decina PREZZO PRTSWFR Installation & Owners Manual

Back-to-wall rimless toilet suite

Download this manual

P R E Z Z O B A C K - T O - W A L L R I M L E S S T O I L E T S U I T E

This manual provides the correct steps and care advice for a safe and long lasting installation.

The Prezzo rimless back-to-wall toilet suite has the latest in innovative, hygiene technology in a modern streamline design. Designed to

THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED TRADESMAN

READ CAREFULLY

PRIOR TO COMMENCING

INSTALLATION

I N S TA L L AT I O N & O W N E R G U I D E

Thank you for purchasing a Decina Prezzo Toilet Suite .

sit flush against the wall it saves space & makes cleaning easier.

Before installing your new toilet, unpack & check the item is correct & not damaged. If there

are any visible defects do not proceed with the installation & contact the place of purchase

immediately. Any claims for damage will not be accepted after installation.

If the product has not been installed in accordance with AS/NZS 3500.1 and AS/NZS 3500.2

instructions, the warranty will be invalidated.

Check that the toilet is compatible with your current set out requirements. This toilet has a

universal set out distance of 100-200mm.

This toilet comes with a S Trap Vario Bend. P Trap connection IS SOLD SEPARATELY.

Check that the floor and wall are level and perpendicular.

This product is configured as a left hand top inlet or can be reconfigured as right or left hand

bottom inlet entry. An appropriate length flexible connector is sold separately.

This toilet is not suitable to be used with some offset collars and slab adapters.

*Decina Universal Adjustable Pan Connector (150-250mm) connector) DEPCU

PRTSWFR

CYCLONE

FLUSH

Need help?

Do you have a question about the PREZZO PRTSWFR and is the answer not in the manual?

Page 1 I N S TA L L AT I O N & O W N E R G U I D E Thank you for purchasing a Decina Prezzo Toilet Suite . This manual provides the correct steps and care advice for a safe and long lasting installation.
Page 2 SAFETY EQUIPMENT REQUIRED FOR INSTALLATION Protective Clothing Foot Protection Eye Protection Hand Protection INSTALLATION STEPS STEP 1. Install the brass spigots and rubber washers into the pan. Do not over tighten - leave loosely attached to enable flexible connection when fixing cistern to pan (Step 6).
Page 3 INSTALLATION STEPS STEP 4. Insert the Vario Bend onto the pan outlet spigot. If trimming is required work out the measurement and mark the cutting line. Check the measurements and then cut the Vario Bend to the correct length. Place rubber seal and cover over the front of the Vario Bend and install, ensure that the sewer connection is connected correctly and a good seal has...
Page 4 *Warranty T&Cs apply. All dimensions are nominal & subject to manufacturing tolerances & may vary +/-5mm therefore we strongly recommend installation does not occur until after delivery. Decina reserves the right to modify or change models without notice. Please confirm all particulars with your sales consultant prior to purchase. For further information and for...
