Summary of Contents for FCS Intelligens
- Page 1 Intelligens User Manual This manual contains important safety and operating information. Please read, understand, and follow the instructions in the manual and also any safety / approvals or Intrinsic Safety (ATEX, IECEx or UKEX) Safety Supplement documents shipped with the device.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ............................1 1.1. Documentation and Support of Product ..................1 1.2. Safety Considerations ........................2 1.3. Operating Temperature .......................3 1.4. Use of Cellular networks – Important Notes ................4 1.5. Viewing Data ..........................4 1.6. IDT – Software Tool (for logger programming and tests)............4 1.7. - Page 3 Appendix 4 – Configuration options .................... 48 Appendix 5. - Supplement for discontinued items ..............52 11.1. Pressure Sensor (Internal) ......................52 11.2. Intelligens EXTPRESS (External Pressure Sensor Box) unit ............ 52 11.3. ESIB (External Sensor Interface with Battery) unit ..............53...
-
Page 5: Introduction
Intelligens is designed for use in potentially explosive atmospheres, being an ‘intrinsically safe’ logger device. It is the responsibility of the installer to correctly specify and install the Intelligens in conjunction with other equipment, making the appropriate checks for safety markings and suitability for inter-connection of the equipment. -
Page 6: Safety Considerations
AFETY ONSIDERATIONS The Intelligens is an intrinsically safe logging device, designed for use within potentially explosive atmospheres. When installed in such an environment, Intelligens is required to be connected to other compatible devices that are approved for use within potentially explosive atmospheres. -
Page 7: Operating Temperature
documents, supplied with the main unit and other (optional) units that are part of the logger. These provide additional ATEX-related safety information, including port parameters. Retain all documents for future reference. Before using this product: Make a risk assessment of the installation site and expected work activity. •... -
Page 8: Use Of Cellular Networks - Important Notes
(logger software and IDT software) are able to communicate with each other over a working communications path. IDT is available in two versions. However, the Intelligens logger is compatible with: IDT (for PCs having a Windows-operating system), sometimes referred to as ‘IDT (PC)’. -
Page 9: Cross-Reference: Connector - Circuit Entity
settings and functions. The IDT user-guide provides setup steps and a description / explanation of each setting or control. 1.7. C – C ROSS REFERENCE ONNECTOR IRCUIT NTITY The logger interface descriptions can sometimes differ between the labelling of the connection (see logger labels) and the entity parameters (see the Safety Supplement document). -
Page 10: Overview
& C HYSICAL EATURES ONNECTOR DENTIFICATION The Intelligens logger family is flexible in design Nameplate and can be built to suit a variety of uses. It has a label (front) plastic enclosure and is of a waterproof construction, using seals to keep out water. -
Page 11: Name Variants
Figure 6. Numbered locations are shown in plastic enclosure. 2.1.2. AME VARIANTS The logger can be labelled as one of the following, depending on its build configuration and intended application: Intelligens WW … (see example opposite) • Intelligens GNS • Logger name appears on Intelligens PRS •... -
Page 12: Esi (External Sensor Interface) Unit
2.2. ESI (E XTERNAL ENSOR NTERFACE UNIT The Intelligens logger can be extended with an ‘External Sensor Interface’ unit (see Figure 7). (To provide atmospheric pressure compensation, a breather vent option may be included along with a desiccant Connection to for drying the air). -
Page 13: Esib (External Sensor Interface With Battery) Unit
For other models, which have a part-number beginning with “ESIB/”, refer to section 11 and 11.3. The Intelligens logger can be extended using one or more of the “ESIB” units (External Sensor Interface with Battery). This is a family of devices (see Figure 9) which primarily act as a battery power source. - Page 14 ‘MODBUS INPUT (ESI)’. • Note: Despite the labelling difference, the ‘SDI-12’ and ‘Modbus’ inputs on the Intelligens logger are identical; They are converted to the same digital interface to the logger. For setup purposes, IDT will regard them both as a ‘serial input’.
