48in. x 24in. OVERHEAD STORAGE RACK
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #6107896
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Klutch 6107896
Summary of Contents for Klutch 6107896
- Page 1 48in. x 24in. OVERHEAD STORAGE RACK Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #6107896 READ & SAVE THESE INSTRUCTIONS...
- Page 2 ® Thank you very much for choosing an KLUTCH product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: Purchase Date: Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ........................ 5 Specific Operation Warnings........................ 6 Main Parts of Shelving Rack ......................... 7 Assembly Instructions .......................... 8 Operating Instructions ........................11 Maintenance ............................12 Troubleshooting .......................... -
Page 4: Intended Use
Intended Use Overhead Storage Rack is a storage unit with a steel frame attached to the ceiling and steel mesh, offering industrial-strength storage. The mesh decks allow air circulation around stored items. The rack can be installed individually or in series. The rack has a 350-lb. total capacity Packaging Contents ⚠WARNING •... -
Page 5: Important Safety Information
Important Safety Information ⚠WARNING • Read and understand all instructions. Failure to follow all instructions may result in serious injury or property damage. • The warnings, cautions, and instructions in this manual cannot cover all possible conditions or situations that could occur. Exercise common sense and caution when using this product. Always be aware of the environment and ensure that the product is used in a safe and responsible manner. -
Page 6: Specific Operation Warnings
⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. •... -
Page 7: Main Parts Of Shelving Rack
Main Parts of Ceiling Mounted Shelves Part Subassembly Quantity Uprights Ceiling Mounted Bracket Long Beam Short Beam Cross Brace Wire Mesh Deck Page 7 of 14... -
Page 8: Assembly Instructions
Assembly Instructions ⚠WARNING • CAUTION: Make sure that the shelf brackets are completely fixed on the ceiling without gaps to prevent property damage or personal injury. STEP 1: Install the Ceiling Mounted Bracket ▪ Determine if the orientation of your ceiling rack will be installed parallel or perpendicular to the direction of your ceiling. - Page 9 STEP 3: Install the Uprights onto the brackets. ▪ For Perpendicular Assembly: Bolt together one post assembly through the hole located on the side of the post to the center hole of the inside angle of bracket. ▪ The backside of the post must be facing in and the tapered ends of the post slots must be facing down (as illustrated below).
- Page 10 STEP 5: Install the Cross Brace. ▪ Put the Cross Brace (E) into the middle of the two Long Beam (C) as shown in the photo. ▪ Secure the Cross Brace and the Long Beam (C) by Lock Nut and Hex Screw (see figure 5). Figure 5 STEP 6: Insert the Wire Mesh Deck ▪...
-
Page 11: Operating Instructions
Operating Instructions ⚠WARNING • Do not exceed the rated load capacity per shelf. • Do not climb. • This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children. • Make sure these instructions are read and completely understood before attempting installation. If you are unsure of any part of this installation, please contact a professional installer for assistance. -
Page 12: Maintenance
Maintenance • To avoid rusting, keep the unit out of damp or wet environments. • If shelves become damp, wipe with a cloth to avoid rusting. Be sure to dry the shelf joints. Troubleshooting Failure Possible Cause Corrective Action Unload shelf and reload, staying Shelf is bent. -
Page 13: Replacement Parts
Northern Tool & Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the KLUTCH product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions. - Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in Vietnam Page 14 of 14...
