Artusi AINT7600 Series Installation & Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APPLIANCES
FOR LIVING
AINT7600**
INSTALLATION &
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AINT7600 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Artusi AINT7600 Series

Summary of Contents for Artusi AINT7600 Series

  • Page 1 APPLIANCES FOR LIVING AINT7600** INSTALLATION & OPERATION MANUAL...
  • Page 2 ARTUSI Family. This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
  • Page 3 AINT7600** INSTALLATION GUIDE...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Symbols and Their Meanings ............................4 Installation Place................................7 Tool list....................................10 ALTERNATIVES FOR INSTALLATION ..........................11 PREPARATION FOR INSTALLATION ..........................12 Cabin Dimensions ................................12 Location of the Electrical Wiring.............................13 Location of the Water System ............................14 Production dimension …… ............................16 Unpacking ..................................23 Removing Connectors on the rear Wall .........................25 Removing Mounting Parts in the Freezer Compartment ....................26...
  • Page 5 FURNITURE DOOR PREPARATION............................52 Removing the Mechanism Covers ..........................52 Removing the Panel-Adjustment Mechanisms on the Refrigerator ................53 Preparing Furniture Door..............................54 Preparing the Furniture Door ............................55 Preparing the freezer Furniture Door..........................57 Installing the Fridge Furniture Door ..........................59 Installing the Freezing Furniture Door..........................65 HINGE ADJUSTMENT................................71 Adjusting the hardness of the hinges ..........................

  • Page 6: Symbols And Their Meanings

    Symbols and Their Meanings Symbols used in the installation manual are as follows. Important information or useful usage tips WARNING: Conditions that may damage the product or its operating functions ATTENTION: Conditions containing serious injury risk Conditions containing electric shock risk Packaging materials of the product have been manufactured from recyclable materials in accordance with our National Environment Regulations.
  • Page 7 • Minimum clearances between product parts and surrounding structures must be suitable. • Minimum dimensions and proper organisation of ventilation holes must be observed. • The product must be connected to the mains power, and corresponding connections of other components must be suitable. •...

  • Page 8: Product Weight

    This appliance has been designed to Climate range Ambient temperature of the room be used in certain climate ranges Between +50 F (10 C) and +90 F (32 (ambient temperatures). It must not Between +60 F (16 C) and +90 F (32 be used out of this range.

  • Page 9: Installation Place

    Installation Place You must follow the instructions below: • The floor on which the product will be installed must be capable of bearing 1,200 pounds (544 kg) minimum. • Kitchen floor and the bottom of the product must be at the same level. Otherwise, problems may occur with the air suction of the product.
  • Page 10 To avoid the risk of electric shock: • Connect the plug to a grounded 3-pin socket. • Do not remove the ground terminal of the plug. • Do not use adapters. • Do not use extension cables. ATTENTION: Failure to follow these instructions may result in death, fire or electric shock. Connecting the grounding conductor of the equipment to an improper place may lead to electric shock.

  • Page 11: Electrical Connection

    Ventilation: Vent holes where the air enters and exits the unit must not be blocked or obstructed. In addition, you must periodically clean the dust and dirt that accumulate on these holes in time. Electrical Connection: • Never use an extension cable. •...

  • Page 12: Tool List

    TOOL LIST Tools to be used when installing the product are as follows: Safety ½" Cordless Goggles Wrench Drill ammer Ladder Ø2.4 Drill bit Ø8.0 Safety Drill bit Cutter Gloves ¼" Tape Star bit measure Wrench Flat Bubble Tape Wheelbarrow Level Tool...

  • Page 13: Alternatives For Installation

    ALTERNATIVES FOR INSTALLATION The product can be placed in various ways based on the kitchen design. It must be installed at a place where it is ensured that the door can be opened and closed properly. If the doors cannot be opened 90 degrees at least, you cannot completely open the drawers inside the product.

  • Page 14: Preparation For Installation

    PREPARATION FOR INSTALLATION The instructions below have been prepared according to Built-in type. Built-in: The Appliance and Panels fully seat into the gap, and a material that can be their own box is jammed between the two kitchen cabinets or decorative columns. This is the most common installation scenario.