-
Page 15: Version: 4 ~ 20Ma
Pass-through is Logger connection Logger connection only available on cable cable units with a single (main analogue sensor interface. logger Pass-Through unit) connector Inter-connection is only permitted for (first (second two units with a ESIB unit) ESIB unit) (Interface single analogue connector sensor interface. -
Page 16: Versions: 0 ~ 1V & 0 ~ 10V
This version of ESIB unit has a connector labelled “INPUT, 4-20mA” (or similar). This is suitable for use with an appropriate (and compatible) cabled sensor which uses an industry-standard 4-20mA signalling scheme. The ESIB unit provides power to the sensor from its own internal battery. However, the power is controlled by the main logger unit, which signals to pre-power the sensor a short time before a measurement is needed and deactivate it when not in use. -
Page 17: Version: Sdi-12
in an ATEX environment. (Enquire to your HWM representative if you have any requirements regarding a new type of sensor). 2.3.3. : SDI-12 ERSION This version of ESIB unit plugs into an interface in the main logger labelled “SDI-12 INPUT (ESI)”. Note: The connector on the main logger unit is not SDI-12, but a proprietary multi-purpose interface, sometimes referred to as ‘ESI’. - Page 18 The ESIB unit provides power to the sensor from its own internal battery. However, the power is controlled by the main logger unit, which signals to pre-power the sensor a short time before a measurement is needed and deactivate it when communication with the sensor is completed. Refer to the IDT user-guide and the sensor documentation for guidance on setting the IDT control for sensor pre-power.
-
Page 19: External Battery Pack (Option)
2.4. E XTERNAL ATTERY OPTION Most Intelligens models have a connector that allows an ATEX-approved External Battery to be connected. The battery provides the logger with additional power capacity. An example battery pack is shown in Figure 11. Always use a compatible ATEX Battery Pack supplied by HWM that has been approved for use with the Intelligens logger. -
Page 20: Enhanced Logging (Options)
OGGING OPTIONS Section 2.5 gave a description of logger operation that is available as standard on Intelligens logger models; The logger normally samples data at the set sample period, and records datapoints at the set log period. However, certain models offer options for making additional recordings (of logged data) at higher-than-normal sampling rates. -
Page 21: Server Integration - Storing And Viewing Data
NTEGRATION TORING AND IEWING The Intelligens logger includes an interface (referred to as a modem) that provides access to the internet via the cellular mobile communications network. A SIM card is used to give access to the network. Measurement data is initially stored within the logger, until the next call-in time. The data can then be uploaded to the server using an encrypted format. -
Page 22: Installation Accessories
The DataGate server can also forward any alarms received from the logger to all users that have subscribed to them; one logger alarm message can therefore be distributed to multiple DataGate users. DataGate can also (by arrangement with your sales representative) be used to export logger data to other servers. -
Page 23: Communications Interfaces And Programming Cables
2.9. C OMMUNICATIONS NTERFACES AND ROGRAMMING ABLES To communicate with the Intelligens logger, an ATEX-approved programming cable is required. E.g. part-number COMMS USB/IS or COMMS-Y USB/IS. The in-line COMMS BOX contains safety barrier components. It is required for ATEX compliance. -
Page 24: Logger Activation Process (For First-Time Use)
‘immediately’). Most Intelligens loggers are set to start ‘immediately’ upon having their settings read by IDT and then saved back to the unit. (Refer to the IDT user-guide for the steps required to read the logger program and then to save it back to the unit using the ‘Setup Device’... -
Page 25: Installation
Check that all equipment is suitable for use at the installation site (e.g., ATEX markings). This • must include the main Intelligens logger unit and any additional units that attach to the Intelligens. Check that you have the required sensors and that these are suitable for use at the installation site. -
Page 26: Installing The Logger
o Where required, undertake the setup of any additional options related to the channel. (e.g., Add an initial meter reading, pulse replication setting, sensor calibration; these will be dependent on sensor and logger use). (Refer to the IDT user-guide for guidance regarding any additional settings related to an interface). -
Page 27: Wall-Mounting
4.2.1. MOUNTING The Intelligens logger (main unit) can be secured to a wall using a suitable bracket, an example of which is shown in Figure 15. First secure the bracket to the logger using Holes for two machine screws. Then fasten the bracket fixing the to the wall. -
Page 28: Electrical Connections To The Logger
The wire handle can similarly be used to hang the system on a suitable bracket. Figure 17. An example of Intelligens Flow system, mounted onto a carrier frame. 4.2.2. LECTRICAL CONNECTIONS TO THE LOGGER When making electrical connections to the logger (e.g., attaching a connector for a sensor), ensure... -
Page 29: Factory Settings
The External Sensor Interface is used to connect a compatible cabled pressure sensor to the Intelligens logger. An air-breather option may also be fitted to provide atmospheric pressure compensation (important for lower range transducers). Both pressure and depth versions are available (refer to Figure 7 and Figure 8). -
Page 30: Flow Sensor Input (Meter Pulse Collection)
Your logger must have the correct interface and settings for the signalling from the meter to be compatible with it. The Intelligens logger requires two Flow input signals in order to work with the meter-pulse signalling of certain meters. A pair of inputs can therefore sometimes be configured to work together to operate as a single channel. - Page 31 (open = forward flow, closed = reverse flow). This differs from (2) in that two output channels (datapoint streams) are produced. One records the forward flow. The other records the reverse flow. The Intelligens can be fitted with up to 2 input pulse (flow) signal pairs. MAN-142-0001-P...
