- Page 1 APS 5 Battery Pack Manual...
-
Page 2: Table Of Contents
Content Specifications Description Package Contents Precautions Recommendations for Battery Use Battery Charging Legal Compliances and Disclaimers... -
Page 3: Specifications
Specifications APS 5 Model APS 5 79181 Type Li-ion Nominal capacity at +22°С 4900 mAh (72°F) Rated voltage 3.7 V Charge/discharge cycles, minimum* Charge/discharge ambient 0°С...+35°С/-25°С...+50°С temperature (+32°F…+95°F/-13°F…+122°F) 84 × 25 × 25 mm Dimensions (3.3 × 1 × 1 inches) Weight 0.08 kg (2.9 oz) * Once reached the specified limit, the battery capacity may drop to 80%. -
Page 5: Description
Description APS 5 rechargeable lithium-ion power supplies are designed for use with Pulsar thermal imaging devices. APS 5 batteries support USB Power Delivery fast charging technology when using a standard charging set (charger, USB Type-C cable, power adapter). The rechargeable battery can be used separately or with a battery-locking... -
Page 6: Package Contents
Package Contents APS 5 battery APS 5 battery-locking cover Operating Manual Warranty card... -
Page 7: Precautions
Precautions Always use the APS 5 charger supplied with the device (or purchased separately) to charge APS 5 batteries. Using the unsuitable charger can cause irreparable damage to the battery and fire. Do not charge the battery immediately after brining it from cold to warm. Wait at least 30 minutes for the battery to warm up. -
Page 8: Recommendations For Battery Use
Recommendations for Battery Use The battery should be partially charged for long-term storage – 50 to 80 The battery should be charged at an ambient temperature of 0°C…+35°C (+32°F…+95°F). Otherwise, lifespan of the battery will decrease significantly. When using the battery at sub-zero temperatures, the battery capacity decreases, this is normal and not a defect. -
Page 9: Battery Charging
Battery Charging 1. Insert the battery (1) along the guide to the stop into the APS 5* charger slot (4) (see. Fig.). 2. Connect the plug of the USB Type-C cable* (7) to the USB Type-C connector of the power adapter*(3). Plug the power adapter (3) into a socket 100-240 V (110 V for US) (6). - Page 10 designed for it. LED indication (2) in the Battery Level battery charging mode Battery charge level is from 0% to 25% Battery charge level is from 26% to 50% Battery charge level is from 51% to 80% Battery charge level is from 81% to 99% Battery is fully charged.
- Page 11 Defective battery. Do not use the battery! Attention! When using a power adapter that does not support USB Power Delivery fast charging technology, the flicker frequency of LED indicators is reduced by 3 times. Attention! The charger heats up during fast charging. Excess heat is removed through the radiator and does not affect the device operation.
-
Page 12: Legal Compliances And Disclaimers
MANUFACTURER WILL NOT BE LIABLE FOR LOST REVENUES OR INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY, OR PUNITIVE DAMAGES, EVEN IF THE MANUFACTURER KNEW OR SHOULD HAVE KNOWN THAT SUCH DAMAGES WERE POSSIBLE AND EVEN IF DIRECT DAMAGES DO NOT SATISFY A REMEDY. For technical support please contact support@pulsar-vision.com. - Page 13 Answers to frequently asked questions about the devices can also be found in the section.
