- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. EMPIRE VFPA36BP71LP-2 Owner's Manual Shop genuine replacement parts for EMPIRE VFPA36BP71LP-2 Find Your EMPIRE Fireplace Parts - Select From 642 Models -------- Manual continues below --------...
- Page 2 INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL VENT-FREE GAS FIREPLACES UNVENTED GAS FIREPLACE MODELS: MILLIVOLT VFPA(32,36)BP3(0,1)L(N,P)-1 INTERMITTENT PILOT VFPA(32,36)BP7(0,1)L(N,P)-1 WARNING If not installed, operated and maintained in accordance with the manufacturer’s instructions, this product could expose you to substances in fuel or from fuel combustion which can cause death or serious illness.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Carton Contents ................................3 Important Safety Information ............................4 Safety Information For Users Of Propane Gas ......................5 Introduction .................................. 6 Specifications ................................7 Water Vapor: A By-Product Of Unvented Room Heaters ..................... 8 Provisions For Adequate Combustion & Ventilation Air ..................... 8-9 Gas Supply ................................ -
Page 4: Carton Contents
CARTON CONTENTS Product Registration Card Decorative Rock QUANTITY SUPPLIED INDEX DESCRIPTION NUMBER 30 Series 70 Series Battery AA Cover Junction Box Decorative Rock Flex Line Hood Instruction Sheet - Soot Power Adaptor Receptical Registration Card Rockwool Screw #8 X 1/2 Trim, Left Side Trim, Right Side Trim, Top Side... -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION DANGER: Indicates a hazardous situation which, if not avoided, will • WARNING! This fireplace needs fresh air for ventilation to result in death or serious injury. run properly. This fireplace has an ODS (oxygen depletion sensor) which will shut down the heater if adequate fresh air is WARNING: Indicates a hazardous situation which, if not avoided, not available. -
Page 6: Safety Information For Users Of Propane Gas
SAFETY INFORMATION FOR USERS OF PROPANE GAS Propane is a flammable gas which can cause fires and explo- members of your household. Someday when there may not sions. In its natural state, propane is odorless and colorless. be a minute to lose, everyone's safety will depend on knowing You may not know all the following safety precautions which exactly what to do. -
Page 7: Introduction
INTRODUCTION Instructions to Installer Installation on Rugs and Tile 1. Installer must leave instruction manual with owner after If this appliance is installed directly on carpeting, tile or other installation. combustible material other than wood flooring the appliance 2. Installer must have owner fill out and mail warranty card shall be installed on a metal or wood panel extending the full supplied with unvented room heater. -
Page 8: Specifications
SPECIFICATIONS MODEL VFPA32BP VFPA36BP Input BTU/Hr Maximum 32,000 36,000 Input BTU/Hr Minimum 22,000 25,000 KWH (Maximum) 9.38 10.55 KWH (Minimum) 6.45 7.33 MINIMUM FIREBOX OPENING Height 33" 35" Width 35” 40” Depth 16-1/2" 19” Gas Inlet 1/2” 1/2” ACCESSORIES EK-1 Embers Kit PE-20 Platinum Embers... -
Page 9: Water Vapor: A By-Product Of Unvented Room Heaters
WATER VAPOR: A BY-PRODUCT OF UNVENTED ROOM HEATERS Water vapor is a by-product of gas combustion. An unvented room The following steps will help insure that water vapor does not heater produces approximately one (1) ounce (30ml) of water for become a problem. - Page 10 PROVISIONS FOR ADEQUATE COMBUSTION & VENTILATION AIR Ventilation Air From Outdoors (Figure 2) The space in the above example is a confined space because the actual BTU/Hr used is more than the maximum BTU/HR the space Provide extra fresh air by using ventilation grills or ducts. You must can support.
