  • Page 1 User´s Manual English FLEXA 3.0 IBPRO6...

  • Page 2: Table Of Contents

    Air conditioning control User settings Time schedule Consumption of system Zone settings Warnings and errors in the system Airzone Think Knowing the Airzone Think Screensaver Home screen (temperature control) Managing the Airzone Think Navigation Basic Functions Setup Menu Warnings and errors in the system...

  • Page 3: Precautions And Environmental Policy

    PRECAUTIONS AND ENVIRONMENTAL POLICY Precautions For your security, and to protect the devices, follow these instructions: • Do not handle the system with wet or damp hands. • Disconnect the power supply from the air conditioning and heating system before making any connections or disconnecting equipment. •...

  • Page 4: Airzone Interfaces

    AIRZONE INTERFACES Airzone thermostats control the air conditioning and boost the energy efficiency of your AC unit. Both master and zone thermostats can be easily configured. From your master thermostats you can change modes, define the degree of energy efficiency with Eco- Adapt or select the speed of your unit.

  • Page 5: Airzone Blueface

    AIRZONE BLUEFACE GETTING TO KNOW YOUR BLUEFACE Screensaver The screensaver pops up after about 30 seconds of inactivity, displaying the following information: Time and date Current zone Room temperature Relative humidity Zone state. On/Off Time and date. This information can be edited from the user settings menu. (See user settings, page 9).

  • Page 6: Home Screen (Temperature Control)

    Home screen (temperature control) With just one touch, the thermostat goes from the screensaver to home screen. There we can find the following functions: Operating mode System speed Eco-Adapt function Current zone/Room temp. User settings Set-point temperature Relative humidity On/off Air conditioning control Zone settings Time schedule...

  • Page 7: Managing The Blueface

    Air conditioning control: Control menu of the basic functions of Airzone systems. Time schedules: In this menu, you can program your Airzone system and activate/ deactivate time schedules. (See time schedules, page 10). System consumption It provides information about the consumption of your system.
  • Page 8 Ventilation: In this operating mode, the system works exclusively in ventilation mode when any of the zones is generating demand (Setpoint T < room T). Cooling: In this operating mode, the system works exclusively in cooling mode when any of the zones is generating demand (Setpoint T <...
  • Page 9 Fan Speed It is used to set the speed of the AC unit fan. The speed is set in automatic mode by default, imposing the flow depending on the number of zones in demand. In fancoil installations, the system speed can be manually selected from the Master thermostat.

  • Page 10: User Settings

    Depending on your system configuration, you can select: • State of the zone: it displays information about the state and configuration of the zone. • Weather information: Only available with Webserver Airzone Cloud. • AC unit consumption: only available for computers with consumption reading. •...

  • Page 11: Time Schedule

    Time schedule If you press the time schedule icon, you will access the menu where you can schedule your air conditioning: Add. Create schedule Time schedule Activate/Deactivate time schedules ZONE 01 PROGRAMA 01 PROGRAMA 01 Mode schedule 12:00 12:00 Mo - Tu - We - Th - Fr - Sa - Su 23.0 ºC 23.0 ºC PROGRAMA 02...

  • Page 12: Consumption Of System

    Depending on the type of installation and on how you system is configured, there are some extra functionalities: Grille angles: It allows you to define the angle of the Airzone grilles of the zone for cooling and heating modes. It is defined at 90º by default (this option is not available for plenums).

  • Page 13: Warnings And Errors In The System

    Lite settings: You can use this parameter to define base set-point temperature for zones with Airzone Lite. Besides, you can also configure your wired Airzone Lite cable to act as wireless (the LED light will switch off after a few seconds).

  • Page 14: Airzone Think

    17). Control bar: It adjusts (by pressing or by sliding) all the parameters controlled by the Think. Airzone: A button used to confirm and return to home. On/off: On/off of the zone where the thermostat is located.

  • Page 15: Home Screen (Temperature Control)

    Home screen (temperature control) Press on the Airzone icon once to deactivate the screensaver and go to home. Once there, you will find the following functions: System speed Eco-Adapt function Operating mode Control Bar Zone Settings menu Set-point temperature Relative humidity...

  • Page 16: Managing The Airzone Think

    Blueface. Control bar: It adjusts (by pressing or by sliding) all the parameters controlled by the Think. Airzone: A button used to confirm and return to home. On/Off: On/off of the zone where the thermostat is located. USING AIRZONE THINK...

  • Page 17: Settings Menu

    Settings menu Thanks to this parameter, you can set with the control bar the Sleep mode values: the Sleep mode is an auto power-off timer of the zone. These are the values you can select: • OFF. The timing is off. •...

  • Page 18: Warnings And Errors In The System

    Average speed. Low speed. Automatic speed. Warnings and errors of the system The Airzone Think thermostat screensaver displays several system warnings. Warnings Battery. Low battery warning. Incidents The system has an error-control mechanism. If the system displays any error, please contact your trusted installer.

  • Page 19: Airzone Lite

    AIRZONE LITE THERMOSTAT GETTING TO KNOW YOUR AIRZONE LITE The Airzone Lite thermostat allows you to easily control the temperature of the zone. On/off: Temperature setting: Temperature setting: lower temperature rise temperature On/off: On/off of the zone. In addition, it indicates the operating mode by using different colours.

  • Page 20: Managing The Airzone Lite

    The thermostat is switched off when the icon flashes to touch the interface. After about 10 seconds, your wireless Airzone Lite will switch off. In the case of having a wired Lite, you can configure this option in the Blueface: Lite settings (see zone settings, page 11-12).

  • Page 21: About The Battery

    ABOUT THE BATTERY Blueface thermostats and Think thermostats will display on their screen a battery alert when their batteries are dying. Lite thermostats also report when their batteries are dying but on the Blueface thermostat display. In order to replace the battery, please remove the thermostat from its support and then replace it (CR2450).