  • Page 15: Location Of The Electrical Wiring

    Location of the Electrical Wiring Location of the electrical wiring must be within the range given below. ATTENTION: Do not use extension cables or two-pin adaptors and do not remove the ground terminal of the grounding cable. ATTENTION: A qualified electrician must ensure that the poles of the socket are connected correctly. Verify that the grounding of the socket is correct.

  • Page 16: Location Of The Water System

    Location of the Water System The water connected to the water mains must be potable. Location of the water system must be within the range given below. Water system of the refrigerator must be connected to the water mains system in the house. The user must be able to switch it on/off with the valve when necessary.
  • Page 17 WARNING: • Flatness of the floor where the product will be installed must be checked with a Bubble Level Tool. • Uprightness of the furniture flanges must be checked with a Bubble Level Tool. • If the flatness and uprightness of the product is not proper, problems may arise with the installation.

  • Page 18: Production Dimension

    PRODUCT DIMENSION AINT7600/AINT7600IW AINT9000/AINT9000IW Category 29 3/4” (756mm) 35 3/4” (908mm) without panel : 23 5/16” (592mm) with panel : 24 ¼” (616mm)
  • Page 19 Category AINT7600/AINT7600IW AINT9000/AINT9000IW 15 9/32" (388mm) 15 9/32" (388mm)
  • Page 20 Category AINT7600/AINT7600IW AINT9000/AINT9000IW 32 7/16” (824mm) 38 7/16” (976mm) 29 3/4“ (756mm) 35 3/4“ (908mm) 55 1/32” (1398mm) 61” (1550mm) 3/8” (10mm) 90° 90°Door swing...
  • Page 21 Category AINT7600/AINT7600IW AINT9000/AINT9000IW 443/8” (1127mm) 54 3/4” (1391mm) 29 3/4“ (756mm) 35 3/4“ (908mm) 14 5/8” (371mm) 19” (483mm) 52 11/16” (1338mm) 57 11/16” (1466mm) 115° 115°Door swing...
  • Page 22 Anti tip bracket location 3/4” (19mm) Remaining space after install Minimum height adjustment for leveling 3/4” (19mm) Assembly dimension between Assembly dimension between Wood panel and freezer door Wood panel and fridge door...
  • Page 23 AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 24 Height of the kitchen countertop based on the min/max. height of the cabin; standard 4” (102mm) 32 11/16” (831mm) 84” (2134mm) minimum 3 13/16”(97mm) 32 1/2“ 826mm 83 13/16“ 2129mm maximum 5 3/8“ 137mm 34 1/8“ 866mm 85 3/8“ 2169mm Door wood panel Furniture wood panel AINT7600/AINT7600IW...

  • Page 25: Unpacking

    Unpacking WARNING: At least two persons must carry the refrigerator. • Use a box cutter to remove the tapes. • Cut the Packaging Board with a Box Cutter through the section illustrated in dotted lines and remove it.
  • Page 26 ⚫ Remove the Packaging Polystyrene material. ATTENTION: Do not remove the tape of the upper door on the product until the refrigerator is placed into the cabin. Risk of tipping over.

  • Page 27: Removing Connectors On The Rear Wall

    Removing connectors on the rear wall Part name spec Trim fridge furniture side PVC extrusion L=617, L=1,259 Trim fridge door side PVC extrusion L=1136 Trim freezer door side PVC extrusion L=556 Trim furniture top PVC extrusion L=762, L=914 Cover freezer door top Conference Category AINT7600/AINT7600IW...

  • Page 28: Removing Mounting Parts In The Freezer Compartment

    Removing mounting Parts in the Freezer Compartment ⚫ Open the freezer compartment door and remove the mounting boxes and documents in the crisper. Part name spec Furniture door preparation template paper Anti tip bracket T4.0, Zn-coating Dowel Anti tip bracket screws M8*L60 Position adjustment jig 90 limiting pins...

  • Page 29: Removing The Freezing Crisper

    Part name spec Cabinet- cabin connecting bracket T1.0, Zn-coating Screw cabin connecting bracket ST4x14, counter sunk head screw Cover furniture door bracket Screw door fixing bracket M4*12, truss washer head Door- door furniture connecting bracket T1.0, Cr+zn-coating Screw furniture door fixing bracket ST4x14, counter sunk head screw Screw furniture door hanger bracket ST4x14, counter sunk head screw...

