- Page 1 NUR162 - MESSY PLAY CORNER TABLE Installation Instructions PLAYTEC TOP NUR162 - MESSY PLAY CORNER TABLE 161-F 161-A 161-G NUR162 - C REF: NUR162 pg 1 of 7 09.10.2023 REV-1...
-
Page 2: Parts Required
PARTS REQUIRED NUR162 - B NUR162 - D NUR162 - E 25MM PLASTIC WASHER M8X180 SCREWS CHALK BOARDS M8XM80 SCREWS M8X60 BOLT M6X60 SCREW NYLOC END CAP REF: NUR162 pg 2 of 7 09.10.2023 REV-1... -
Page 3: Foundation Details
FOUNDATION DETAILS SOIL POST CONCRETE REF: NUR162 pg 3 of 7 09.10.2023 REV-1... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALL UPRIGHTS INTO THE GROUND USING - NUR162 -A X3 / NUR161- G X1 / M8X150 SCREWS X 16 ATTACH PLAYTEC TOP PLATE TO FRAME USING - M8X80 SCREWS X12 274.M12X230 X4 REF: NUR162 pg 4 of 7... - Page 5 INSTALLATION INSTRUCTIONS FIX WOOD PANNELS TO FRAME USING - M8X60 SCREWS X18 BRACE BACK OF FRAME AND SCREW INTO UPRIGHT USING - M8X80 SCREWS X5 / NUR162 - H X1 REF: NUR162 pg 5 of 7 09.10.2023 REV-1...
- Page 6 INSTALLATION INSTRUCTIONS REPEAT ON OTHER SIDE WITH WOOD PANNELS AND BRACE USING - M8X80 SCREWS X5 / M8X60 SCREWS X12 / NUR162 - H X1 ATATCH CHALK BOARDS USING - END CAPS X4 / BOLTS X2/ NYLOC X2/ 25MM PLASTIC WASHER X 2...
-
Page 7: Additional Dimensions
ADDITIONAL DIMENSIONS REF: NUR162 pg 7 of 7 09.10.2023 REV-1...