-
Page 11: Gas Supply
GAS SUPPLY Check all local codes for requirements, especially for the size and The use of the following gas connectors is recommended: type of gas supply line required. — ANS Z21.24 Appliance Connectors of Corrugated Metal Tubing and Fittings RECOMMENDED GAS PIPE DIAMETER —... -
Page 12: Clearances
GAS SUPPLY (CONT'D) Checking Manifold Pressure VFPA(32,36)BP(70,71) (Propane Gas) will have a manifold pressure approximately 10.0"w.c. (2.49kPa) for maximum input or 4.9"w.c. VFPA(32,36)BP(30,31)LN (Natural Gas) will have a manifold (1.220kPa) for minimum input at the pressure regulator outlet with the pressure of approximately 3.5"... -
Page 13: Combustible Materials
COMBUSTIBLE MATERIALS Do not attach combustible material to the mantel of your fireplace No greeting cards, stockings or ornamentation of any type should be This is a fire hazard. placed on or attached to the fireplace. This is a heating appliance. The flow of heat can ignite combustibles. -
Page 14: Fireplace Dimensions
FIREPLACE DIMENSIONS OUTER FIREPLACE DIMENSIONS .5 inches OUTER FIREPLACE DIMENSIONS (IN INCHES) VFPA32 VFPA36 16-1/2 27-7/8 31-7/8 22-1/4 24-1/4 1-3/16 1-3/16 31-1/2 33-1/2 8-5/16 8-5/16 4-3/4 4-3/4 30-1/4 34-5/8 60-3/8 69-1/8 2-11/16 2-11/16 42-5/8 48-7/8 Figure 8 39025-2-0620 Page 13... -
Page 15: Planning Installation
PLANNING INSTALLATION In planning the installation for the fireplace, it is necessary to If the fireplace is installed directly on carpeting, tile or other determine where the unit is to be installed and whether optional combustible material other than wood flooring, it should be installed accessories are desired. -
Page 16: Installing Hood And Trim Kit
FIREPLACE FRAMING AND INSTALLATION (CONT'D) DELUXE VENT-FREE FIREBOX FRAMING DIMENSIONS (In Inches) Model Framing Framing Framing Height Width Depth VFPA32BP 33 3/4 35 1/2 16 1/4 VFPA36BP 35 3/4 40 1/2 18 3/4 Attention: Add 3-3/4 inches to "A" Dimension when using flush mantel base. -
Page 17: Placement Of Glowing Embers And Lava Rock
Rock wool should not be placed in the area of the pilot assembly. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater. WARNING: All previously applied loose material must be removed prior to reapplication. -
Page 18: Vfpa(32,36)Bp(30,31) Lighting Instructions
VFPA(32,36)BP(30,31) LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by •... -
Page 19: Vfpa(32,36)Bp(70,71) Lighting Instructions
VFPA(32,36)BP(70,71) LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which can be lighted with the manual •... -
Page 20: Operation Instructions/Flame Appearance
OPERATION INSTRUCTIONS/FLAME APPEARANCE PERIODIC CLEANING – Refer to parts diagram for location of Flames from the pilot (rear right back side of the pan burner) as well as the main flame should be visually checked as the log set items discussed below. is installed. -
Page 21: Pilot Flame Characteristics
PILOT FLAME CHARACTERISTICS Figures 13 and 15 show a correct pilot flame pattern. The correct INTERMITTENT PILOT flame will be blue and will extend beyond the thermocouple. The Correct Pilot Flame Pattern flame will surround the thermocouple just below the tip. A slight IGNITOR yellow flame may occur where the pilot flame and main burner flame meet. - Page 22 PILOT FLAME CHARACTERISTICS Cleaning and Pilot Maintenance Oxygen Depletion Sensor Pilot When the pilot has a large yellow tip flame, clean the Oxygen Depletion Sensor as follows: Clean the ODS pilot by loosening nut B from the pilot tubing. When this procedure is required, grasp nut A with an open end wrench.
-
Page 23: Millivolt Wiring
MILLIVOLT WIRING Remote Receiver Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper Use the following steps to place the remote receiver adjacent to operation after servicing. the gas valve. Attention: The remote receiver bracket is not used in this installation. -
Page 24: Millivolt Troubleshooting
MILLIVOLT TROUBLESHOOTING SYMPTOMS - POSSIBLE CAUSES AND CORRECTIONS Turn appliance OFF and allow to cool before servicing. Only a qualified service person should service and repair the heater. a. Control knob not fully pressed in - Press in control 1. When ignitor button is pressed, there is no spark at knob fully. -
Page 25: Intermittent Control System Operating Instructions
INTERMITTENT CONTROL SYSTEM OPERATING INSTRUCTIONS 5.25 VDC ELECTRONIC CONTROL VALVE Follow the SAFETY and LIGHTING INSTRUCTIONS for In- The electronic control valve system includes the ability to switch termittent Pilot controls found in this manual, and on labels the pilot from a standing pilot mode to an intermittent pilot mode. found in the control compartment located in the lower cavity •... -
Page 26: Intermittent Control System Wiring Diagram
INTERMITTENT CONTROL SYSTEM WIRING DIAGRAM BLUE BLUE GREEN WHITE WHITE CPI/IPI ORANGE SWITCH ON/OFF REMOTE RECEIVER PILOT SWITCH (OPTIONAL) YELLOW + ON REMOTE - OFF BLACK BLACK GAS CONTROL VALVE (GND) WHITE GREEN BLACK AC/DC POWER ADAPTOR BLACK ELECTRONIC CONTROL MODULE BATTERY HOLDER Figure 21 If any of the original wire as supplied with this unit must be replaced, it must be replaced with equivalent gauge and temperature... -
Page 27: Intermittent Control System Troubleshooting
Brief Description of the Components The gas valve is equipped with a manual HI/LO knob to allow for manual modulation of the gas outlet pressure. The manual HI/LO knob can be replaced by an Empire Comfort Systems Variable Remote Kit. WARNING This appliance is equipped for Natural or Propane gas. - Page 28 INTERMITTENT CONTROL SYSTEM TROUBLESHOOTING If the DFC giving signal lock out: Verify the electrical connections’ integrity and The board should be unlocked to make sure they are in accordance with the relevant reinitiate a pilot flame ignition (for Is the DFC board in system wiring diagram.