  • Page 30: Removing The Freezing Door

    Removing the Freezing Door Remove 2 screws which are near the front section and connect the freezing door and the rail. ⚫ Pull the door frontward to free it from the tabs at the back and remove it.

  • Page 31: Removing The Lower Vent Hole Assembly

    Removing the Lower Vent Hole Assembly ⚫ Remove the 2 screws to take out the Lower Vent Hole Assembly. Removing the Upper Vent Hole Part ⚫ Remove the 2 screws to take out the Upper Vent Hole Part.

  • Page 32: Pre-Installation

    PRE-INSTALLATION Continue to install the product according to the instructions below. Additionally, consider national and local instructions regarding installation. Please observe the following: • For the USA, The National Electrical Code, ANSI/NFPA 70 – last version/State or Municipality directives and/or regional directives. •...
  • Page 33 ⚫ Use a drill to create holes for dowels (item No.3) at the marked points. (5/16” -Ø8) ⚫ Use the hammer to fit the dowels ( item No.3)
  • Page 34 ⚫ Fit the anti-tip brackets (item No.2) into their places, using 4 screws (item No.4) for each. You must use all of the 2 brackets to ensure safety of the product. WARNING: If you are not sure whether the existing connection parts are fit to the wall as securely as they should be, you can use alternative anti-tip methods.

  • Page 35: Alternative Anti-Tip Method

    Alternative anti-tip method: If the anti-tip brackets cannot be connected securely, you must use the alternative method below. In this method, you can use wooden girders to avoid the risk of tipping over. It must be installed as illustrated in the figure below. There must be no clearance between the product and the wooden girder.

  • Page 36: Preparing The Water Hose And The Power Plug

    Preparing the Water Hose and the Power Plug You will need a hose with a minimum length of 60" (1.5 meters) and a diameter of ¼" water connection of the product during installation. A connector that has a thread with an external diameter of ¼ must be used to connect the hose end to the product. can choose the method A or method B below to prevent the cable from getting jammed.

  • Page 37: Installation To The Cabin

    INSTALLATION TO THE CABIN Taking the Refrigerator from the Wooden Pallet ⚫ Remove the brackets that connect the refrigerator to the Wooden Pallet.

  • Page 38: Placing The Refrigerator Into The Cabin

    ⚫ Recline the refrigerator slowly and pull back with the help of the cart, and then land ATTENTION: The risk of tipping over is high as of this point. You should not open the doors until the product is placed into the cabin. Placing the refrigerator into the cabin ⚫...
  • Page 39 IMPORTANT INFORMATION: ⚫ Apply the below method to prevent the cable from getting jammed. Power cord Nylon string Move to walll Water hose ⚫ Start the refrigerator and make sure it is energised. (You can check if the lamps of the freezer compartment are on or off to see if the product is operating).
  • Page 40 IMPORTANT INFORMATION: You must use the upper edges of the Freezer Door when aligning the product with the furniture. Adjustment of other edges are explained in the following pages.

  • Page 41: Adjusting The Height Of The Refrigerator In The Cabin

    Adjusting the height of the refrigerator in the cabin ⚫ Adjust the refrigerator height using the adjustable feet. WARNING: First of all, raise the front feet to reduce the risk of the cabin falling frontward. A/D –Turn the key clockwise to lift the front B/C –Turn the key clockwise to lift the rear.

  • Page 42: Adjusting The Refrigerator According To The Cabin Flange

    ⚫ After adjusting the adjustable feet, check the flatness in both width and depth directions. The maximum height that the adjustable feet can reach is 1 9/16" (40 mm) and the product height is 85 3/8" (2,169 mm) IMPORTANT INFORMATION: Adjusting the refrigerator according to the cabin flange ⚫...
  • Page 43 ⚫ For products without furniture doors, the product is placed using the Adjustment part (Item No5) as shown in the figure below. IMPORTANT INFORMATION: It is very important to align the upper edge of the Freezer door when aligning. All the other edges can be adjusted with the adjustment mechanisms.
  • Page 44 ⚫ The position adjustment jig (Item No5) must be adjusted according to the thickness of the door. It can adjust the level for 4 different door thickness levels.

