel parts are not stamped. 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) Look for TREATED Stamp 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) 2 x 4 x 96"...
  • Page 7 FASTENER/HARDWARE BAG x140 1-1/2" (3,8 cm) x235 2" (5,1 cm) x120 3" (7,6 cm) 2" (5,0 cm) 1-5/8" (4,1 cm) NOTE: If you are using a nail gun, nails 3/4" (1,9 cm) may be used where screws are shown for quicker assembly. Length of nail must match screw length.
  • Page 8 ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed does not include any leveling materials. • See the FLOOR LEVELING section on page 10 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. •...
  • Page 9 COMPONENT SECTION INDEX Description Section Page Floor 12-15 Walls Rafters 17-18, 44 Gable Units 36-39, 45 Roof Panels Soffit & Fascia Trim 50-55 Doors Corner Trim Collar Ties Loft & Shelves Windows Shingles...
  • Page 10 OPTIONAL WOOD FRAME FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS (Typical for 8' x 14' Kit) Runners are generally 12"...
  • Page 11 CONCRETE FOUNDATION Your kit contains all materials to construct a wooden floor. If you choose to install your kit on a concrete slab, refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4"...

  • Page 12: Parts Required

    FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) Look for 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) TREATED Stamp 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) BEGIN Arrange parts on fl at surface.
  • Page 13 LEVEL AND SQUARE FLOOR FRAME Before installing fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 10 for the preferred fl oor leveling method. Using a level, ensure that the frame is level before installing fl oor panels.
  • Page 14 FLOOR PANELS PARTS REQUIRED: x233 2" (5,1 cm) 5/8 x 48 x 96" (1,6 x 121,9 x 243,8 cm) Install all floor panels with the rough side facing up (painted grid-lines). Ensure your floor frame is square by installing one panel and squaring frame. BEGIN (2) Nails Attach the 48 x 96"...
  • Page 15 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 5/8" x 23-7/8" x 96" (1,6 x 60,6 x 243,8 cm) 5/8" x 48" x 96" (1,6 x 121,9 x 243,8 cm) Continue installing panels, as shown. Use a chalk line or the pre-painted grid lines on panels during nailing. Secure panels with 2"...
  • Page 16 IMPORTANT! Ensure that the floor frame is level after installing floor panels. Re-level if needed. • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process HINT: to avoid over-handling of the walls. GABLE WALL BACK WALL FRONT WALL...

  • Page 17: Rafter Assembly

    RAFTER ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 8" (5,1 x 10,2 x 20,3 cm) Build a rafter jig using the fl oor and (3) parts COA, as shown. ¸ BEGIN Secure one COA fl ush to the fl oor deck using two 3" screws. Measure over 96-3/4"...
  • Page 18 RAFTER ASSEMBLY PARTS REQUIRED: x 152 x 16 2" (5,1 cm) 1-5/8" (4,1 cm) OSB OR WOOD GRAIN 6 x 24" (15,2 x 61 cm) 2 x 4 x 63-3/4" (5,1 x 10,2 x 161,9 cm) Build 8 rafters - Six with 2 gussets and Two with only 1 gusset. ¸...
  • Page 19 WALL INDEX Create your own style of shed. Choose your door location. Use this guide to find the corresponding wall construction and installation pages. IMPORTANT! Build your door header before building any walls (see next page). After assembling the walls for your 14' x 8' shed, go to page 32 for wall installation. Windows on Right Gable Wall Gable Wall 01...
  • Page 20 WALL PANEL INSTALLATION HINTS & EXAMPLES PARTS REQUIRED: 2" (5,1 cm) TEMP. SPACER 3/4" GAUGE BLOCK 3/8 x 48 x 84" (1 x 121,9 x 213,4 cm ) Ensure your wall is square by installing one panel and squaring frame. Install all wall panels with the primed side facing up.
