Scandinavian Safe BOX LOCK PIN Quick Start Manual

Important information:
The lock is delivered with two codes activated: master code and user code.
•
We recommend changing both codes.
• When programming code; keep the door open and the lock uprightly. The lock
is powered by a 3V CR2032 battery. If the lock does not open after correctly
entered code, the battery is probably too weak. (See power supply below.)
• We recommend to always have access to a spare battery.
If the wrong code is entered several times in a row, the lock goes into blocking mode for about one
•
minute. (Repeating beeps.)
The functions of the lock:
When the lock is delivered, standard function is activated.
• Standard function: the lock has two active codes, a master/programming code and a user code.
The user code is the one used to open/close the cabinet; the master/programming code is only used if
the user code is forgotten. When the master/programming code is used, the user code is reset to the
factory code (1-2-3-4) and must be reprogrammed.
Temporary user: the lock has the option of having two active codes, a master/programming code
•
(always activated) and a temporary user code (this code must be activated after each opening).
The temporary user code allows temporary users to use the lock during a locking/unlocking cycle once.
After that, a new temporary user code must be programmed again. You can only have one temporary
user code activated at a time. When the temporary user code is not activated, the cabinet is opened
with the master/programming code. If the master code is used to open the locker when the temporary
user code is activated, the temporary user code is deleted.
Power supply/battery replacement
Low battery level is indicated by two short beeps while the battery and padlock symbols flash once.
•
The battery is placed on the top of the lock. To access the battery, you need to unscrew the screw.
•
A screwdriver for this screw is included when the lock is delivered.
The lock is powered by a 3V CR2032 battery.
•
•
If the battery runs out without a new battery available, you can supply power to the lock via the USB
micro socket on the underside of the lock.
Scandinavian Safe AB I www.scandinaviansafe.se I +46(0)8- 68 98 560 I info@scandinaviansafe.se
BOX LOCK PIN
The lock has two different positions; standard function and temporary user.
1/2
2022-12-08