  • Page 45: Screwing The Cabinet-Cabin Connecting Bracket

    Screwing the cabinet- cabin connecting bracket ⚫ Fix the cabinet-cabin connecting bracket (Item No12) to the cabinet, where 2 on the top, and 3 on every side. Use screw cabinet connecting bracket (Item No11) to tighten. WARNING: Before starting to screw the Side and Upper brackets, please make sure that water is supplied to the product and there is no water leakage.
  • Page 46 IMPORTANT INFORMATION: If you have difficulty tightening the screws, opening a reference hole with the drill will make this procedure easier. ⚫ Attach cabinet-cabin connecting bracket (Item No12) to the cabin. with 16 screws cabin connecting bracket (Item No13).

  • Page 47: Installing The Cabin Bottom

    INSTALLING THE CABIN BOTTOM Water connection ⚫ Use the box cutter to cut the water hose from the end of the pipe it comes out, leaving a section of 10". ⚫ Use the 2 wrenches to firmly connect the hose coming from the mains and the hose coming from the valve.
  • Page 48 IMPORTANT INFORMATION: Once the connection is complete, you must turn on the mains valve and make sure that there is no leakage at that point.

  • Page 49: Attaching The Upper Vent Hole Part

    Attaching the upper vent hole part ⚫ Use 2 screws to attach the upper vent hole part.

  • Page 50: Attaching The Lower Vent Hole Assembly

    Attaching the lower vent hole assembly ⚫ Use 2 screws to attach the lower vent hole part. IMPORTANT INFORMATION: You can move the lower vent hole forward-backward to adjust it to the kick plate in the kitchen. WARNING: Forward-backward travel distance of the lower kick plate must be 15/16" (23 mm). As you can see in the figure, the decorative kick plate must not be in front of the upper vent hole level.

  • Page 51: Attaching The Decorative Parts

    Attaching the decorative parts ⚫ Attach the trim fridge furniture side (Item No1) onto cabinet-cabin connecting bracket (Item No12). ⚫ Attach the trim furniture top (Item No4) onto cabinet-cabin connecting bracket (Item No12).
  • Page 52 WARNING: Maximum weights of the furniture to be mounted to the product are as follows. Fridge Door: 35.7 lbs. (16.2 kg) Freezer Door: 19.8 lbs. (9 kg) Choosing the Door Thickness ⚫ The door of your refrigerator can open by 115° maximum. If the door is going to open to this degree, you can choose the following thickness levels.
  • Page 53 ⚫ You can limit the opening degree of your door to 90° if you want. In this case, the door thickness levels can be like the following (you can look at the relevant section to learn how to attach the 90° limiting pin (Item No6).

  • Page 54: Furniture Door Preparation

    FURNITURE DOOR PREPARATION This section contains information about preparing the furniture doors and mounting them to the product. Removing the Mechanism Covers ⚫ Remove screws to take out the cover door hanger bracket upper and fixing bracket. ⚫ Remove two screws to take out the cover door hanger bracket low.

  • Page 55: Removing The Panel-Adjustment Mechanisms On The Refrigerator

    Removing the Panel- Adjustment Mechanisms on the Refrigerator ⚫ Remove the upper and lower Adjusting Mechanism assemblies from the door.

  • Page 56: Preparing Furniture Door

    Preparing Furniture Door IMPORTANT INFORMATION: You must take the dimensions into account when grouping the cradle parts on the furniture door. When marking, you can use the "Furniture door preparation template" (Item No 1) provided with the product. WARNING: Handle connection holes must be adjusted according to the handles to be used in kitchen design. WARNING: Minimum thickness of the door must be ¾"...

  • Page 57: Preparing The Furniture Door

    Preparing the Fridge Furniture Door 76：1 7/16” (38mm) 91：4 7/16” (114mm) 26 13/16”(680mm) 76：29 3/4“ (756mm) 91：35 3/4“ (908mm) 76 1 7/16” (38mm) 91 4 7/16” (114mm) AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 58 WARNING: You must use screws suitable for the door thickness. ⚫ Install 2 hanger bracket using the screw furniture door hanger bracket (Item No18). You can also use the furniture door preparation template (Item No 1) provided with the product to align these parts. It is recommended to keep this template for future reference.

