Ford Ranger/Everest and VW Amarok
Camera Installation Guide
1480 (10 Inch) & 1486 (12 Inch)
PLEASE READ BEFORE BEGINNING INSTALLATION
Installation Terms & Conditions
•
All labels on the product including software versions and serial numbers must not be covered, damaged or removed.
This may void the warranty on the product.
•
Ensure that all left over accessories, including remote controls and cables, are kept for future use. If replacements are
required in the future they will not be provided free of charge.
•
Please ensure the installation of this product will not interfere with any factory safety equipment (e.g. Airbags).
•
If working with Airbags, be sure to disconnect the vehicle Battery before beginning work. This product and the
following instructions are designed for installation by a qualified 12v installer, car audio installer or auto electrician.
•
Interfaces modules must not be installed in a location where they will be exposed to extreme temperatures
including, but not limited to, installation on top of a vehicles radio, transmission tunnel or firewall.
Damaged caused by exposure to heat is not covered under warranty.
Important Product Information
•
This product comes with a 2 year warranty against manufacturer related defects. Please read the included warranty
card and register the device on the Advanced ICE Pty Ltd website.
•
This installation manual covers a range of products and vehicles.
Required Tools for Installation
•
Dash and Trim Removal tools
•
7mm Socket Set
•
Dash Protection Tape (Recommended)
Contents
•
Picking Tool
•
Electric/Battery Drill
Page 1
1486_1480_INS_V1.7
1
2
2
3
3
4
4
4
5
6
7
7
7
8
8
10
Advertisement
Table of Contents
Related Manuals for Advanced ICE 1480
Summary of Contents for Advanced ICE 1480
-
Page 1: Table Of Contents
• This product comes with a 2 year warranty against manufacturer related defects. Please read the included warranty card and register the device on the Advanced ICE Pty Ltd website. • This installation manual covers a range of products and vehicles. -
Page 2: Kit Contents
Mode Connection Plug the Mode button in here for use when testing the system or if the customer does not like the Steering Control Buttons available 1486 Ford/VW 12 Inch Interface 1480 Ford 10 Inch Interface F H G Page 2... -
Page 3: Wiring Information
Wiring Information Description Used For Connect Camera video signal for cameras Video Input (F CAM) F - CAM that can be viewed when driving Connect Camera video signal for cameras Video Input that can be viewed when in reverse R - CAM (R CAM) using RTC (see user manual) Video Input... -
Page 4: Step 1 - Dash Removal
Step 1 - Dash Removal Click or scan on the QR Code to watch the video on how to perform the dash removal in order to prepare for the installation. Ford Ranger VW Amarok These videos are to be used as a guide only and may not represent the exact process for all Year/Model Variants. -
Page 5: Camera Installation Scenarios
Camera Installation Scenarios SINGLE CAMERA INSTALLATION Connect to Camera RCA R - CAM F - CAM DUAL CAMERA INSTALLATION When Installing a AHD Dual Camera Setup, it is crucial you refer to page 6 F - CAM Connect to Driving Forwards Caravan Camera R - CAM Connect to Reverse... -
Page 6: Camera Power Wiring For Dual Ahd Cameras
Camera Power Wiring for DUAL AHD Cameras In some situations it is possible for interference to show on the camera image when installing a DUAL AHD Camera to our interface. Below are the instructions and a schematic diagram showing how to wire up the cameras to remove the interference. -
Page 7: Interface Menu Settings
Interface Menu Settings Scan or click on the QR Code to watch the video on how to use the interface menus to configure the system. Vehicle Option Menu In the Vehicle Option Menu the following changes can be made Car Model The car model menu is an important menu where the interface needs to be set for the correct car that it is being installed in. -
Page 8: Setup System Menu
Setup System Menu Side Cam Detect This menu allows you to activate additional camera inputs, a total of 3 cameras are available while driving. • CAM OFF - Default One Camera input activated - This camera is always activated • CAM2 (R) This adds a second camera input and allow the right camera to be turned on by indicator. -
Page 9: When Driving
Ford Ranger & Everest VW Amarok When Driving Long Press the OK button which is the systems Default Activation button to turn on the Camera Source. If additional camera inputs have been activated, then additional long press of this button will cycle through the camera inputs. In Reverse Long Press the OK button to switch from the vehicles factory reverse camera to the Camera input of our interface. -
Page 10: Trouble Shooting
Trouble Shooting When I connect the interface I get no image on the factory screen, it’s black? A1. Please check to ensure that the LVDS Video Cables are connected the right way. The Cable with the Red Tape should be connected to the LVDS Video connector on the end - OEM IN. A2.