  • Page 21 DOOR FRAME UNIT Assemble the door frame unit unit before building any walls! PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 67" (5,1 x 10,2 x 170,2 cm) 7/16 x 3-1/4 x 66-3/4" (1,1 x 8,3 x 170,2 cm) BEGIN Place (1) AM and OSB end-to-end on flat surface, flush in middle.
  • Page 22 DOOR FRAME UNIT PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 8" (5,1 x 10,2 x 20,3 cm) 3" (7,6 cm) Assembled Header 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) Arrange parts on edge on fl oor, Flush ASSEMBLED HEADER...
  • Page 23 WINDOW FRAME UNITS Assemble 3 window frame units before building any walls! PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) Build (3) window frame units (Fig.A). BEGIN Arrange parts on edge on fl oor.

  • Page 24: Front Wall

    FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 8-3/4" (5,1 x 10,2 x 22,2 cm) 2 x 4 x 52" (5,1 x 10,2 x 132,1 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) Window Frame Door Frame 2 x 4 x 80"...
  • Page 25 FRONT WALL PARTS REQUIRED: 3/4" GAUGE 3" (7,6 cm) BLOCK x218 2" (5,1 cm) Temporary Brace 3/8 x 3-3/4 x 72" 3/8 x 11-7/8 x 35-3/4" 69" (75,3 cm) Door Stiffener (1 x 60,6 x 213,4 cm) (1 x 30,2 x 121,9 cm) Install (2) 11-7/8"...
  • Page 26 GABLE WALL 01 PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 80" (5 x 10,2 x 203,2 cm) 2 x 4 x 89" (5 x 10,2 x 226,1 cm) Temporary support Temporary support 19/32 x 2-1/2 x 9" 2 x 3 x 21-3/4" (5,1 x 7,6 x 55,2 cm) (1,5 x 6,3 x 22,8 cm) BEGIN Arrange parts on floor.
  • Page 27 GABLE WALL 01 PARTS REQUIRED: 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm) 1-1/2" (3,8 cm) Flush 3/4" BEGIN HERE (4,4 cm) Install 48" x 84" panel on frame fl ush at top and with a 1-3/4" gap along TK. Maintain 1-3/4"...
  • Page 28 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) HINT: BEGIN For easier nailing...
  • Page 29 BACK WALL PARTS REQUIRED: x186 2" (5,1 cm) 3/4" GAUGE BLOCK 23-7/8 x 84" 48 x 84" (60,6 x 213,4 cm) (121,9 x 213,4 cm ) 3/4" BEGIN HERE (1,9 cm) Install (1) 48" x 84" panel fl ush to the top plate. 6"...
  • Page 30 GABLE WALL 02 PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) Window Frame 2 x 4 x 89" (5 x 10,2 x 226,1 cm) Unit BEGIN Arrange parts on edge on floor. Measure and mark. HINT: For easier nailing Secure with (2) 3"...
  • Page 31 GABLE WALL 02 PARTS REQUIRED: x108 2" (5,1 cm) 3/4" GAUGE BLOCK 23-7/8 x 84" (60,6 x 213,4 cm) Flush 3/4" BEGIN HERE (1,9 cm) Install window cutout panel fl ush to the top plate. Use GAA for consistent 3/4" measurement. 6"...
  • Page 32 FRONT WALL PARTS REQUIRED 3" (7,6 cm) Temporary Support 69" Door Stiffener (175,3 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center front wall on the 168" fl oor measurement. Use OO as a temporary brace. Secure with (2) 3" screws. 3"...
  • Page 33 GABLE WALL 01 or 02 PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) 2" (5,1 cm) 2" (5,1 cm) 3" (7,6 cm) 2" (3,8 cm) BEGIN Screw Flush Flush Stand gable wall on fl oor. Secure top of wall to front Fig.
  • Page 34 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) Fig. B BEGIN Install back wall centered on fl oor. The 1" overhang is to the bottom. 2" (5,1 cm) Screw Secure with (2) 3"...
