- Page 1 MODEL MITSW 28EC INSTALLATION OPERATION MANUAL Pac age T e Wa In e e Hea...
- Page 2 OWNER’S MANUAL Packaged Thru-The-Wall Heat Pump ALWAYS MAKE SURE THAT THIS MANUAL REMAINS WITH THE ODESSEY PACKAGED THRU-THE-WALL HEAT PUMP OR OWNER OF THE PRODUCT. READ THIS MANUAL BEFORE INSTALLING, OPERATING, OR PERFORMING MAINTENANCE ON THE ODESSEY PACKAGED ROOM AIR HEATPUMP UNIT.
-
Page 3: Table Of Contents
OWNER’S MANUAL Packaged Thru-The-Wall Heat Pump INDEX ODESSEY PACKAGED THRU-THE-WALL HEAT PUMP UNIT PAGE INTRODUCTION SAFETY INSTRUCTIONS RECEIVING THE GOODS HANDLING LIST OF ACCESSORIES TECHNICAL FEATURES POSITIONING THE UNIT INSTALLATION TEMPLATE DRILLING THE WALL FASTENING THE BRACKET INSTALLATION OF THE PIPES FITTING THE GRATINGS FITTING THE UNIT ON THE BRACKET INTRODUCTION OF LCD ICONS... -
Page 4: General Information
OWNER’S MANUAL Packaged Thru-The-Wall Heat Pump Do not operate any product with a damaged 1. GENERAL INFORMATION cord or plug, or after the unit malfunctions, 1.1 INTRODUCTION has been dropped, or damaged in any Do not dispose of any packaging until manner. - Page 5 Packaged Thru-The-Wall Heat Pump OWNER’S MANUAL The appliance is not accessible to general public. industry recognised assessment specification. Servicing shall only be performed as This appliance can be used by children aged recommended by the equipment manufacturer. from 8 years and above and persons with reduced Maintenance and repair requiring the assistance physical, sensory or mental capabilities or lack of of other skilled personnel shall be carried out...
- Page 6 Packaged Thru-The-Wall Heat Pump OWNER’S MANUAL parties are advised. installation, repairing, removing and disposal, Initial safety checks shall include: during which flammable refrigerant can possibly that capacitors are discharged: this shall be be released to the surrounding space. Prior to done in a safe manner to avoid possibility of work taking place, the area around the sparking;that no live electrical components...
- Page 7 Packaged Thru-The-Wall Heat Pump OWNER’S MANUAL several times. such as compressors or fans. Compressed air or oxygen shall not be used for this task. Detection of flammable refrigerants: Flushing shall be achieved by breaking the Under no circumstances shall potential vacuum in the system with OFN and continuing sources of ignition be used in the searching to fill until the working pressure is achieved,...
- Page 8 Packaged Thru-The-Wall Heat Pump OWNER’S MANUAL • all personal protective equipment is properly maintained and available and being used correctly; that any associated electrical components • the recovery process is supervised at all are sealed to prevent ignition in the event of times by a competent person;...
-
Page 9: Receiving The Goods
OWNER’S MANUAL Packaged Thru-The-Wall Heat Pump 1. FASTENING BRACKET 1.3 RECEIVING THE GOODS The unit is delivered in a protective packaging and 2. REMOTE CONTROL is accompanied by an instruction manual. This 3. REMOTE CONTROL HOLDER manual is an integral part of the unit and should 4. -
Page 10: Technical Features
Packaged Thru-The- all Heat Pump OWNER S MANUAL 1.6 TECHNICAL FEATURES P1 P2 MITS -2 EC 1Bth/h, 2 0 5Bth/h, 2 1 2 Bth/h, 2000 2 Bth/h, 2000 1 .1 25 CFM / 0 m /h 1 . o / 70 g ALL PERFORMANCE DATA AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE STANDRD TEST OPERATING CONDITIONS IN COOLING AND DEHUMIDIFICATION MODE Inside 0.0 F DB;... -
Page 11: Positioning The Unit
2. INSTALLATION 2.2 PAPER TEMPLATE P4 2.1 POSITIONING THE UNIT P3 Niveau 7 .7 7 .7 Fasten the template to the wall once the following guidelines have been checked. Do not drill any holes until you are To maintain the best performance from your completely confident that there are no unit and to prevent breakdowns or ha ards, obstacles in the area you wish to drill... -
Page 12: Fastening The Bracket
named “A” and the other one is horizontal to Fasten the template to the wall taking care the floor which is named “B” as shown in P6. to check the distance from the floor or ceiling. Method “A”: Employing this method allows Keep it horizontal by using a level. -
Page 13: Installation Of The Pipes
2.6 FITTING THE GRATINGS AND THE METAL to maintain the intended installation of the unit GRILLE (P9, P10, P11, P12) - CONT’D to the wall. The manufacture is not liable in case of underestimation of the structural consistency of the anchorage made at the time of installation. 2.5 INSTALLATION OF THE PIPES (P8) After drilling the holes, the plastic sheet supplied with the air conditioner need to... -
Page 14: Fitting The Unit On The Bracket
2.7 FITTING THE UNIT ON THE RACKET P13 P14 The unit shall not be installed inside a laundry room. LIFT IT UP LIFT IT UP The unit must be positioned so that the plug HERE HERE is accessible. The unit shall be installed in accordance with the National Electrical Code N.E.C. -
Page 15: Introduction Of Lcd Icons
3. USE AND MAINTENANCE 3.1 INTRODUCTION OF LCD ICONS Icons Meaning Icons Meaning Airflow Auto direction Cooling Fan speed Sleep MODE Auto fan FAN- FAN+ HEATER SLEEP Heating Temp CLOCK TIMER C / F LOCK LIGHT Light Clock (optional only) Heater Timer (optional only) -
Page 16: Standard Heating Mode