-
Page 32: Via A Logger 7-Pin Bulkhead Connector
ULKHEAD ONNECTOR Intelligens Flow signal inputs are presented on a 7-pin connector, which may also be used for the IDT/programming cable (shared connector use). Each connector has two pairs of Flow signal inputs. The pinout of this connector is shown below:... -
Page 33: Status Inputs
Connections: Blue Flow / Pulse / Status - Digital Input1 Yellow Flow / Pulse / Status - Digital Input2 Violet Flow / Pulse / Status - Digital Input3 Brown Flow / Pulse / Status - Digital Input4 Green Ground Note: When used in an ATEX environment, approved Intrinsically safe installation methods/equipment need to be used for making these connections and the work should only carried out by an ATEX / Intrinsic Safety trained installer. -
Page 34: Outputs (Digital Switch: Open/Closed)
4.6. O UTPUTS IGITAL SWITCH OPEN CLOSED Intelligens Outputs are presented on a 3-pin connector. Up to two outputs can be supported. The pinout of the connector is shown below: Logger bulkhead connector pinout : 3-pin Outputs Signal Output 1 Output 2 The logger does not supply any power to the output. -
Page 35: Combined Flow Input / Pulse Replication Output On Rj11 Connectors
RTD_SENS - When the temperature sensor is ordered from HWM along with the logger, the sensor will have the correct connector fitted for the Intelligens logger. The logger input will also be factory calibrated for use with the supplied sensor. -
Page 36: Radarsens (Distance / Depth Sensor Using Ultrasound)
Refer to the SonicSens-3 user-guide (MAN-153-0001) for instructions on how to install and setup the sensor for operation. Note: This input is multi-purpose. If enabled, your setup tool may include facilities to change the logger input to an alternative sensor type. (e.g. SonicSens to RadarSens). 4.10. -
Page 37: Esib Unit: 0~1V And 0~10V Versions
Sensor -ve A wide variety of sensors are available with this interface. When ordered from HWM, the sensor will have the correct connector fitted for the Intelligens logger. IDT gives access to controls to set the amount of time the sensor has power applied prior to and during measurement. -
Page 38: Serial Input (Sdi-12) / Esib Unit
(Link together for 2-wire sensors) A wide variety of sensors are available with this interface. When ordered from HWM, the sensor will have the correct connector fitted for the Intelligens logger. IDT gives access to controls to set the amount of time the sensor has power applied prior to and during measurement. -
Page 39: Serial Input (Rs485 / Modbus) / Esib Unit
A wide variety of sensors are available with this interface. When ordered from HWM, the sensor will have the correct connector fitted for the Intelligens logger. In addition, the sensor type will have been tested with the logger to confirm compatibility for use to obtain certain measurements. - Page 40 A wide variety of sensors are available with this interface. When ordered from HWM, the sensor will have the correct connector fitted for the Intelligens logger. In addition, the sensor type will have been tested with the logger to confirm compatibility for use to obtain certain measurements.
-
Page 41: External Battery
(if required). Only use HWM-provided antenna with your logger, to ensure the radio interface meets approvals requirements (safety, etc). 4.15.1. ONNECTING THE ANTENNA Intelligens has two alternative antenna connector types: Antenna (plastic “Bulgin” style connector shell). • Antenna (metal “FME” style connector). -
Page 42: Antenna Type, Placement And Cable Checks
When using the metal “FME” style antenna connector, some additional preparation is needed. Prior to connecting the antenna, ensure that Apply a small the connector is dry and clear of dirt and debris; quantity of trapped moisture or contaminants can impair WRAS approved silicon grease the antenna performance. -
Page 43: Positioning And Testing The Antenna
Some general advice is given below: Monopole Antenna For most installations, a monopole antenna will give acceptable performance. Installation Considerations: Always comply with any installation restrictions as per warnings in the • documentation supplied. The antenna has a magnetic base to be used for mounting. •... - Page 44 Initially this test should be done with an open chamber. This is to verify that the connection to the mobile network works, and to determine the signal levels in a ‘best case’ situation. Then, with the test still running, close the chamber. The values will degrade due to the lid of the chamber reducing the strength of the received signal.