  • Page 59: Preparing The Freezer Furniture Door

    Preparing the Freezer Furniture Door 2 9/16” (65mm) 76 29 3/4 “ (756mm) 91/92 35 3/4” (908mm) AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 60 WARNING: Handle connection holes must be adjusted according to the handles to be used in kitchen design. WARNING: Minimum thickness of the door must be ¾" (19 mm). WARNING: You must use screws suitable for the door thickness. ⚫ Install hanger bracket using the screw furniture door hanger bracket (Item No18). You can also use the furniture door preparation template (Item No 1) provided with the product to align these parts.

  • Page 61: Installing The Fridge Furniture Door

    INSTALLING THE FRIDGE FURNITURE DOOR 1. Attach the furniture door to the fridge door...
  • Page 62 How to align the fridge door with bolts. Position of the Furniture Doors to the kitchen furniture must be flush. To achieve this, you should adjust 3D direction using by two fixing bolt to perform fine adjustments. First of all, review the position of the grouped Furniture Doors against the kitchen furniture. Distances between furniture must be 1/8"...
  • Page 63 • How to align the furniture door lower part with bolts Front & back Up & down Fixing furniture door completely Left & right...
  • Page 64 • Use the door-door furniture connecting bracket (Item No16) to join th e furniture door • Use 1 screw door fixing bracket (Item No15) to fix on the door. • Use 2 screws (Item No17) to fix on the furniture door. AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 65 • Clip the cover furniture door bracket (Item No14) AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 66 • Attach and screw the upper/lower decoration cover. AINT7600/AINT7600IW AINT9000/AINT9000IW WARNING: There is a magnet on the cover door hanger bracket upper. This is a functional part for the operation of the product. It should not be confused with the lower cover.

  • Page 67: Installing The Freezing Furniture Door

    INSTALLING THE FREEZING FURNITURE DOOR • Attach door-door furniture connecting bracket (Item No16) on the door lower part with screw door fixing bracket (Item No15) ⚫ Attach the furniture door to the freezing door...
  • Page 68 How to align the freezing furniture door lower part • • How to align the furniture door upper part with screw freezer door hanger bracket (Item No8). Front & back Left & right Up & down • Use the door-door furniture connecting bracket (Item No16) to join the furniture door •...
  • Page 69 • Clip the cover furniture door bracket (Item No14). WARNING: You must keep these parts for future use. You will need them if you want to change the door directions. • Install the Freezer Furniture door assembly onto the rails.
  • Page 70 • Fix the Freezer Furniture door assembly onto the rails with 2 screws. • Locate the drawer onto the rail and tighten the screws...
  • Page 71 • Attach the cover freezing door top (Item No5) using the tabs.
  • Page 72 • Attach the Trim door side (Item No2,3) The backing paper of the double-sided tape should be removed before attaching the parts.

  • Page 73: Hinge Adjustment

    HINGE ADJUSTMENT Adjusting the hardness of the hinges • Use a drill to adjust the hardness of the upper and lower hinges of the fridge door. Set the hinge adjustment screw to position "I" from position "O". WARNING: The door must be fully open during this adjustment. WARNING: This adjustment must definitely be performed after the door has been adjusted.

  • Page 74: Changing The Direction Of The Ff Door

    CHANGING DIRECTION OF THE FRIDGE DOOR Removing the fridge furniture door • Set the hardness level of the hinge to "0". ATTENTION: Failure to set the hinge to "0" and continuing the installation like that may cause injury. • Remove the trim fridge furniture side...
  • Page 75 • Loosen 2 screws of the upper cover of the fridge door and remove • Remove the upper adjustment kits • Loosen 2 screws of the lower cover of the fridge door and remove it.
  • Page 76 • Remove fridge lower and upper bracket and fixing screws. AINT7600/AINT7600IW AINT9000/AINT9000IW...
  • Page 77 WARNING: The clad door will be released when these screws are removed. You must take measures to prevent the door from falling. You can tape the Furniture Door to the Inner Door or ask for help from another person. • Take the Fridge Furniture Door and lay it down on a table upside down.

