- Page 1 Itel Grid-tied PV Inverter user manual IGT-8~30KTA...
-
Page 3: Table Of Contents
Thank you for choosing non-isolated on-grid PV inverter. Contents In order to ensure your safety and proper use, please Contents read the manual in details before using. Thanks for your cooperation! 1.Overview ..........................3 1.1 Use of this manual ....................3 1.2 Symbols ........................ - Page 4 10.1 Specification ........................41...
-
Page 5: Overview
Contents 1.Overview Overview 1.1 Use of this manual This manual mainly introduces installation, operating and maintenance of inverter and related technical parameters. It is suitable for people who install the inverters and do other related jobs. Readers need to have some knowledge of electric, electrical wiring and mechanics. Before installing this product, please read this manual carefully, and put it in a suitable place, so as to ensure that relevant personnel of installation and operation can easily get it. -
Page 6: Nameplate
1.3 Nameplate Take IGT-12KTA for example... -
Page 7: Delivery
Contents 2.Delivery Delivery 2.1 Scope of Supply There are following items in the packing box, as shown in Table 2-1. Please check in time after receiving the products. Name Note PV on-grid inverter Product qualification certificate Fixed bracket Factory inspection report PV cable connector Male/female cable connector: 2 for each Used for fastening machine and the fixed... -
Page 8: Description
Contents 3.Description Description 3.1. Brief Introductions On-grid PV power generation system usually is composed of solar panels, junction box, inverter, ammeter and power grid. The core of the system is PV grid-connected inverter. The sunshine irradiates on the surface of the solar panels, solar panels output DC, converted by inverter, then output AC of the same frequency and phase with the grid, and then feed into the grid. -
Page 9: General Introduction
3.2 General Introduction Appearance and interface Fig 3-2 Appearance of 8~30KTA Appearance of IGT 8-30KTA (take 10KTA for example) is as shown in Figure 3-2. Its external interface is in the bottom of the machine and is composed of PV input port +, PV input port-, communication port, DC switch, AC output. - Page 10 Name Description Inverter’s DC input port, connect with + PV input port + port of PV arrays Inverter’s DC input port, connect with – PV input port - port of PV arrays Electric cut off between inverter and PV DC switch arrays Connect inverter with PC through this WIFI/GPRS/RS485...
-
Page 11: Installation
4.Installation Contents Installation Please carefully read below installation guide for IGT 8-30KTA. 4.1 Installation Procedure Before installing and operating this product, please strictly abide by the installation sequence and warning symbols. Start Preparations Mechanical installation Electrical Connection Overall inspection Commissioning Fig 4-1 Installation procedure 4.2 Installation Preparation ●... - Page 12 best service at fast as possible. ● Tools for installation The following installation tools and parts are needed. Spanner Electric impact drill Cross screwdriver M4 Allen wrench Megameter & Multimeter ● Choose installation location WARNING Please read carefully and follow the following basic installation requirements.
- Page 13 4. Do not install the inverter in the living area to avoid noise affecting daily life. 5. The installation location of the inverter should be far away from the reach of children. 6. Installation height is better to make the LCD at the same level with people’s eye so as to make it convenient to operate on the LCD.
- Page 14 9.Enough space surrounding the inverter is needed to ensure good heat dissipation. 10. Ensure that the inverter is ventilated and dissipated smoothly. It is strictly forbidden to install the inverter in a closed space, otherwise the inverter will not work normally, and there may even be a danger of explosion.
-
Page 15: Mechanical Installation
12. Please choose a place where you can avoid rain, snow, and direct sunlight for installation (sunlight, rain, snow, etc. will directly affect the service life of the inverter. If it is unavoidable, please shield the inverter reasonably. To ensure the best operating environment) 4.3 Mechanical Installation After moving the inverter to the installation site, install the fixing bracket to the wall through the expansion bolt (expansion bolt is M8×30) assembly, and then install the inverter to the fixing bracket. - Page 16 4-2 Installation size 2.Drill holes and install fixed brackets 4-3 installation steps If install the inverter on concrete wall a. Mark the drilling position on the wall according to the specifications of the fixing plate in Figure 4-2, and then drill at the marked position. A circular hole with a diameter of 10mm and a depth of 35mm. b.