  • Page 35 GABLE WALL 02 or 01 PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) Fig. B BEGIN 2" (5,1 cm) Screw Remove temporary support. Place gable door wall on fl oor centered between front and back walls.
  • Page 36 GABLE UNIT 01 PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 26" (5,1 x 10,2 x 66 cm) Install panels with primed side facing up. BEGIN Arrange 2x4 parts on flat edges, as shown. Place left gable panel over 2x4 parts. Secure with 1-1/2" nails. 1-1/2"...
  • Page 37 GABLE UNIT 02 PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 14-1/2" (5,1 x 10,2 x 36,8 cm) 2 x 3 x 21-3/4" (5,1 x 7,6 x 55,2 cm) Install panels with primed side facing up. Arrange 2x4 parts on fl at edges, as shown. Place left gable panel over 2x4 parts.
  • Page 38 GABLE UNIT 01 - INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Assembled 2" (5,1 cm) Install gable unit 01 on the gable wall without a window. BEGIN Measure 2-9/16" down from top plate (SZ) and mark at each side (Fig. A). Set gable unit on top plate.
  • Page 39 GABLE UNIT 02 INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Assembled Install gable unit 02 on the side of shed with a window. Measure 2-9/16" down from top plate (SZ) and mark at each side (Fig. A). Set gable unit on top plate. Secure with (1) 2" nail on each side. CENTER GABLE UNIT ON WALL BEFORE NAILING.
  • Page 40 LOFT PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) 3" (7,6 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) Install loft on the gable wall without a window. BEGIN Measure and mark gable wall corner studs 3/4"...
  • Page 41 LOFT PARTS REQUIRED: 2" (5,1 cm) 7/16 x 26-5/8 x 88-3/4" (1,1 x 67,6 x 225,4 cm) Install 26-5/8" x 88-3/4" loft panel centered on loft supports. Slide panel into gap under gable walltop plate (Fig. A). Secure to loft frame with 2" nails evenly spaced. Fig.
  • Page 42 SHELVES PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 21-3/4" (5,1 x 7,6 x 55,2 cm) 3" (7,6 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) Install shelves below the loft. BEGIN Measure and mark locations for top of (2) loft support boards AED (Fig. A, Fig. B). Install (2) AED between back wall studs with narrow side to wall panel (Fig.
  • Page 43 SHELVES PARTS REQUIRED: 3" (7,6 cm) 2" (5 cm) 7/16 x 10-1/2 x 88-3/4" (1,1 x 26,7 x 225,4 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) Measure and mark both AED's at the measurements shown from back wall end stud. Mark front wall window stud at the two measurements shown.
  • Page 44 RAFTERS PARTS REQUIRED: 3" (7,6 cm) Assembled Rafter Assembled Rafter with 2 gussets with 1 gusset ¸ BEGIN Locate fi rst 2 gusset rafter on top plate, aligned over studs at each side and fl ush to gable wall panel (Fig.
  • Page 45 GABLE UNITS (continued) and RAFTER SPACERS PARTS REQUIRED: 2" (5,1 cm) 3/8 x 3-1/4 x 4-3/4" (1,0 x 8,3 x 12,1 cm) BEGIN Secure top of gable panels to rafter with 2" nails spaced 6" apart. 2" (5,1 cm) Nails 3-1/4"...
  • Page 46 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 7/16 x 48 x 96" (1,1 x 121,9 x 243,8 cm) Install all roof panels with the rough side (painted grid lines) facing up. Roof panels may cause serious injury until securely fastened. BEGIN Install (1) 48"...
  • Page 47 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 7/16 x 47-7/8 x 48" 7/16 x 15-3/4 x 23-7/8" (1,1 x 121,6 x 121,9 cm) (1,1 x 40,0 x 60,6 cm) Install (1) 47-7/8" x 48" panel flush to installed panel, with a 3/4" measurement on the rafter (Fig.
