V0.1
OBDII CODE READER
With Bluetooth
®
Instruction Manual
51002
WARNING
!
READ AND UNDERSTAND THIS INSTRUCTION MANUAL
PRIOR TO USING THIS PRODUCT. FAILURE TO DO SO
MAY RESULT IN SERIOUS INJURY OR DEATH.
Keep this instruction manual for future reference.
©2024 Star Asia-USA, LLC
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 51002 and is the answer not in the manual?

Questions and answers

Related Manuals for Titan 51002

Summary of Contents for Titan 51002

  • Page 1 V0.1 OBDII CODE READER With Bluetooth ® Instruction Manual 51002 WARNING READ AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO USING THIS PRODUCT. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. Keep this instruction manual for future reference.

  • Page 2: Specification

    51002 V0.1 This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest product information available at the time of publication.

  • Page 3: Supported Protocols

    V0.1 51002 Specification Value Operating Temperature: 32º to 140ºF (0º to 60ºC) Storage Temperature: -4º to 158ºF (-20º to 70ºC) 5-1/4 x 3-1/8 x 7/8 in. Size: (133 x 78 x 21 mm) Weight: 5.5 Oz. (155 g) FEATURES • Supports all 10 modes of OBD II •...

  • Page 4: General Safety Rules

    51002 V0.1 UNPACKING When unpacking, please inspect the product carefully to ensure the product is intact and undamaged. If any parts are missing or broken, please call 1-800-386-0191 as soon as possible. WARNING Do not use this product if damaged during shipment, handling, or after misuse.
  • Page 5 V0.1 51002 Non-skid footwear is recommended • ALWAYS chock the wheels prior to to maintain proper footing and testing. balance to enable better control in • Use extreme caution when working unexpected situations. around the ignition coil, distributor • DO NOT let comfort or familiarity...

  • Page 6: Diagnostic Trouble Codes (Dtcs)

    51002 V0.1 cannot locate it. NOTE: The DLC on some vehicles may have a plastic cover that will need to be removed before the OBD II Connector can be plugged in. DIAGNOSTIC TROUBLE CODES (DTCs): OBD II Diagnostic Trouble Codes (DTCs) are codes that are stored by the vehicle’s on-board computer diagnostic system in response to a problem found...

  • Page 7: Data Link Connector (Dlc)

    V0.1 51002 General definitions for codes may be found by searching online or in the Code Reader DTC Library. However, because the codes may be specific to the make, model, engine size, and configuration of your vehicle, it is important that you consult with your vehicle’s repair manual for the exact definition of the DTC.
  • Page 8 51002 V0.1 Non-Continuous I/M Monitors, on the other hand, test vehicle components when specific vehicle operating conditions are met. These sensors differ between spark ignition vehicles (gasoline engines) and compression ignition vehicles (diesel engines). Examples of non-continuous monitors are: Spark Ignition...
  • Page 9 V0.1 51002 and Diagnostic Trouble Codes (DTCs), which were captured at the moment when the control unit detected a malfunction. Because sometimes multiple DTCs may have caused the vehicle’s MIL to illuminate, this information may help to identify the initial DTC that caused the malfunction.

  • Page 10: Tool Identification

    51002 V0.1 TOOL IDENTIFICATION Name Description OBD II Connector SAE J1962 Type A Connector to connect to vehicle. LCD Display Displays and indicates test results. UP button Moves Menu and Submenu UP in menu screen. DOWN button Moves Menu and Submenu DOWN in menu screen.

  • Page 11: Navigation Characters

    V0.1 51002 NAVIGATION CHARACTERS Navigation characters are used to help navigate the different screens in the Code Reader: 1. “ “ Cursor to indicate the current selection. 2. “Pd” Identifies a pending Diagnostic Trouble Code (DTC) when viewing DTCs. 3. “$” Identifies the control module from which the data is retrieved.
  • Page 12 51002 V0.1 SETTING THE LANGUAGE: Use the UP/DOWN buttons to move the Cursor to item 1) Language from the System Setup Menu, then press the OK button. SET THE LANGUAGE: Use the UP/DOWN buttons to select a language. Once the desired language...
  • Page 13 V0.1 51002 SETTING THE BACKLIGHT: Use the UP/DOWN buttons to move the Cursor to item 4) Backlight from the System Setup Menu, then press the OK button. Use the UP/Down buttons to adjust, then press the OK button to save and return to the System Setup Menu.

