Acrel ACR10R Use And Installation Manual

Rail-type multi-function electrical instrument with external split core current transformer
Hide thumbs Also See for ACR10R:
Table of Contents

Advertisement

Quick Links

Download this manual
`
474
ACR10R Rail-type Multi-function Electrical
Instrument with External Split Core Current
Transformer
Use and Installation Manual V1.2
Acrel Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACR10R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acrel ACR10R

Summary of Contents for Acrel ACR10R

  • Page 1 ACR10R Rail-type Multi-function Electrical Instrument with External Split Core Current Transformer Use and Installation Manual V1.2 Acrel Co., Ltd.
  • Page 2 Announcement Please read the manual carefully before using the product. The pictures, marks and symbol in the manual belong to Acrel. The manual or part of it shall not be publicly reprinted by people outside the company without written authorization.

  • Page 3: Table Of Contents

    Content 1． Overview ..................................1 2．Product specification ..............................1 3．Product Function ................................1 4．Technical Parameters ..............................2 5．Installation ..................................3 5.1 Overall and Installation Dimensions (Unit: mm) ....................3 5.2 Open Current Transformer’s Dimension (Unit: mm) ..................4 5.3 Installation Method ..............................4 5.4 Connection Mode ..............................4 6．Programming and Use ..............................

  • Page 4: 1． Overview

    It is very suitable for real-time power monitoring system with an LCD display and the panel buttons to realize the setting and control of parameters. 2．Product specification 3．Product Function Model ACR10R-(DxxT)E4S ACR10R-(DxxT)ES Function ACR10R-(DxxT)E3S Display method LCD (field LCD) ■...

  • Page 5: 4．Technical Parameters

    ■ ■ Four-quadrant power measurement Maximum demand ■ ■ Complex rate power ■ ■ metering Event logging □ Data logging Alarm □ Built-in clock ■ ■ RS485 interface ■ ■ Communication Ethernet interface □ RJ45 interface □ A1+（B1 or C1） Optional function Relay output (2DO) (4DI+2DO or...

  • Page 6: 5．Installation

    Power consumption: less then 0.2VA Output mode:Open collector optocoupler pulse, 2-way output Electricity Three-phase Pulse constant:100imp/kWh Output Communication RS485 interface, Modbus-RTU、Ethernet Display Input 4 dry contact inputs On Off Function Output mode: 2-way relay normally open contact output Volume Output Contact capacity：AC 250V/3A、DC 30V/3A Measurement precision 0.5 level, Reactive energy: 2 level、Other: 1 level...

  • Page 7: Open Current Transformer's Dimension (Unit: Mm)

    Open Current Transformer’s Dimension (Unit: mm) Φ10mm Φ16mm Φ24mm 5.3 Installation Method Instrument mounting method: DIN 35mm standard rail mounting Open-close transformer installation method 5.4 Connection Mode (Note: The connection diagram on the instrument housing shall prevail in case of any discrepancies with it) According to different design requirements, it is recommended to add fuses to the power and voltage input terminals to meet the safety requirements of the relevant electrical codes...

  • Page 8: 6．Programming And Use

    When three-phase three-wire wiring, terminal 2 and terminal 4 should be connected together externally The instrument must be installed on site one by one with the matching open and closed transformer, otherwise it will affect the measurement accuracy, and at the same time must ensure a reliable connection between the two. 6．Programming and Use 6.1 Button Function Description The five buttons of the instrument are FN button, SET button, Enter button from left to right.

  • Page 9: Instrument Interface Display

    In measurement mode, press the key to page up the display item to view the relevant parameters, as described in the display menu. ▲button In programming mode, it is used to switch the menu of the same level or the decrease of the digit.
  • Page 10 Maximum demand Average value MAX DEMAND AVERAGE 000.9 000.0 V 10-12 09:58 000.0 V 000.0 A Time 2022-05-18 14 : 50:14 Note: No phase voltage and split-phase power interface when three-phase three-wire 6.2.2 Single-phase interface Voltage and current Power 000.0 000.0 000.0 000.0 kvar...
  • Page 11 Last month's compound rate active energy Previous month compound rate active energy Total complex rate active energy Last month Month before last Total Eletric energy 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 000000.00 1 、...
  • Page 12 after the event record is selected. As shown above, the 1st record indicates the 1st switch input at 8:31:26 on 5/3/16; the 5th record indicates the 1st switch input at 12:31:26 on 5/3/16. Press the up and down keys to view other records, and a total of 16 records are saved.
  • Page 13 In.PU is set to 10kV, PI is set to 600 6.2.6.2 Communication settings Config A OUT ADDR MODE NONE Comm Timer BAUD 38400 645: 000000000000 Tarrif Others MODE NONE 192168000101 D OUT Version 645:0000000000000 255255255000 Version 192168000101 255255255000 192168000001 Port： 05001 255255255000 Version...

