COLOUR TELEVISION
INSTRUCTIONS
Thank you for buying this JVC
colour television.
To make sure you understand how to
use your new TV, please read this
manual thoroughly before you begin.
AV-21W93
AV-25L93
AV-29W93
AV-21W93B
AV-25L93B
AV-29W93B
LCT1173-001A-H
0802-NIC-JET
Contents
3 Connecting the aerial and VCR .................. 4
4 Connecting other devices .......................... 5
6 Initial setting ............................................... 6
ECO SENSOR button ..................................... 8
PICTURE MODE button ................................. 8
COLOUR SYSTEM button ............................. 8
SOUND SYSTEM button ............................... 8
button ............................................. 9
BASS button .................................................. 9
MUTING button ............................................. 9
DISPLAY button ............................................. 9
OFF TIMER button ......................................... 9
RETURN + button ........................................ 10
CHANNEL SCAN button .............................. 10
CINEMA SURROUND button ...................... 10
Basic operation ............................................ 11
INPUT ........................................................... 12
PICTURE TILT ............................................... 12
VNR ............................................................... 12
COMPRESS (16:9) ........................................ 12
AUTO SHUTOFF .......................................... 13
CHILD LOCK ................................................. 13
BLUE BACK .................................................. 13
VIDEO-2 SET ................................................ 14
Picture Adjustments .................................... 14
Sound Adjustments ..................................... 14
AI VOLUME .................................................. 15
AUTO CH PRESET ....................................... 15
MANUAL CH PRESET .................................. 16
SKIP .............................................................. 17
LANGUAGE .................................................. 17
© 2002 VICTOR COMPANY OF JAPAN, LIMITED
2
3
7
8
11
19
21
22
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV-21W93 and is the answer not in the manual?

Questions and answers

Related Manuals for JVC AV-21W93

Summary of Contents for JVC AV-21W93

  • Page 1: Table Of Contents

    INSTRUCTIONS 2 Insert the batteries into the remote control ... 3 3 Connecting the aerial and VCR ....4 Thank you for buying this JVC 4 Connecting other devices ......5 colour television. 5 Connect the power cord to the AC outlet ... 5 To make sure you understand how to 6 Initial setting ..........

  • Page 2: Safety Precautions

    Safety precautions WARNING • To prevent fire or shock hazard, do not expose the TV to rain or moisture. CAUTION • Operate only from the power source indicated on the rear of the TV. • Avoid damaging the power cord and mains plug. When you unplug the TV, pull it out by the mains plug.

  • Page 3: Preparation

    Preparation 1 Confirm which remote control you have Your TV comes with one of the four remote controls shown below. Functions you can operate differ depending on the type of remote control. <RM-C1011> <RM-C1012> POWER POWER MUTING MUTING BASS SYSTEM CINEMA SYSTEM CINEMA...

  • Page 4: Connecting The Aerial And Vcr

    Preparation 3 Connecting the aerial and VCR • Read the manuals provided with the devices. Depending on the device, the connection method may be different from the diagrams. Also the device settings may need to change depending on the connection method. •...

  • Page 5: Connecting Other Devices

    Preparation 4 Connecting other devices If you are not connecting any other devices, skip step 3 and perform step 4. • Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off. •...

  • Page 6: Initial Setting

    Preparation 6 Initial setting When the TV is first turned on, it enters the initial setting mode, and the JVC logo is displayed. Follow the instructions on the on-screen display to perform the initial settings. 1 Press the Main power button on the TV.

  • Page 7: Basic Operation

    Basic operation 1 Press the POWER button to turn • The illustration below is for the remote control RM-C1012 supplied with W93B and L93B series your TV on. models. Your remote control may not look ex- • If your TV does not turn on, press the Main actly like the illustrations.

  • Page 8: Remote Control Buttons And Functions

    Remote control buttons and functions ECO SENSOR button COLOUR SYSTEM button You can adjust this TV so that the screen If the picture is not clear or no colour automatically adjusts to the optimum appears, change the current colour system contrast according to the brightness of your to another colour system.

  • Page 9: Button

    Remote control buttons and functions button MUTING button You can select a sound setting for stereo You can turn the sound off instantly. broadcast programmes and bilingual Press this button. programmes. To turn the sound on, press this button Press this button to select a sound again.

