- Page 1 USER MANUAL SPARTAN SR5-CX Lumen Dual Flash (Strobe White LED flash) Digital Camera Trap PLEASE READ CAREFULLY BEFORE USING YOUR CAMERA. Product specifications and data are subject to change without notice to improve reliability, function or design.
-
Page 2: Camera Diagram
Package Contents Mounting Strap Camera Trap User Manual CAMERA DIAGRAM... -
Page 4: Things You Need
THINGS YOU NEED • Micro-SD card, up to 64 GB ((not included)) • 6 x AA size batteries ((not included) Lithium ((recommended) Alkaline Rechargeable Li-ion 1.5v5v) • 12V external SLA / Lithium rechargeable battery and connection cable OR 12V solar panel (not included) BBUTTONS : Menu: Enter the program menu in preview mode, exit from settings... -
Page 5: Quick Setup
QUICK SETUP 1. Load batteries a. Press the Battery Tray Eject button to release the battery tray then pull it out so you can load the batteries. b. Insert each battery and make sure its polarity matches the indicators on the bottom of the battery tray. - Page 6 Set up the camera a. Slide the power switch to the ON position, set the date and time, then press the Menu button to exit. b. Set the Camera, Trigger, and System options as desired. c. Format the microSD card (System menu). Mount, Test and ARM the camera a.
- Page 7 PHOTO INFO STRIP Camera Name Tag Photo Trigger Indicator, indicating what type of event caused the photo to be taken. M = = Motion E = = Scheduled event or manual photo T = = Time-lapse Date & Time Moon phase Temperature Power Level = Full...
-
Page 8: Menu Settings
MENU SETTINGS 1. Switch the camera ON. 2. Navigate the main menu or setting choices using the (up and down) buttons. 3. Press the OK button to select a setting or the (Menu) button to exit and return to ... - Page 9 * Default Settings Menu Setting Description Sensitivity High, *Normal / Low / Off. The 'sleep' time after each trigger i.e. the time delay between when a motion triggered pic/clip is Trigger Interval taken and the next pic/clip can be triggered. Options:: *0-55 sec in 5 sec intervals, 1-60 min in 1 min intervals *All Day / Pan1 / Plan2.
- Page 10 * Default Settings Menu Setting Description Clock Set the Hour, Minute, Month, Day, Year *On, Off. Select ON to print an info strip at the Time Stamp bottom of each photo, OFF for no info strip. Set a 4-digit password using this option. (Note: keep a record of this password.
-
Page 11: Viewing And Deleting Photos And Videos
VIEWING AND DELETING PHOTOS AND VIDEOS Viewing Photos 1. Highlight Playback then press the OK button. 2. Press the (up and down) buttons to navigate through the pictures / videos. 3. To return to the Home screen without deleting any photos / videos, press the (Menu) ... -
Page 12: Export Settings
EXPORT SETTINGS Exporting the settings 1. In the System menu, highlight Export Settings then press the OK button to save a file called 'settings.ini' to the micro-SD card. Using the exported settings in a new camera 1. Once you have saved / copied the 'settings.ini' file from one camera onto a micro- SD card, insert this micro-SD card into the new camera. -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS FOV (Field of View) 75° wide angle Strobe / Xenon (used for photos / White LED (used for video clips) Flash Type Display 2'' IPS colour LCD, 480x240mm)- Front-facing display Memory Card Micro-SD, up to 64Gb Strobe / Xenon flash, full colour (with auto-adjustable flash power feature) Night-time Image Flashh White LED flash, full colour (with auto-adjustable flash power feature) Night-time Video Flash... -
Page 14: Fcc Compliance Statements
FCC COMPLIANCE STATEMENTS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. The device may not cause harmful interference 2. The device must accept any interference received, including interference that may cause undesired operation. -
Page 15: Warranty
POLICIES The latest terms and privacy policy are available at spartancamera.com • Terms and Conditions: spartancamera.com/pages/terms-and-conditions • Privacy Policy: spartancamera.com/pages/privacy-policy WARRANTY • Spartan cameras come with a 1 year manufacturer limited warranty plus an additional 1 year extended warranty upon registration. •...