-
Page 17: Electrical Connection
Solid Spring Spring wall washer washer Flat washer Expansio Bolts n plug Note: Please cooperate with the machine before installing the fixed bracket to prevent reverse installation. The inverter must be wall-mounted vertically 4.4 Electrical Connection When performing electrical wiring work, personal protective equipment must be worn. DANGEROUS High voltage! Electrical shock! - Page 18 NOTE The relevant rules of the local power grid and the relevant safety instructions of the photovoltaic string must be followed. All electrical installations must comply with the electrical standards of the country/region where the installation is located. Only after getting permission from the local power supply department, can the inverter be integrated into the grid.
- Page 19 In the figure, the L1 phase of the power grid is represented by a yellow line, the L2 phase is represented by a green line, the L3 phase is represented by a red line, and the power grid N line is represented by a black line.
- Page 20 ● AC cable wiring steps lens 1. Turn off the AC side circuit breaker and place a "no power-on" sign to prevent it from being switched on. 2. Connect the AC side connector to the corresponding AC terminal at the bottom of the inverter. 3.
- Page 21 Distance between inverter and grid connecting point, corresponsive cable(cable Model diameter: mm 10-30m 30-50m 50-80m Above 80m When there is only one inverter in the 8/12K project, try to avoid distance between 15/17K inverter and grid connecting point more than 80m. When there are multiple inverters in project, it can firstly use combiner box to 20/23/25/28/30K combine outputs of inverters, then choose...
- Page 22 The two PV string inputs operate independently, and each has an independent MPPT. Therefore, the two photovoltaic inputs can be different from each other, including: different panel types; different numbers of cells in the PV string; different inclination angles, different azimuth angles. NOTE In order to make full use of the DC input power, the PV strings of the same input should be close to the same (especially the voltage), including: the same model;...
- Page 23 1. This series of connectors only supports multi-strand copper wires. Cut and strip as required, the stripping length is 7-8mm. 2. Crimp the wire. Place the terminal correctly in the terminal crimping pliers, then put the bare copper wire part of the cable into the terminal opening slot and press it firmly. Be careful not to damage the terminals and the copper wires of the wires.
- Page 24 WARNING When wiring the PV cable, the positive and negative poles must be connected correctly. Please cut off the power of the system and verify whether the male and female connectors are of the same model before use. 4. After the cable is plugged in, use a special wrench or adjustable wrench to tighten the nut. In order to achieve better results, two wrenches can be used to work together.
- Page 25 ● Grounding WARNING Since the inverter is a transformerless type, it is required that the positive and negative poles of the photovoltaic string cannot be grounded, otherwise the inverter will not operate normally. Grounding system In this PV power generation system, all non-current-carrying metal parts and equipment housings should be grounded (such as the bracket of the PV arrays, the inverter housing, etc.).
-
Page 26: Monitoring
Contents 5.Monitoring Monitoring 5.1 Overview The inverter has a variety of communication methods. When users need to monitor the operation information of the photovoltaic power generation system, we provide the communication system solutions shown in Figures 5-1 and 5-2. RS485(standard MODBUS) Figure 5-1 RS485 (standard MODBUS protocol) communication system mode Smart device Figure 5-2 WIFI/GPRS communication system mode... - Page 27 ● Collector description Figure 5-3 Installation diagram...
-
Page 28: Wifi Logger Quick Guide
WIFI Logger Quick Guide Notice: Please read this manual carefully before using products and keep it in the place where O&M providers can easily find. Due to product upgrade and other factors, the content of this manualmight change from time to time. - Page 29 Notice: 5G WiFi is not supported . Step 2: WIFI Logger connect the router wifi signal. Open the mobile browser and enter the IP: 10.10.100.254. Enter the WIFI Logger network connection page. Step 3: Click on the FIND WIFI button to look for the router signals tobe connected to the Internet.
- Page 30 Step 4: Select the wifi signal of router and input the wifi password, finally click OK Notice: If connect displays 1, it means that the network connection is successful. If configuration failure occurs, please check the following reason and try it again. Make sure WLAN is ON.
-
Page 31: Atsolar App
5.3 ATSolar App ATSolar App is a set of smart systems based on mainstream mobile platforms that realize data docking between smart devices and cloud platforms. It can display the operating data and status of the system in real time. ●... - Page 32 Power station list Daily power generation ● Add multiple power plants under the same account Log in to the list of "My Power stations", Click the drop-down menu in the upper left corner, click "+" to add power station. Enter your power station name and city location, and at the same time correct the location of your power station in the middle map position (you can manually enter the longitude and latitude of your power station in the longitude and latitude edit box) to complete the addition of your power station.
