Summary of Contents for ELSER 600V2 GPS
- Page 1 MotoAlarmSystem 600V2 GPS / 600V1 Installation & user manual...
- Page 3 ATVs, scooters and other motorcycle-type machines with a 12V battery voltage. Thank you for your choice! ELSER 600V2 GPS THIS SYSTEM INCLUDES Security Unit: With built-in 122dB siren. Backup Battery: Ensures continuous operation even in case of power failure and activates the unit's siren.
- Page 4 ELSER 600V1 THIS SYSTEM INCLUDES Security Unit: With built-in 122dB siren. Backup Battery: Ensures continuous operation even in case of power failure and activates the unit's siren. HOPPING CODE: Protects the system from possible hacking attempts in case of attempted theſt.
- Page 5 System security and anti-theſt functions ELSER 600v2 GPS & 600V1 System Arming with Tilt and Shock sensor Before security arming, make sure that: Ignition switch is off. The arming delay of the security unit is 15 seconds. Press and release the button the siren will chirp once and parking light once motorcycle's flashers will light up once,...
- Page 6 Panic mode Press and release the button The siren will activated and the turn signals will flash for 30sec Motorcycle's location Press and hold the button for 3 seconds. The siren does not sound and motorcycle's flashers will flash to inform the owner of the motorcycle's location.
- Page 7 Security Disarming with personal PIN code - Password setup and changing This ELSER security system allows the user to program a personal disarming password to provide a higher level of security for the motorcycle's security system.
- Page 8 Press and release the button of the remote control as many times as needed to increase > the level of the personal PIN code by one step at a time, the system will respond with siren sounds (the maximum level is 9) Press and release the button as many times as needed to decrease <...
-
Page 9: Sensor Settings
SENSOR SETTINGS You can adjust the shock and tilt sensors using the remote control. SHOCK SENSOR ADJUSTMENT The adjustment of the shock sensor is performed in disarmed mode in the following order: Turn the ignition switch to the ON position. Press and hold the button of the remote control for 5 seconds;... - Page 10 How to Activate the Built-Battery While the system is in the disarmed state, ignition switch to the ON position. Press and hold button 1 and button 3 for 1 second together. The siren will chirp (2) twice and the flashers will flash (2) twice, confirming that the system has activated the backup battery.
- Page 11 Installation and connection of the system General installation requirements Find the ideal point by placing the unit and organizing the wiring on the particular motorcycle, a procedure must be followed for the system to function properly. Check the spaces and construction of the motorcycle, to decide what is the best available space for mounting the unit and accessories.
- Page 12 Main unit wiring information Black connector 10PIN it is divided into black 4PIN connector and constitutes the central wiring of the alarm unit Installation is designed to be easy and quick. Black connector 4PIN Black wire: (-) ground or to the negative pole of the battery. Gray wire: +12V output with fuse on the right turn signal.
- Page 13 GPS tracking Pair your alarm system with ELSER TRAC to get GPS Tracking on your smartphone for added security and convenience! Installation of GPS ELSER TRACK Device Connect the black cable of Elser Track device to the accessory wiring directly to the black 3PIN with a three-wire plug that the main unit wiring has.
- Page 14 Upgrade your security system for even more security Optional Accessories MD-4 Perimeter sensor MD-4 Perimeter sensor Safety with perimeter protection – Detects movement around the motorcycle designed with 3 warning levels. Installation MD-Perimeter sensor Connect the black cable of the MD-4 device to the accessory wiring directly to the black 4PIN with a three-wire plug that the main unit wiring has.
- Page 15 Starter kills Starter– kills MD-5 Eliminate motorcycle theſt by preventing thieves from starting the motorcycle engine while the ELSER security system is armed. Installation Connect the black cable of the MD-5 device to the accessory wiring directly to the black 2PIN with a two-wire plug that the...