-
Page 45: Making A Call Test Test Internet Data Network
RSRQ value: The following guidelines are given for the cellular network signal, (as measured with the chamber closed): ██ > -9 Good. (Data transmission should be reliable). ██ -10 to -12 Fair. (Data transmission should be reasonably reliable). It is important to select the correct antenna and install it in the most suitable location). -
Page 46: Maintenance, Service And Repair
5. M AINTENANCE ERVICE AND EPAIR Unauthorised servicing will void the warranty and any potential liability for HWM-Water Ltd. 5.1. C LEANING Note the safety warnings that are applicable to cleaning. The unit should only be cleaned using a mild cleaning solution and a damp soft cloth. Always keep connectors free of dirt and moisture. 5.2. -
Page 47: Return Of Product
When returning product for investigation or repair, be sure to follow the instructions of your distributor to document why the product is being returned and provide contact details. If returning to FCS, this can be done by completing the on-line RMA (Return Materials Authorisation) form: https://www.fluidconservation.com/support/#submit-an-rma... -
Page 48: Troubleshooting
6. T ROUBLESHOOTING Any issues should consider all parts of the system (IDT, the user, the logger, sensors, the cellular network, and the server). General checks: Initial checks to be made during a site visit include: Check that the latest version of IDT is being used. •... -
Page 49: Appendix 1 - Battery Replacement (Internal)
7. A 1 – B PPENDIX ATTERY EPLACEMENT NTERNAL Warning: ALWAYS USE BATTERY PACK INTBATTPACK/7V2/H95 AND NEVER OPEN THE UNIT IN AN EXPLOSIVE GAS ENVIRONMENT 1) Remove the lid, taking care not to damage the seal. Then lift out the battery Do not damage the seal... -
Page 50: Appendix 2 - Fitting Your Own Sim Card
8. A 2 – F PPENDIX ITTING YOUR OWN CARD Warning: DO NOT OPEN WHEN EXPLOSIVE ATMOSPHERE IS PRESENT. DISCONNECT THE BATTERY BEFORE REMOVING OR INSERTING A SIM CARD 1) Remove the lid of the logger, taking care not to damage the seal. Do not damage the seal... -
Page 51: Appendix 3 - Technical Specifications
9. A 3 – T PPENDIX ECHNICAL SPECIFICATIONS (For Technical Specifications, please refer to the product datasheet) MAN-142-0001-P... -
Page 52: Appendix 4 - Configuration Options
10. A 4 – C PPENDIX ONFIGURATION OPTIONS Data logger physical port positions Part Number make-up – H95/xxxxxxx/xxxxxx/IS /xxxxxxx /xxxxxx HWM Logger Type No Antenna, Communications & Input/Output Modem opt Safety Designation Channel Configuration (See tables below) (See table) Input Channel Type Matrix (/xxxxxxx/xxxxxx) Select the channel types required from the table below and build the number based on your required case positions in the order –... - Page 53 Example part number: ESI2/21-10/IS 350mBar Depth Transducer 10m length. Note: The External Sensor Interface must only be used with the Intelligens / COMLog™IS data logger, HWM Part number H95/xxxxxxx/xxxxxx/IS which must include a type 3 entry in the part number. MAN-142-0001-P...
- Page 54 5. The External Sensor Interface must only be used with the Intelligens / COMLog™IS data logger, HWM Part number H95/xxxxxxx/xxxxxx/IS. 6. The use of voltage / 4-20mA variants requires the Intelligens / COMLog™IS data logger to be equipped with option ‘3’ from the ‘other logger connections’ options.
- Page 55 4. The External Sensor Interface must only be used with the Intelligens / COMLog™IS data logger, HWM Part number H95/xxxxxxx/xxxxxx/IS. 5. The use of SDI-12 variants requires the Intelligens / COMLog™IS data logger to be equipped with options Q from the ‘other logger connections’ options.
-
Page 56: Appendix 5. - Supplement For Discontinued Items
IDT Ref: Pressure 3 input The transducers are factory calibrated, with calibration values Position 2 IDT Ref: Pressure 4 input stored in the EXTPRESS unit. No on-site calibration is required. Figure 25. Intelligens External Pressure Sensor Box unit MAN-142-0001-P... -
Page 57: Esib (External Sensor Interface With Battery) Unit
Pressure Transducer (20Bar) Pressure Transducer (35Bar) Pressure Transducer (70Bar) Note: The External Sensor Interface must only be used with the Intelligens / COMLog™IS data logger, Part number H95/xxxxxxx/xxxxxx/IS which must include a type 3 entry in the part number. 11.3. ESIB (E... - Page 58 Fluid Conservation Systems 1960 Old Gatesburg Road Suite 150 State College PA, 16803 (800) 531-5465 www.fluidconservation.com MAN-142-0001-P...
