North Light WX-31VLED44-200WW-10-1 Instruction Manual

Icicle String Light,
extendable
Art.no 36-6686 Model WX-31VLED44-200WW-10-1 (warm white)
36-6684 WX-31VLED44-100WW-10-1 (warm white)
36-7642 WX-31VLED44-200WW-10-1 (cool white)
36-7641 WX-31VLED44-100WW-10-1 (cool white)
Please read the entire instruction manual before use and then
save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical
data. In the event of technical problems or other queries, please
contact our Customer Services.
Safety
Warning:
• Neither the product nor its mains adapter may be dismantled
or modified in any way.
• Never use the product or the mains adapter if it is in any way
damaged or malfunctioning.
• The product must only be connected to the included mains
adapter.
• The mains lead must never be replaced. The product must
be discarded if the mains lead is damaged in any way.
• The extension 36-6684/36-7641 must only be connected to
Icicle String Light, extendable 36-6686/36-7642.
Important
• For indoor and outdoor use.
• The light bulbs cannot be replaced.
Class II mains adapter.
Class III string light.
Care and maintenance
• Unplug the mains adapter from the wall socket before wiping
the string light clean with a cloth.
• Store the string light in a dry, dust-free environment out of
children's reach whenever it is not to be used for a long time.
Connection
1. Connect the string light to the power adapter (it only fits one
way) and tighten the connection by screwing on the lock nut.
2. Unwind the string light completely and plug its power adapter
into a wall socket.
3. Make sure that cap covering the socket on
the end of the string light is screwed on if no
additional string lights are to be connected.
Connect more string lights
Note:
• Up to a maximum of 5 string light extensions can be
connected, art.no 36-6686/36-7642. Max 700 LEDs in total.
• The extendable string light has a string light extension socket
at one end.
1. Remove the screw cap covering
the socket.
2. Connect an extension string light
and secure the connection with
the lock nut.
3. Make sure that cap covering
the socket on the end of the string light
is screwed on if no additional string
lights are to be connected.
Responsible disposal
This symbol indicates that this product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards
caused by incorrect waste disposal, the product
must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
the product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
36-6686/36-7642
IP rating IP44
Light bulb LED × 200, 0.021 W
String light Length 5 m
Connection cable 5 m
Input: 220-240 VAC,
50/60 Hz, 100 mA
Output: 31 VDC,
242 mA, max 7.5W
36-6684/36-7241
IP rating IP44
Light bulb LED × 100, 0.021 W
String light Length 2.5 m
English
