Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts, which may have come loose inside the carton during shipment. Identify and count all items and
compare with the PARTS LIST and/or HARDWARE LIST shown below.
CAUTION: Read the instructions carefully before assembly.
1. We recommend that you assemble this product with the assistance of another person to eliminate
damage to the product during assembly.
2. When you want to reposition the product, please always "LIFT & M0VE."
PARTS LIST
NO. DESCRIPTION
A
SEAT FRAME
LEFT SIDE
FACING
B
(LSF) ARM
RIGHT SIDE
FACING
C
(RSF) ARM
D
BACKREST
SEAT
E
CUSHION
F
LEG
ASSEMBLY INSTRUCTIONS
BIANELLO COLLECTION
U2521-20A
BIANELLO LOVESEAT FRAME, CUSHION, ARMS, LEGS & 3 PILLOWS
U2521-20B
BIANELLO LOVESEAT BACKREST
Q'TY
SKETCH
(PCS)
HARDWARE LIST
NO. DESCRIPTION
FLAT
1
1
WASHER
Ø5/16 x 3/4''
WASHER
1
2
Ø5/16 x 1/2''
BOLT
1
3
Ø5/16 x 2¼''
ALLEN KEY
1
4
Ø5/16 x 3¼''
BOLT
1
5
Ø5/16 x 3¼''
4
Q'TY
SKETCH
(PCS)
11
11
8
1
3
PAGE 1/4
Created date: 7/4/2023
Advertisement
Related Manuals for New Classic Furniture ROYAL CLASSICS BIANELLO U2521-20A
Summary of Contents for New Classic Furniture ROYAL CLASSICS BIANELLO U2521-20A
- Page 1 ASSEMBLY INSTRUCTIONS BIANELLO COLLECTION U2521-20A BIANELLO LOVESEAT FRAME, CUSHION, ARMS, LEGS & 3 PILLOWS U2521-20B BIANELLO LOVESEAT BACKREST Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS LIST and/or HARDWARE LIST shown below.
- Page 2 ASSEMBLY INSTRUCTIONS BIANELLO COLLECTION U2521-20A BIANELLO LOVESEAT FRAME, CUSHION, ARMS, LEGS & 3 PILLOWS U2521-20B BIANELLO LOVESEAT BACKREST STEP 1: Lay the seat frame (A) on its back side to reach the holes to secure the bolts for the arms. Assemble the LSF arm (B) and RSF arm (C) to the seat frame (A) using Allen Key (4) with hardware, 1,2, and 3.
- Page 3 ASSEMBLY INSTRUCTIONS BIANELLO COLLECTION U2521-20A BIANELLO LOVESEAT FRAME, CUSHION, ARMS, LEGS & 3 PILLOWS U2521-20B BIANELLO LOVESEAT BACKREST STEP 3: Place the frame up right and install the backrest (D) to the LSF arm (B) and RSF arm (C) by sliding the brackets all the way until it is secured.
- Page 4 ASSEMBLY INSTRUCTIONS BIANELLO COLLECTION U2521-20A BIANELLO LOVESEAT FRAME, CUSHION, ARMS, LEGS & 3 PILLOWS U2521-20B BIANELLO LOVESEAT BACKREST STEP 5: Place the frame up right and place the seat cushion (E) to the seat frame. FINISH PAGE 4/4 Created date: 7/4/2023...
