TOLSEN TOOLS 88553 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
88553
DEMOLITION HAMMER
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
1700W 230V~50HZ

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 88553 and is the answer not in the manual?

Questions and answers

Related Manuals for TOLSEN TOOLS 88553

Summary of Contents for TOLSEN TOOLS 88553

  • Page 1 88553 DEMOLITION HAMMER INSTRUCTION MANUAL 1700W 230V~50HZ SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: Important Safety Information

    SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: read all safety warnings and instructions.Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.Save all warnings and instructions for future reference.The term ”power tool” in the warnings refers to your mains-operated (corded) power tool. Work area safety 3.

  • Page 3: Personal Safety

    SAFETY Personal safety 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

  • Page 4: Demolition Hammer Safety Warnings

    9. Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact Tolsen Tools for a replacement. 10. Avoid unintentional starting. Prepare to begin work before turning on the tool.
  • Page 5 SAFETY This tool vibrates during use. repeated or long-term exposure to vibration may cause temporary or permanent physical injury, particularly to the hands, arms and shoulders. to reduce the risk of vibration-related injury: 1.anyone using vibrating tools regularly or for an extended period should first be examined by a doctor and then have regular medical check-ups to ensure medical problems are not being caused or worsened from use.

  • Page 6: Specifications

    SPECIFICATIONS SPECIFICATIONS Electrical Input 230VAC / 50 Hz No Load Blows 1650 BPM Per Minute NPUT POWER 1700W Impact Joules (30mm x 410mm) 1 Bull Point (included) Chisels 1 Flat Point (included) Note: Symbology Double Insulated WARNING mark concerning Risk of Eye Injury.

  • Page 7: Setup - Before Use

    SETUP SETUP - BEFORE USE: Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Assembly The only assembly required for the Demolition Hammer is the positioning of the Auxiliary Handle around the Cylinder Case.
  • Page 8 SETUP OPERATING INSTRUCTIONS Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Tool Set up To prevent serious injury from accidental operation: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.

  • Page 9: Work Piece And Work Area Set Up

    SETUP Work piece and Work area Set up 1.Designate a work area that is clean and well-lit. The work area must not allow access by children or pets to prevent distraction and injury. 2.Route the power cord along a safe route to reach the work area without creating a tripping hazard or exposing the power cord to possible damage.

  • Page 10: Maintenance And Servicing

    MAINTENANCE AND SERVICING procedures not specifically explained in this manual must be performed only by a qualified technician. Note: the Demolition Hammer will cease operation once carbon Brushes are worn. check Brushes every 100-120 hours and, when necessary, replace them. TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERAITON: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.

  • Page 11: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING problem possible causes Likely Solutions Tool will 1.Cord not connected. 1.Check that cord is plugged in. not start. 2.No power at outlet. 2.Check power at outlet. If outlet is unpow- 3.Tool’s thermal reset breaker tripped ered,turn off tool and check circuit breaker. If (if equipped).

  • Page 12: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 88553 DEMOLITION HAMMER Hand Held Electric Chisel (Electric Chisel) Complies with the essential health and safety requirements of the following Directices: EC Council Directive 2006/42/EC Machinery Standards and technical specifications referred to:...
  • Page 13 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