  • Page 78: Removing And Preparing The Fridge Inner Door

    Removing and preparing the Fridge Inner Door • Remove the hinge connection screws of the Hinge Brackets. ATTENTION: The clad door will be released when these screws are removed. You must take measures to prevent the door from falling. You can tape the Furniture Door to the Inner Door or ask for help from another person.
  • Page 79 • Take out the fridge door and lay it down on a table remove the fixing parts and screw them to the opposite side of the door as shown figure.

  • Page 80: Replacing The Hinges

    Replacing the hinges • Remove the Hinge Caps located at the other side where you will fix the hinges.
  • Page 81 • Remove the lower right hinge by loosening its 2 screws and fix it to its slot at the upper left side.
  • Page 82 • Remove the u pper right hinge by loosening its 2 screws and fix it to its slot at the lower Left side...
  • Page 83 • Attach the Hinge Slot Caps removed from the left side to the Hinge Caps at the right side.

  • Page 84: Installing The Fridge Door

    Installing the Fridge Door • Place the Fridge Door to the refrigerator and fix it with 4 screws.

  • Page 85: Installation Dual Cabin

    INSTALLATION DUAL CABIN If you are going to make a dual cabin installation, you must definitely demand "Dual Cabin Installation Kit" from the authorized service. The instructions below have been prepared according to Built-in type. Built-in: The Appliance and Panels fully seat into the gap, and a material that can be their own box is jammed between the two kitchen cabinets or decorative columns.

  • Page 86: Location Of The Electrical Wiring

    Location of the Electrical Wiring Location of the electrical wiring must be within the range given below. ATTENTION: Do not use extension cables or two-pin adaptors and do not remove the ground terminal of the grounding cable. ATTENTION: A qualified electrician must ensure that the poles of the socket are connected correctly. Verify that the grounding of the socket is correct.
  • Page 87 WARNING: Make sure that there is no water leakage when making the water connections. Otherwise, there will be water on the floor and the furniture will get damaged. You will need a hose with a minimum length of 60" (1.5 meters) and a diameter of ¼" for water connections of the product during installation.

  • Page 88: Mounting Part Lists

    Mounting Part list Part name Spec Remark Insulation sponge Sponge, gray, T3.0*400*1750 Connecting bracket T2.0, Cr+zn-coating Truss washer head M4*12 Fastener Trim furniture middle PVC extrusion L=1876 Truss washer head screw Spec : M4x12 Fixing Refrigerator Such as cabinet and door (press part) Item No1 Stick the Insulation Sponge (...

  • Page 89: Attaching The Fasteners And Connecting Bracket

    Insulator Insulator T3.0*400*1750 Attaching the fasteners and connecting bracket Item No2) Item No4) Screw the connecting bracket( and fasteners ( that are going to connect two refrigerators together. Fastener Connecting bracket...
  • Page 90 Make power and water connections of the refrigerator as explained before. After making sure that they are in alignment Screw the upper brackets to the other refrigerator. After making sure that they are in alignment screw the lower brackets to the other refrigerator.

  • Page 91: Adjusting The Height Of The Refrigerator In The Cabin

    Adjusting the height of the refrigerator in the cabin Adjust the refrigerator height using the adjustable feet. WARNING: First of all, raise the front feet to reduce the risk of the cabin falling frontward. A/D –Turn the key clockwise to lift the front B/C –Turn the key clockwise to lift the rear...

  • Page 92: Screwing The Bracket Furniture On The Cabin Side Wall

    Screwing the bracket furniture on the cabin side wall Attach the to the furniture with 12screws. cabinet- cabin connecting bracket Screwing the bracket furniture on the cabin top wall ⚫ Attach the cabinet- cabin connecting bracket to the furniture with 4screws.

  • Page 93: Attaching The Decorative Parts

    Attaching the decorative parts Attach the trim furniture side onto the abinet- cabin connecting bracket. Attach to the trim furniture top onto the abinet- cabin connecting bracket.
  • Page 94 Attach the trim furniture middle ( Item No5) between two refrigerators.