  • Page 48 ROOF PANELS PARTS REQUIRED: 7/16 x 15-3/4 x 48" (1,1 x 40,0 x 121,9 cm) 2" (5,1 cm) 7/16 x 23-7/8 x 48" 7/16 x 15-3/4 x 96" (1,1 x 60,6 x 121,9 cm) (1,1 x 40,0 x 243,8 cm) 3/4"...
  • Page 49 ROOF PANELS PARTS REQUIRED: x172 2" (5,1 cm) Secure the roof panels with 2" nails spaced 6" apart on edges and 12" apart inside panel. 6" (15,2 cm) Repeat all steps to install roof panels on the opposite side. FINISH Your roof panels are now installed.
  • Page 50 GABLE TRIM PARTS REQUIRED: 1-1/2" (3,8 cm) LEFT 3/8 x 4-3/4 x 64" (1 x 12,1 x 162,6 cm) RIGHT 2 x 4 x 64" (5,1 x 10,2 x 162,6 cm) 3/8 x 4-3/4 x 64" (1 x 12,1 x 162,6 cm) Build two left and two right gable trim units.
  • Page 51 GABLE TRIM PARTS REQUIRED: 3" (7,6 cm) RIGHT gable trim unit LEFT gable trim unit BEGIN Install right gable trim unit fl ush to gable panel center seam and fl ush with roof panels (Fig. A, Fig. B). Secure with 3" screws into end rafter. Space the screws evenly (approximately 24" (61 cm). Flush Fig.
  • Page 52 GABLE TRIM PARTS REQUIRED: 2" (5,1 cm) Right 3/8 x 4-3/4 x 64-5/8" (1 x 12,1 x 138,7 cm) Left 3/8 x 4-3/4 x 64-5/8" (1 x 12,1 x 138,7 cm) BEGIN Install the right 4-3/4" x 64-5/8" fascia fl ush to trim seam and fl ush with roof panels (Fig. A, Fig. B). Secure with 2"...
  • Page 53 EAVE SIDE SOFFITS PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm) 2" (5,1 cm) 3/8 x 4-3/4 x 73-1/2" (1 x 12,4 x 186,7 cm) 3/32" (2,4 mm) Drill Bit 3/8 x 4-3/4 x 96" (1 x 12,4 x 243,8 cm) Ensure soffit boards are flush at rafter ends and flush at seam.
  • Page 54 EAVE SIDE SOFFITS PARTS REQUIRED: Install all trim with the primed side facing down. Install 96" soffi t board fl ush to gable trim unit and rafter ends (Fig. B). Secure with 2" fi nishing nails, two in each rafter and two into edge of nailer AO. Install 73-1/2"...
  • Page 55 EAVE SIDE FASCIA PARTS REQUIRED: 2" (5,1 cm) 3/8 x 4-3/4 x 77-1/4" (1 x 12,1 x 196,2 cm) 3/8 x 4-3/4 x 96" (1 x 12,1 x 243,8 cm) Install all trim with the primed side facing out. BEGIN Install 77-1/4"...
  • Page 56 DOUBLE DOORS - GABLE WALL PARTS REQUIRED: IMPORTANT! 3" (7,6 cm) USE DOORS WITH HINGE BOARD ENDS PAINTED GREEN AND RED 1-5/8" (4,1 cm) HINT: x1 GAA Look for 3/8" SPACER 1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) attached to doors.
  • Page 57 DOUBLE DOORS - GABLE WALL PARTS REQUIRED: 3" (7,6 cm) TEMPORARY SUPPORT 69" (175,3 cm) Door Stiffener Install OO fl ush under panels. Secure OO to fl oor frame with (2) 3" screws (Fig. A). Mark center of door opening. Fig.
  • Page 58 DOUBLE DOORS - GABLE WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" (1,9 cm) 19/32" x 2-1/2" x 26 5/8" (1,5 x 6,3 x 67,6 cm) BEGIN Secure door trim from inside with 3/4" screws (Fig. A). Secure two horizontal door rails AH with (4) 3/4" screws from behind to center of doors. 3/4"...
