- Page 1 PIVOT BLUETOOTH KEYBOARD WITH TRACKPAD PA-KA27A | User Guide For Use With PIVOT A27A Case [Issued 2025.05.16]...
-
Page 2: Read Before Use
For best results, we recommend setting up your iPad, including adding your fingerprint in Touch ID, before installing it in the PA-KA27A case. This ensures all sensors and buttons are fully accessible during setup. The PA-KA27A case is... -
Page 3: Product Description
Product Description The PA-KA27A is a Bluetooth Keyboard solution for users who frequently use their iPad for data entry or document editing. The PA-KA27A is an accessory to be used in combination with iPads housed in the protective *PIVOT A27A case. - Page 4 Trackpad PA-KA27A Keyboard Removable Silicone Keyboard Cover Installing PA-KA27A STEP 1: Remove the iPad from the PIVOT A27A case. Beginning with the bottom edge near the charging port, press firmly using your thumbs to disengage the case seal. Continue carefully pressing around the edges of the case to release the iPad in the order shown.
- Page 5 Installing PA-KA27A (cont.) STEP 2: Place the PA-KA27A keyboard into the PIVOT A27A case body. STEP 3: With the PA-KA27A USB-C charging port aligned properly with the PIVOT A27A case body, press the keyboard into place within the case body.
- Page 6 The iPad will snap securely into the case's perimeter seal. Reference STEP 1 if necessary. Congratulations! Assembly is now complete. You are now ready to pair the PA-KA27A with your iPad via Bluetooth, see next page for steps. page: 06...
-
Page 7: Indicator Light Description
If this occurs, turn the keyboard o and then on to automatically reconnect. If you need to reconnect manually, delete the connected PA-KA27A by clicking PIVOT-KB001 from the Bluetooth list before reconnecting using the same pairing steps above. - Page 8 The blue character functions of certain keys must be used in combination with the Fn key. To activate, press and hold the Fn key + the desired blue character function key. See below for the PA-KA27A keyboard layout and described function keys. Button Icon...
- Page 9 Use Configurations A. Laptop Mode B. Tablet Mode C. Transit Mode PA-KA27A Articulation A. The durable hinge provides 360° rotation. 360° 360° page: 09...
-
Page 10: Incorrect Use
Incorrect Use The PA-KA27A is durable if used as intended, but can be damaged if subjected to repeated stress and misuse. Do not attempt to force the PA-KA27A beyond its maximum open position of 180°. - Page 11 Trackpad Function One finger tap mode for Two finger tap mode for left mouse button function right mouse button function Slide up and down with two fingers Swipe left or right with two fingers for mouse wheel function to switch desktops Pinch to zoom Swipe up with three fingers in and out (web page)
-
Page 12: Product Specs
4.35 lbs (1.97 kg) Sleep Mode Function If the PA-KA27A is not operated for more than 10 minutes, it will automatically enter sleep mode and the keyboard will disconnect from Bluetooth to preserve battery life. To wake from sleep mode, press any key on the keyboard and wait 3 seconds, then the keyboard will wake and automatically reconnect. -
Page 13: Safety Precautions
I can't seem to connect the PA-KA27A to my iPad, what can I do? If the PA-KA27A isn't working correctly, please try the following steps: A. Make sure the PA-KA27A is within 10 meters of the e ective working distance. B. Make sure Bluetooth pairing is successful. If not, attempt re-pairing. - Page 14 Thank you. Learn more at: PIVOTCASE.COM PIVOT SUPPORT If you have questions please contact PIVOT Support. www.pi vot c as e . com /s up por t sa les@piv ot ca se.com 1-888-4-FLYBOYS (1-888-435-9269) www.youtube.com/@pivotcase TM and © 2025 FlyBoys. All rights reserved.
