Scandinavian Safe UR4020 Quick Start Manual

Important information:

• Before the lock is used, read through the manual carefully.
When you enter the code, cover the keypad so no unauthorized person can see the code.
•
• Every code must be kept safe. Try to use different numbers throughout the keypad and
avoid using personal information like birthdays etc.
• Remember your code – it is not possible to reset the lock if the code were to disappear!
• When programming code; keep the cabinet door open and the handle in locked position.
After programming code; try the new code multiple times before you close the door.
•
• When closing cabinet, always make sure the cabinet is locked.
The lock is powered by a 9-volt battery, only use alkaline high-quality batteries.
•
• If the lock does not open after correctly dialled code, the battery is probably too weak.
(See power supply/battery change below).
•
We recommend to always have a spare battery accessible.

Features of the lock:

• This lock has up to two users, so called master code and user code. Both the master- and user code is
always 6 numbers. When the cabinet is delivered, only the master code is activated.
Both the master- and user code can open the cabinet.
•
The master code "decides" everything and can add/delete the user code without knowing the code. The
•
user code can only change its own code.
• The lock can be programmed with time delay (1-99 min) and opening period (1-19 min). If activation of
this function is desired, contact us.
• The lock has a tamper lock, which means that if four incorrect codes are entered, the lock is
locked/blocked for 5 minutes. During the blocking time, the diode on the keypad flashes every
10 second and each press causes a long signal regardless of which key is pressed. After the blocking
time, if you enter two incorrect codes a new blocking time will start.
When the battery level is low, the lock warns by repeated short beeps after opening. It can also be
•
shown by the handle not being able to be lowered at the time of opening, despite the correctly
entered code.
Then change the battery.
•
1. Check that the handle is in its normal position i.e., turned as high as possible.
2. Enter the current code (the factory code is 1-2-3-4-5-6). The lock confirms with a double signal.
3. Turn the handle down to the open position.
1. Check that the handle is in the open position and close the door.
2. Raise the handle to the locked position.
3. Check that the cabinet is locked by trying to lower the handle to the open position.
www.scandinaviansafe.se I Tel: +46(0)8-68 98 560 I info@scandinaviansafe.se
ELECTRONIC CODE LOCK – UR4020

To open the lock/cabinet:

To close the lock/cabinet:

2022-11-22
1/2
Keypads
PI2030 & QT2030