  • Page 59 DOUBLE DOOR STIFFENERS - GABLE WALL PARTS REQUIRED: 2" (5,1 cm) 69" Door Stiffener (175,3 cm) BEGIN Center OO vertically on the left door in the door opening fl ush with the edge of door (Fig. A). Secure with (6) 2" screws through outside trim into OO (Fig. B) Repeat to install OO on right door.
  • Page 60 DOUBLE DOOR HARDWARE PARTS REQUIRED: Extender 1/4" (0,6 cm) 4" Shaft 1/2" (1,3 cm) Drill Bits 1-1/2" (3,8 cm) BEGIN Measure and mark location of hole on outside of right door as shown (Fig. A). Pre-drill pilot hole with 1/4" dril. Pre-drill through hole with 1/2"...

  • Page 61: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 1" (2,5 cm) 5/16" (0,8 cm) Drill Bit BEGIN Place spring bolt onto OO in open position with bolt end 3/8" down from frame. Bolt is open when loop is contacting base (Fig A). Mark and pre-drill holes for screws. Install bolt with screws supplied and drill 5/16"...
  • Page 62 DOOR - DECORATIVE HINGES PARTS REQUIRED: 1" (2,5 cm) BEGIN Install decorative hinges on horizontal trim and fl ush against hinge, as shown. 1" (2,5 cm) Screws Flush FINISH Your decorative door hinges are now installed.
  • Page 63 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8 x 1-3/4 x 81-1/2" (1 x 4,4 x 207 cm) BEGIN Install (1) 81-1/2" trim board fl ush under soffi t panel and against eave wall (Fig. A, Fig. B). Secure with (1) 2" fi nish nail at the top. Install next 81-1/2"...
  • Page 64 COLLAR TIE INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 1 x 4 x 60" (2,5 x 10,2 x 152,4 cm) BEGIN Install collar ties to the rafters with (3) 3" nails at each end (Fig. A). Install fi rst collar tie on the 2nd and 4th rafters from the gable door wall. Fig.
  • Page 65 LARGE WINDOWS PARTS REQUIRED: Window 1-5/8" (4,1 cm) 22-1/4 x 29-3/4" (56,5 x 75,6 cm) BEGIN Seal windows with high-quality exterior-grade caulk before installing (Fig. A). Center and secure windows with 1-5/8" screws. Ensure window is level. CENTER CENTER Fig. A Fig.
  • Page 66 WINDOW TRIM PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 28-1/2" (1,5 x 6,3 x 72,4 cm) 19/32 x 2-1/2 x 30-1/8" (1,5 x 6,3 x 76,5 cm) CENTER OF Place the inside edge of AZ 11-1/2" apart WINDOW Fig.
  • Page 67 GABLE WINDOW and WINDOW TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32 x 2-1/2 x 9" (1,5 x 6,3 x 22,9 cm) 3/4" (1,9 cm) 19/32 x 3-1/2 x 32-3/4" (1,5 x 8,9 x 83,2 cm) Before installing window, caulk areound back side of frame with high quality exterior-grade caulk. You must caulk completely around window BEGIN frame and all exposed door panel edges and...
  • Page 68 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 69 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 70 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 71 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 72 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles into THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 73 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off fl ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
  • Page 74 16769-A 8' x14' Order Form CATEGORY PART DESCRIPTION PART SIZE PART ITEM # BUILDING QTY. PART ID Loft Ledger / Shelf Support LUM SPF 2X3X96 #2&BTR 12115 2 X 3 Shelf Supports / Gable Connector "B" 2 X 3 X 21 3/4" Q 21120000000 Rafter 2 X 4 X 63-3/4"...
  • Page 75 Storage Buildings To validate your warranty, it is necessary to properly maintain your Backyard Storage Solutions, LLC unit; shingle the roof and paint or solid-colored stain the siding using quality, 100% acrylic latex exterior product with a minimum of two (2) coats within thirty (30) days of assembly;...