  • Page 10: Return + Button

    Remote control buttons and functions RETURN + button CHANNEL SCAN button You can set a channel you frequently view You can quickly view all TV channels to the Return Channel and you can view programmes that you can view on your TV, that channel at any time with one-touch.

  • Page 11: Using The Tv's Menus

    Using the TV’s menus This TV has a number of functions you can operate using the menus. To use all your TV’s functions fully, you need to understand how to use the menus. 4 Press the MENU buttons to SYSTEM CINEMA change function settings.

  • Page 12: Input

    Using the TV’s menus INPUT You can view images from VCRs or other You can reduce picture noise. devices connected to your TV. 1 Press MENU T to display the 1 Press MENU T to display the “MENU 1” menu, then select “MENU 1”...

  • Page 13: Auto Shutoff

    Using the TV’s menus AUTO SHUTOFF BLUE BACK You can set your TV to turn off if no signals You can mute the sound and change the are received for about 15 minutes or longer picture into a blue screen while no signals after the end of a broadcast.

  • Page 14: Video-2 Set

    Using the TV’s menus VIDEO-2 SET Picture Adjustments Set the VIDEO-2 SET correctly according to You can adjust the picture as you like. the video signal input from the external 1 Press MENU T to display the device connected to the VIDEO-2 terminal. “MENU 4”...

  • Page 15: Ai Volume

    Using the TV’s menus AI VOLUME AUTO CH PRESET You can prevent the sudden increase or You can automatically preset all TV channels decrease of volume that occurs when that can be received by your TV to channels. changing channels or switching VIDEO 1 Press MENU T to display the modes.

  • Page 16: Manual Ch Preset

    Using the TV’s menus If the picture is not clear: MANUAL CH PRESET Fine-tune the TV channel. You can manually preset desired TV channels to desired channels. 1 Press MENU t to select “FINE”. 1 Press MENU T to display the MANUAL FINE “MENU 3”...

  • Page 17: Skip

    Using the TV’s menus SKIP LANGUAGE You can set undesired channels to be You can select the language for the on-screen skipped. Channels set to be skipped cannot display. be selected by the CHANNEL m buttons 1 Press MENU T to display the nor the CHANNEL SCAN button.

  • Page 18: Attaching The Twin Port Bass Blaster Unit

    Attaching the Twin Port Bass Blaster Unit <AV-21W93B/AV-25L93B/AV-29W93B only> The Twin Port Bass Blaster Unit is packaged together with the TV. Before you use the TV, mount the Twin Port Bass Blaster unit correctly on the TV. Note: • The BASS functions do not work unless the Twin Port Bass Blaster Unit is connected correctly to the TV.

  • Page 19: Tv Buttons And Parts

    TV buttons and parts Front <AV-29W93/AV-29W93B> L/MONO IN (VIDEO-3) <AV-25L93/AV-25L93B> <AV-21W93/AV-21W93B> POWER MENU CHANNEL VOLUME L/MONO EXIT IN (VIDEO-3) 1 Headphone jack 6 TV/VIDEO button 2 VIDEO-3 terminal 7 ECO sensor 3 MENU button 8 Remote control sensor 4 CHANNEL m buttons...
  • Page 20 TV buttons and parts Rear COMPONENT VIDEO-1 ( VIDEO-2 ) OUTPUT INPUT INPUT MONO MONO 3 OUTPUT terminal 1 VIDEO-1 INPUT terminal 4 Aerial socket 2 COMPONENT (VIDEO-2) INPUT terminal...

  • Page 21: Using The Buttons On The Tv

    Using the buttons on the TV Basic operation Operating menus • Check to make sure the CHILD LOCK function You can operate functions in menus using is set to “OFF”. When the CHILD LOCK function the front control buttons on the TV. is set to “ON”, the TV cannot be operated using 1 Press MENU y to display a menu.

  • Page 22: Troubleshooting

    Troubleshooting If there is no picture or the TV does not operate normally, make sure the problem isn’t due to the reasons indicated below. If the problem persists even after taking the measures indicated, please contact a service technician. Cannot turn the TV on Poor picture •...

  • Page 23: Specifications

    Specifications TV RF systems B, G, I, D, K, K1, M Colour systems PAL, SECAM, NTSC 3.58 MHz/NTSC 4.43 MHz Channel and frequencies VHF low channel (VL), VHF high channel (VH), UHF channel (U) Receives cable channels in mid band, super band and hyper band. External input / output VIDEO-1: VIDEO input, AUDIO L/R input...