  • Page 14: Switching Settings

    16：00 16：00～22：00 In the time period, the rates are flat 22：00 22：00～00：00 In the time period, the rate is pointed 6.2.6.4 Switching settings Config A OUT BAND Comm Timer 0000 0010 Tarrif Others AL.HI AL.L0 In=0 +9000 +0000 D OUT Version After entering the user setting interface, press the up and down key to select the switch (DO1~DO4) setting, and press the enter key to enter the switch setting interface.

  • Page 15: Time Settings

    If it is DO output mode, when set to 0, it is level control mode, and when it is not 0, it is pulse control mode, and it will be disconnected after the time delay set, unit: 1 second. BAND No action band interval AL.Hi High alarm value Range -9999 to 9999 (ignore decimal point position)

  • Page 16: 7．Communication Wiring

    select the item you want to set, and press the left and right keys to modify the value of the setting item. Note: Illegal time cannot be saved (e.g. 25:05 on May 18, 2022 cannot be entered if it is illegal) 6.2.6.7 Other settings Config A OUT...

  • Page 17: Transmission Method

    7.1 Transmission method The information is transmitted asynchronously and in bytes. The communication information passed between the host and the slave is in 10-bit word format, containing 1 start bit, 8 data bits (the least significant bit is sent first), no parity bit, and 1 stop bit, or 11-bit word format if set to and parity bit or 2 stop bits.

  • Page 18: Function Code Introduction

    e. Repeat the third and fourth steps until 8 shifts. This finishes processing a complete eight bits. f. Repeat step 2 to step 5 to process the next octet until all bytes are processed. g. The final CRC register value is the CRC value. There is also a method to calculate CRC using a pre-defined table, its main feature is fast calculation, but the table requires more storage space, the method is not repeated here, please refer to the relevant information 7.3 Function Code Introduction...
  • Page 19 0--4800bps 3--38400bps(default communication rate) Communication rate 1--9600bps 4--2400bps 2--19200bps 5--1200bps Communication parity 0--No parity bit (default mode) 2--Even parity bit mode 1--Odd parity bit 3--2 bits Wiring method 0--3-phase 3-wire 1--3-phase 4-wire Secondary side rated 0--100V 2--660V voltage value Ue 1--400V Secondary side rated 0--1A...
  • Page 20 and secondary side coefficients 21-23 Compound Rate Period 1 24-26 Compound Rate Period 2 The complex rate information is divided into 8 time 27-29 Compound Rate Period 3 periods and four rates; each time period occupies three 30-32 Compound Rate Period 4 words: the first word is the hour, the second word is 33-35 Compound Rate Period 5...
  • Page 21 minutes seconds 143-148 Event Log 1 Reserved 149-154 Event record 2 Reserved 155-160 Event record 3 Reserved 161-166 Event log 4 Reserved 167-172 Event record 5 Reserved 173-178 Event Log 6 Reserved 179-184 Event log 7 Reserved 185-190 Event log 8 Reserved 191-196 Event log 9...
  • Page 22 263-264 Phase B reactive power Qb Secondary side power, 2 decimal places, in var 265-266 Phase C reactive power Qc Secondary side power, 2 decimal places, in var 267-268 Total reactive power Q total Secondary side power, 2 decimal places, in var 269-270 Phase A apparent power Sa Secondary side power, 2 decimal places, in VA...
  • Page 23 energy Previous month's peak 349-350 Secondary electricity, 2 decimal places, in kWh active energy Previous month's active flat 351-352 Secondary electricity, 2 decimal places, in kWh power last month's active valley 353-354 Secondary side power, 2 decimal places, in kWh energy Total active energy in the 355-356...
  • Page 24 0-32, see the correspondence in the table of 6.2.6.4 for 1001 1st alarm selection details If the total active power alarm, this value is 16. 0-9999 Unit: s; If the total active power is alarmed, 1002 1st alarm delay time this value is 16.
  • Page 25 transmission 1100-1102 DLT/645 address 0--4800bps； 4--2400bps Communication rate of the 1--9600bps; 5--1200bps 1103 second communication 2--19200bps； 3--38400bps(Default communication rate) 0--No parity bit(Default method); 1 - Odd check digit; 1104 Second communication 2 - even parity bit. check mode 3--2 bits 1 time zone is divided into 8 time periods;...
  • Page 26 History of total active Same as above 1258-1259 energy in January History of active energy in Same as above 1260-1269 February History of active energy in Same as above 1270-1279 March History of active energy in Same as above 1280-1289 April History of active energy in Same as above...
  • Page 27 For example, bit16: January time zone selection (0: select time zone 1, 1: select time zone 2). bit15：February time zone selection bit14: March time zone selection Bit5：December time zone selection 3000 High Decimal Point U (DPT) Byte 3000 Low Decimal Point I (DCT) Byte 3001 High 4-10...
  • Page 28 3024 Occurrence time: day, hour High 8 bits: day; Low 8 bits: hour 3025 Occurrence time: minutes, seconds High 8 bits: minutes; Low 8 bits: seconds 3026 Line voltage Ubc max. Primary side 3027 Occurrence time: year, month High 8 bits: year; Low 8 bits: month 3028 Occurrence time: day, hour High 8 bits: day;...
  • Page 29 maximum 3055 Occurrence time: year, month High 8 bits: Year; Low 8 bits: Month 3056 Occurrence time: day, hour High 8 bits: day; Low 8 bits: hour Occurrence moment: minutes, High 8 bits: minutes; Low 8 bits: seconds 3057 seconds Total active power P total 3058 Primary side...
  • Page 30 3080 Time of occurrence: day, hour High 8 bits: day; Low 8 bits: hour 3081 Occurrence time: minutes, seconds High 8 bits: minutes; Low 8 bits: seconds B-phase apparent power Sb 3082 Primary side maximum 3083 Time of occurrence: year, month High 8 bits: year;...
  • Page 31 Occurrence moment: minutes, High 8 bits: minutes; Low 8 bits: seconds 3109 seconds 3110 Neutral line current max. Secondary side Current fractional digits: 3 3111 Time of occurrence: year, month High 8 bits: year; Low 8 bits: month 3112 Occurrence time: day, hour High 8 bits: day;...

