DMP XD Quick Start Manual

XD DOOR MODULE
Quick Start Guide
MOUNT THE MODULE
The metal enclosure for the XD Door Module needs to be mounted to a wall,
backboard, or other flat surface. Compatible enclosures include Model X1-3-ENC
and Model X1-OUT-EXP.
To install the XD Door Module, use screws to mount the PCB inside the metal
enclosure following the 3 hole pattern.
ADDRESS THE MODULE
The XD Door Module has a 1 through 9 addressable rotary dial that is factory
defaulted to 0. XD modules can only be addressed from 2-8. Additional modules
need to be addressed in sequence.
CONNECT A CARD READER
The XD Door Module provides direct 12 VDC output to the reader on the RED
terminal connection.
Terminal Name
R1 & R2
W1 & W2
G1 & G2
B1 & B2
LC
BC
WIRE THE INPUTS
Door Switch (DS) - Normally Closed
Connect a door contact or door position switch to
indicate status of door, whether it is open or closed.
Request to Exit (RX) - Normally Open
Connect a motion sensing device or a mechanical
switch to provide RX capability to the system.
Custom Input (CI) - Normally Open
This input triggers a custom action.
Ground (G)
This terminal is the ground for the inputs.
LT-2832 24061 © 2024 Digital Monitoring Products, Inc.
Wiegand Function
12V+
Data 1
Data 0
12V- (ground)
LED Control
Wiegand Buzzer Control
OSDP Function
DC +
B (485 +)
A (485 -)
DC -
N/A
N/A
DS RX CI
R1 W1 G1
B1 LC BC R2 W2 G2 B2 LC
G
BC DS RX CI G NC C NO
