- Page 1 EZ Glaze Installation Guide ™ UV Resistance Snow Load Wind Resistance Aesthetics Easy To Install EZ Glaze™ - Product Page palram.com/us Installation video...
-
Page 2: Recommended Safety Equipment
Installation Recommended Safety Equipment Profile drawing Do not step directly on the sheets between the purlins! When installing EZ Glaze or doing maintenance work, always use ladders or crawl boards, supported by minimum three roof structural elements. Required Tools Overlapping One side of the panel corrugation is larger than the opposite side panel corrugation. -
Page 3: Installation Preparation
24” 24” ‚ To install EZ Glaze directly on rafters, the inner rafters must be 24” on center. ‚ If end rafters are less than 24” on center, then the end roof panels must be cut to proper width before installation (see typical finishing details in the last page). -
Page 4: Installation
Attaching the first EZ Glaze panel Attaching the second EZ Glaze panel ‚ Install the first EZ Glaze panel on the rafters, leaving 1”-3” overhang. ‚ Attach the second panel, overlapping the first one. ‚ Drill 3/8” holes along the outer corrugation, every 16”. - Page 5 Installation (Flashing accessories supplied by others) Attaching the second EZ Glaze panel Applying Expanding foam tape Expanding foam tape Using specified fasteners, attach the panels to the structure by fastening through the Expanding foam tape must expand to a dimension no less than 1.75”.
- Page 6 Installation - Typical Finishing Details (Flashing accessories supplied by others) Applying Silicone Side Wall Flashing Silicon sealer Screw to wall Metal Flashing EZ Glaze Ez Glaze™ Installation Guide...
- Page 7 Installation - Typical Finishing Details (Flashing accessories supplied by others) Installing Side Wall Flashing with trimmed EZ Glaze Silicon sealer Screw to wall Metal flashing EZ Glaze Aluminum angle Silicon sealer Butyl Sealing tape Screw to wall Pre-drill EZ Glaze panel...
- Page 8 In the event of a warranty claim for product failure, Palram Americas reserves the right to inspect any or all of the sheets involved and the installation site itself while the sheets are still in their original position and have not been removed or moved or altered in any way.