  • Page 32: Correspondence Between Communication Value And Actual Value

    8230 float Phase B apparent power Sb Primary power，in 8232 float Phase C apparent power Sc Primary power，in 8234 float Total apparent power S total Primary power，in 8236 float A-phase power factor 8238 float B-phase power factor 8240 float C-phase power factor 8242 float Total power factor...
  • Page 33 Ratio = 3800 * 0.25 = 950V. 7.5.2 Active power, reactive power, apparent power and electrical energy The measured values of this series are read out with command 0x03 of the Modbus-RTU communication protocol, and each item occupies two words. the correspondence between the communication value and the actual primary side value is as follows: Val_s = Val_t / 100;...

  • Page 34: Event Log

    in the Integer reading mode, that is, the communication reads the value Val_t as 1414, then Val_s = Val_t / 1000 = 1414/1000 = 1.414 7.5.4 Date and time This series of measured values includes year, month, day, hour, minute and second, read out by command 03 of Modbus-RTU communication protocol, each item occupies 1 word, in BCD code format.

  • Page 35: Dl/T645-1997 Protocol Overview

    product. This chapter includes a brief description of the DL/T645-1997 protocol, a detailed explanation of the communication application format, details of the application of the machine and the parametric address table. Protocol Overview 8.1 DL/T645-1997 The instrument uses a communication protocol that complies with the DL/T645-1997 specification, which defines in detail the checksum, data, sequence, etc., that are necessary for a particular data exchange.The DL/T645-1997 protocol uses a master-slave answering connection (half-duplex) on one communication line, which means that signals are transmitted on a single communication line along two opposite directions.
  • Page 36 Host sends: FE FE 68 01 00 00 00 00 68 01 02 43 C3 DA 16 ACR10R response (0.40kWh): 68 01 00 00 00 00 00 68 81 06 43 C3 73 33 33 33 6A 16 c) Transmission response...
  • Page 37 Pause time between bytes: ≤ 6 bytes of sending time, when this time is exceeded, the ACR10R considers it a new data frame. d) Error control The byte checksum is even, and the frame checksum is longitudinal information checksum. If the receiver detects an error in even or longitudinal information checksum, the frame is dropped and no response is given.
  • Page 38 power Phase B active XX．XXXX 68 99 99 99 99 99 99 68 01 02 65 E9 B7 16 power C-phase active XX．XXXX 68 99 99 99 99 99 99 68 01 02 66 E9 B8 16 power Phase A reactive XX．XX kvar 68 99 99 99 99 99 99 68 01 02 73 E9 C5 16...
  • Page 39 Attachment 1： Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0...
  • Page 40 Headquarters: Acrel Co., LTD. Address: No.253 Yulv Road Jiading District, Shanghai，China TEL.: 0086-13774416773 WhatsApp: 0086-13774416773 Web-site: acrel.se mail: Daisylin@acrel-electric.com Postcode: 201801 Manufacturer: Jiangsu Acrel Electrical Manufacturing Co., LTD. Address: No.5 Dongmeng Road,Dongmeng industrial Park, Nanzha Street,Jiangyin City,Jiangsu Province,China Postcode: 214405...