  • Page 14: Operation

    51002 V0.1 OPERATION DO NOT connect or disconnect diagnostic test WARNING equipment to the vehicle with the ignition ON or with the engine Running. Follow these steps to begin use: 1. Ensure the ignition is in the OFF position and the engine is not running.
  • Page 15 V0.1 51002 2. Use the UP/DOWN buttons to select the type of trouble codes to view in the Trouble Codes menu, then press the OK button. 3. View the DTCs and their definitions on the display. NOTE: The control module...
  • Page 16 51002 V0.1 2. A warning message will be displayed asking for confirmation. 3. To stop, use the UP/DOWN buttons to select NO and press OK. “Command Canceled” will be displayed. 4. To proceed with erasing the codes, select YES and press OK to erase.
  • Page 17 V0.1 51002 4. RETRIEVING I/M READINESS STATUS The I/M Readiness Function is an excellent tool to check the operations of the vehicle’s emission system prior to any state emissions compliance testing program. Depending on the vehicle make and model, some vehicles may support two I/M Readiness test types: •...
  • Page 18 51002 V0.1 5. VIEW VEHICLE INFORMATION The Vehicle Information Function enables retrieval of the Vehicle Identification Number (VIN), Calibration ID(s), Calibration Verification Numbers (CVNs), and In-use Performance Tracking on vehicles that support Mode 9, which is normally vehicle model year 2000 and newer.
  • Page 19 V0.1 51002 2. Use the UP/DOWN to view each page. 3. Press the EXIT button to return to the Diagnostic Menu. 7. Viewing Realtime Curves Vehicles that support Mode 1 allow the retrieval of real-time vehicle data which can then be plotted and displayed on a curve.
  • Page 20 51002 V0.1 4. Use the UP/DOWN buttons to button to select the O2 sensor test result then press the OK button to view additional data. 5. Press the EXIT button to return to the Diagnostic Menu. 9. Viewing On-Board Monitor Test The On-Board Mon.
  • Page 21 V0.1 51002 10. Performing the Component Test The Component test is initiated by the Code Reader for the vehicle’s on-board computer to perform a leak test for the vehicles EVAP system. Each vehicle manufacturer has different criteria and methods for stopping the test once it has been initiated.
  • Page 22 51002 V0.1 3. The Battery Measurement feature will display the battery voltage. 4. Press the EXIT button to return to the Battery Test Menu. PERFORM BATTERY MONITORING: 1. Use the UP/DOWN buttons to select Battery Monitoring in the Battery Test Menu and press the OK button.
  • Page 23 V0.1 51002 13. DIAGNOSTIC TROUBLE CODE LOOKUP The DTC Lookup function is used to search for definitions of Diagnostic Trouble Codes (DTCs) stored in the Code Reader’s library which is based on general ISO and SAE Diagnostic Trouble Codes. For exact definitions of DTCs and for manufacturer specific DTCs, refer to the vehicle repair or owner’s manual.

  • Page 24: Care And Maintenance

    51002 V0.1 CARE AND MAINTENANCE 1. This tool is a PRECISION TEST AND MEASURING INSTRUMENT. Take care to operate it correctly as described in this manual. Store the Code Reader in a clean and dry environment. 2. Before connecting and disconnecting the Code Reader from the vehicle, be sure the vehicle engine is shut off, and the ignition is in the OFF position.
  • Page 25 V0.1 51002 NOTES Page 25...
  • Page 26 51002 V0.1 NOTES Page 26...
  • Page 27 51002 V0.1 NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED. BUYER’S OR USER’S REMEDIES ARE SOLELY AND EXCLUSIVELY AS STATED ABOVE. STAR ASIA-USA, LLC SHALL IN NO EVENT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, OR SPECIAL DAMAGES.

  • Page 28: 90-Day Limited Warranty

    51002 V0.1 90 DAY LIMITED WARRANTY Star Asia-USA, LLC (hereinafter “seller”) warrants to the original purchaser only, that this product will be free from defects in material or workmanship for a period of 90 days from date of purchase for home domestic use.
