Suntherm B-02 Series User's Information Manual

Vertical wall mount installation - models w/dx cooling and electric or hydronic (hot water) heating
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
B/S/H-02/03 Series: Vertical Wall Mount Installation - Models w/DX Cooling and Electric or Hydronic (Hot Water)
Heating
1 - General ..................................................................................................................1
2 - Safety .....................................................................................................................2
3 - Owner's Information and Seasonal Information ....................................3
1 - Safety .....................................................................................................................8
2 - Air Handler Maintenance ............................................................................ 12
3 - Air Handler Controls ...................................................................................... 13
4 - Sequence of Operation ................................................................................ 16
5 - Troubleshooting .............................................................................................17
6 - Blower Performance .................................................................................................21
1 - Visual Check Points - B/S-02/03 / Electric Heat ......................................4
2 - Visual Check Points - H-02/03 / Hydronic Heat .....................................4
3 - Front Panel Circuit Breaker Location - B-02/03 ......................................5
8 - Typical 1" Replacement Air Filter .............................................................................7
9 - Blower Assembly ............................................................................................ 13
10 - No Electric Heat Control Box - B/S-02/03 ........................................................ 13
11 - Electric Heat Control Box - B/S-02/03 ............................................................... 13
............................................................................................. 19
5 - Field Installed Accessory List ......................................................................24
Manufactured and Distributed by:
1. Models with electric heat and no heat are rated for 208/240 VAC, 60
Hz, 1-Phase.
2. Models with hydronic heat are rated for 115 VAC, 60 Hz, 1-Phase.
3. Air handler is designed for both cooling only and heat pump
applications.
4. Models are available in small, medium, or large cabinet size.
MORTEX PRODUCTS INC.
501 TERMINAL RD FORT WORTH, TX 76106
USERS INFORMATION MANUAL
LIST OF SECTIONS - USERS INFORMATION MANUAL
LIST OF SECTIONS -SERVICE AND MAINTENANCE MANUAL
......................................... 21
The following list includes important facts and information regarding this air handler.
4 - Startup and Shutdown Instructions .......................................................... 5
5 - Owner Maintenance ........................................................................................ 6
9 - Field Installed Accessories ...........................................................................24
10 - Replcement Parts .......................................................................................... 25
11 - Decommissioning & Disposal of the Air Handler .............................. 29
LIST OF FIGURES
13 - Electric Heater Contactor - B/S-02/03 ....................................................14
14 - Refrigerant Leak Detection Sensor Location .......................................14
15 - Hydronic Heat Control Box - H-02/03 ....................................................14
17 - Hydronic Control Board - H-02/03 ..........................................................15
18 - Constant Torque Motor Terminals ............................................................19
19 - Blower Assembly ............................................................................................20
LIST OF TABLES
19
6 - Replacement Parts List - B/S-02 / Electric Heat ...................................26
..... 19
7 - Replacement Parts List - B/S-03 / Electric Heat ...................................27
8 - Replacement Parts List - H-02 / Hydronic Heat ....................................28
9 - Replacement Parts List - H-03 / Hydronic Heat ....................................29
CONTACT INFORMATION
Mortex Products Inc
501 Terminal Rd
Fort Worth, TX 76106

SECTION 1: GENERAL

5. Air handler is designed for upflow applications only.
6. Air handler must not be operated without the access panel installed.
7. Air handler is listed by ETL for the United States and Canada.
INSTALLERS MUST READ ALL INSTRUCTIONS IN THIS MANUAL
THIS MANUAL MUST BE SAVED BY THE HOMEOWNER OR USER FOR
FUTURE REFERENCE.
www.mortx.com
61BA0071 Rev B
3.8.25
Page 1