- Page 29 INTERMITTENT CONTROL SYSTEM TROUBLESHOOTING Replace DFC board. Main burner lights when the pilot only Replace the gas valve. should light. Verify the pilot flame fully engulfs the tip of the sense electrode. If not replace the pilot assembly. Replace the pilot assembly. Carefully clean the electrical connections of the sense cable, and the DFC board sense cable connection.
-
Page 30: Optional Variable Speed Blower Installation Instructions
OPTIONAL VARIABLE SPEED BLOWER INSTALLATION INSTRUCTIONS FBB5 BLOWER INSTALLATION Attention: Install blower assembly before connecting gas inlet supply line. NOTE: Junction box on right side of fireplace must be pre-wired at time of fireplace installation for use with blower assembly. It is recommended that an ON/OFF wall switch be installed that will activate the power supply to the furnace by a qualified electrician. - Page 31 OPTIONAL VARIABLE SPEED BLOWER INSTALLATION INSTRUCTIONS 110 VOLT AC WIRING The appliance, when installed, must be electrically grounded in JUNCTION BOX accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, if an external electrical source is utilized.
-
Page 32: Junction Box Wiring Installation Instructions
JUNCTION BOX WIRING INSTALLATION INSTRUCTIONS A factory installed junction box is located on the lower right hand CAUTION side of the fireplace. Wiring must be fed to the junction box and attached to the receptacle that is provided. Remove the knockout All wiring should be done by a qualified electrician and shall in the installed junction box to accept wiring into the junction box. -
Page 33: Master Parts Distributor List
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F. -
Page 34: Vfpa32Bp(3,7) Parts List
VFPA32BP(3,7) PARTS LIST ATTENTION: When ordering parts, it is very important that part number and description of part coincide. PART NUMBER - VFPA32 Index Description 30 Series 70 Series 39279 39279 Fireplace Painted Assembly 39492 39492 Face Assembly Complete 40736 40736 Top Trim 41135... - Page 35 VFPA32BP(3,7) PARTS LIST (CONT'D) ATTENTION: When ordering parts, it is very important that part number and description of part coincide. PART NUMBER - VFPA32 Index Description 30 Series 70 Series R11332 Wire - Sensor - 24 in R2667 Wire Assembly - ON/OFF Switch 29699 Bracket - ON/OFF Switch R11127...
-
Page 36: Vfpa36Bp(3,7) Parts List
VFPA36BP(3,7) PARTS LIST ATTENTION: When ordering parts, it is very important that part number and description of part coincide. PART NUMBER - VFPA36 Index Description 30 Series 70 Series 39295 39295 Fireplace Painted Assembly 39494 39494 Face Assembly Complete 40737 40737 Top Trim 41137... - Page 37 VFPA36BP(3,7) PARTS LIST ATTENTION: When ordering parts, it is very important that part number and description of part coincide. PART NUMBER - VFPA36 Index Description 30 Series 70 Series R11332 Wire - Sensor - 24 in R2667 Wire Assembly - ON/OFF Switch 29699 Bracket - ON/OFF Switch R11127...
-
Page 38: Parts View
PARTS VIEW MILLIVOLT INTERMITTENT PILOT (IP) VALVE ASSEMBLY VALVE ASSEMBLY 39025-2-0620 Page 37... -
Page 39: Warranty
WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods speci- fied below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. -
Page 40: Service Techncian Notes
SERVICE TECHNICIAN NOTES Date Dealer Name Service Technician Name Service Performed/Notes 39025-2-0620 Page 39... - Page 41 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 40 39025-2-0620...
