Delta Electronics DPS-275GB Specifications

DPS-275GB

FEATURES

• Application: Desktop PC
• 80mm fan
• Comply with Intel CFX12V 1.0
• Remote On/Off
• Low acoustics noise
• High reliability
• Fan speed control
• Short circuit protection
• Over voltage protection
• Over current protection
• Active or Passive PFC @ 230Vac to
meet EN61000-3-2 (optional)
CB

Output

Voltage Regulation
V1 +3.3V
±5%
V2 +5V ±5%
V3 +12V1 ±5%
V4 +12V2 ±5%
V5 -12V ±10%
V6 +5Vsb ±5%
1. Total continue power output: 275W
2. The combined power on +3.3V & +5V: 110W max
All specifications are subject to change without prior notice.
DELTA ELECTRONICS, INC.
3, TUNG YUAN ROAD, CHUNGLI
INDUSTRIAL ZONE
TAOYUAN SHIEH, TAIWAN, R.O.C.
TEL: 886-3-4526107
FAX: 886-3-4527314
mail: powersales@delta.com.tw
Series
150/101.6 (W) x 86/40 (H) x 95 (L) mm

ENVIRONMENTAL

• Operating ambient temperature: 10~50 ºC
• Operating relative humidity: 5~85%
• Storage ambient temperature: -40~70ºC
• Storage relative humidity: 5~95%
• Altitude: 10,000~50,000 feet
• MTBF: > 100K hours @ max. load & 25ºC
ambient conditions.
Minimum Maximum
Peak Load
Load Load
0.5A 13.0A -
0.3A 14.5A -
1.0A 5.0A 7.0A
1.0A 13.5A
0.0A 0.3A -
0.0A 2.0A 2.5A
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL: 1-510-668-5100
FAX: 1-510-668-0680

ELECTRICAL SPECIFICATIONS

INPUT

• Input Range
• Frequency
• Input Current
• Efficiency
• EMI/RFI
OUTPUT

• Maximum Power

• Holdup Time
• Rise Time
• Leakage Current
• Overvoltage Protection: +3.3V, +5V, +12V
• Overcurrent Protection: <240VA
• Short-Circuit Protection: Latch off
Ripple & Noise • Power Good Signal: TTL compatible on delay 100mS
to 500mS, off delay 1mS.
Vp-p
50mV
50mV
120mV
120mV
120mV
50mV
DELTA ELECTRONICS(JAPAN) INC.
DELTA SHIBADAIMON BLDG.
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL: 81-3-5733-1111
FAX: 81-3-5733-1211
90~135Vac / 180~264Vac
47~63Hz
<6A @ 115Vac, <3A @ 230Vac
>70% @ 115Vac/230Vac
CISPR 22 Class B, FCC
275 Watts
>17mS @ 115Vac or 230Vac
0.2~20mS
<0.75mA @ 230Vac