- Page 33 Click on drop-down menu Click to add station Fill in the station information Click to add collector Fill in the collector information NOTE Due to the different operations caused by the software upgrade, please refer to the actual situation. For specific operations, please contact the supplier!
-
Page 34: Cloud Server
5.4 Cloud Server Smart energy management platform is a web-based remote monitoring system. After adding an inverter and binding the device data source, you can monitor the operating status of the PV system in real time, and know the power generation, power, temperature, C02 Key data such as emission reductions and revenue; view equipment operating status, including information such as faults and alarms;... -
Page 35: Trial Run
6.Trial run Trial run is an important step in the installation of PV Contents systems. Correct trial operation can prevent system fires, Trial run electric shocks and other accidents. 6.1 Inspection before trial run Before turning on the inverter for the first time, you need to do the following inspections. Environmental inspection 1). -
Page 36: Shut Down & Dismantle
hut down 7.Shut down & Dismantle Contents & Dismantle 7.1 Shut down In normal operation, there is no need to shut down the inverter manually, but it is necessary to shut down the inverter during maintenance or repair. To disconnect the inverter from the AC and DC power supply, follow the steps below, otherwise it may cause personal injury or death or equipment damage. -
Page 37: Operating
8.Operating Contents Operating 8.1 Working Mode The working modes of the inverter include-start mode, run mode, and standby mode. In each working mode, the LCD displays corresponding information. 8.1.1 Control panel with indicator light only For the indicator panel of the TLC series grid-connected photovoltaic inverter, in order to better carry out the interactive operation of the man-machine interface, 3 LED lights are set on the panel, as shown in Figure 8-1. - Page 38 ● LED display status Function Status Description Grid-connected and power generation DC is normal, AC is not powered on Running DC is normal, grid-connected standby Equipment failure DC is not powered on The communication cable or communication Communicat module is connected, and there is data interaction on the communication channel The communication cable or communication module is not connected or there is no data...
-
Page 39: Disconnect From Grid
8.2 Disconnect from grid When the grid has below abnormal situation, inverter will disconnect from the grid immediately. The grid voltage is outside the normal range of 310V-480V; The grid frequency is outside the normal range of 45-55Hz/55-65Hz; ... -
Page 40: Maintenance
Contents 9.Maintenance Maintenance DANGEROUS Do not open the machine. Users trying to repair the machine by themselves may cause electric shock and fire hazard. 9.1 Maintenance Due to the influence of ambient temperature, humidity, dust and vibration, the internal components of the inverter will age and wear, which will affect the service life of the inverter. - Page 41 Table.9-1.troubleshooting Failure solution 1. Disconnect AC side circuit breaker 2. Disconnect DC side circuit breaker LED indicator and LCD 3. Check the input voltage of the PV array (whether it is lower screen do not light up than 300V) and the grid voltage 4.If the above conditions are met, check the circuit breaker 1.
-
Page 42: Quality Assurance
The warranty period of this product is subject to the contract. ● Conditions 1.Itel will offer free repair service or replace with new product for faults during the warranty. 2.The replaced unqualified product will be returned to Itel. 3.Customers need to give Itel reasonable time to deal with the machine fault. -
Page 43: Specification
Contents Specification 10.1 Specification DC Input Data IGT-8KTA IGT-10KTA IGT-12KTA IGT-15KTA IGT-17KTA Max. DC input power (W) 10400W 13000W 15600W 19500W 22100W Max. DC input voltage(VDC) 1100V Max. DC current(A) 18 /18A 18/30A MPPT voltage range(VDC) 180-1000V Recommended working 650V voltage(VDC) MPPT number Max. - Page 44 Protection class IP66 DC Input Data IGT-20KTA IGT-23KTA IGT-25KTA IGT-28KTA IGT-30KTA Max. DC input power (KW) 26000W 29900W 32500W 36400W 39000W Max. DC input voltage(VDC) 1100V Max. DC current(A) 30/30A 36/30A 36/36A 36/36A MPPT voltage range(VDC) 180-1000V Recommended working 650V voltage(VDC) MPPT number Max.