3.3 Heating mode Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. Press the MODE button, set up the mode to heat " ", the air conditioner will run in heating. Press UP "... -
Page 17: Super Heating Mode
3.4 Super heating mode: Allows the electric heater to run in addition to the heat pump when additional heat is needed. particularly when outdoor temperature are blew 5 C. Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. -
Page 18: Cooling Mode
3.5 Cooling mode Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. Press the MODE button, set up the mode to cool " " , the air conditioner will run in cooling. Press UP "... -
Page 19: Dry Mode
3.6 Dry mode: Allows the unit to dehumidify and remove moisture in the air within the area the unit is installed. Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. Press the MODE button, set up the mode to dry "... -
Page 20: Sleep Mode
3.8 Sleep mode: The sleep mode changes the set temperature of the unit over time while you sleep to provide optimal comfort in an ef fort to match the body’s natural temperature changes during sleep. To activate sleep mode, simply press the sleep button. In the sleep mode, the set temperature of the unit will either increase in cooling mode or decrease in heating mode by 1 degree after an hour, then by another degree an hour later. -
Page 21: Auto Mode
3.9 Auto mode: The unit will automatically adjust its operation according to the room temperature. Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. Press the MODE button, set up the mode to auto "... -
Page 22: Timer Off Function
Timers can be used to turn the unit off or on when not needed, such as when you are not at home. 3.10 Timer off function Sequence of the operations Press the ON/OFF button " ", switch on the air conditioner, it will run by memory mode. -
Page 23: On Board Control Function
3.12 On board control function 1) Running LED: When lit indicates that the compressor is running 2) On/Of button: Turns the unit on/of 3) Mode button: Allows you to select the desired mode - heating/cooling/dry/auto 4) Cooling LED: When lit indicates the unit is running cooling mode 5) Heating LED: When lit indicates the unit is running heating mode 6) Super Heating Mode button: Switches ON/OFF Super Heating Mode 7) Super Heating Mode LED: When lit indicates the Super Heating Mode is ON or OFF. -
Page 24: 2000W Electric Heater Function (Look Like Speakers)
3.13 2000W Electric Heater Function 3.13.1 Heating Mode 1 (Heat Pump + Electric Heater Function) as the default setting. 1. When entering Heating Mode, the Electric Heater signal (from remote controller, or on-board-control, or Wi-Fi APP) is not switched, the electric heater function is executed automatically: The Electric Heater automatic opening requires all of the following conditions to be met: a. - Page 25 "HE" for 5 seconds, then extinguished, and the buzzer will beep twice, disable the Only Electric Heater Operation function. In Heating Model after the device is turned on, the Heating Mode 1 (Heat Pump + Electric Heater Function) will be ef fected.
-
Page 26: Wi-Fi App & Network Installation Guide
The operation of the Door/Window Mode function: 1. The set temperature for the Door/Window Mode is 18 °C (i.e. 65°F 2. The display is on automatically and remain to show “ EC ”. III. Exit of the Door/Window Mode function in Cooling or Heating Mode: After receiving any control signal from the remote controller, the on-board-control, or Wi-Fi APP, the Door/Window Mode function is exited, MODE... - Page 27 2. Open the APP, register an account and log in 3. Long press the power on/of button on-board-command panel for 5S, then release the button, and wait until the Wi-Fi indicator blinks in the display to start the network distribution operation This Wi-Fi indicator blinks...
- Page 28 4. Turn on Bluetooth of the device, on the APP interface, tap "+, Add Device". 4. Turn on Bluetooth of the device, on the APP interface, tap "+, Add Device". 5. According to the APP wizard, enable the required permissions and connect the device to the network. After the connection is successful, the Wi-Fi indicator keeps on;...
-
Page 29: Installing And Changing The Batteries
Packaged Thru-The-Wall Heat Pump Note: If you want to reconnect other devices after the network is successfully connected, long press the power on/off button for 5S when the Wi-Fi indicator keeps on, then release the button. When the indicator changes to blink, the network can be re-connected. -
Page 30: Fresh Air System
3.17 F es ai s s e 1. 7 Fresh air pipe Fresh air filter Fresh air system There is fresh air system in the back of the unit. The air conditioner will change the room air automatically with air from outdoors entering the room. The lter should be clean regularly to maintain the fresh air ow. -
Page 31: Trouble Shooting
ACTIVATED CARBON FILTER (P19) POSSIBLE SOLUTIONS 1. Check the Timer settings to ensure the unit is not programmed to be of /on. 2. Ensure that there is power to the unit and the power cord is not damaged. 3. The filter could be dirty. Clean the filter. 4. -
Page 32: Installation Template For Wall Drilling
Back Unit Height 19.5" Front Fascia Total Height 23" 4" Clearance left...
