BELMONT FLOOR
ASSEMBLY
TOP DIFFUSER
SHADE ASSEMBLY
SOCKET ASSEMBLY
BOTTOM DIFFUSER
LEGS
1. ASSEMBLE LEGS (3 LOWER SECTIONS AND 3 UPPER SECTIONS).
2. ATTACH LEGS TO SOCKET ASSEMBLY (NOTE! REAR LEG INDICATED BY CABLE CLIP).
3. INSERT LOWER DIFFUSER VERTICALLY, ONCE INSIDE, ROTATE UNTIL FROSTED SIDE IS FACING DOWN AND
DROP INTO PLACE MAKING SURE IT NESTS PROPERLY.
4. REMOVE 4X SCREWS IN TOP OF SOCKET ASSEMBLY. SLIP SHADE OVER SOCKET ASSEMBLY AND ATTACH
WITH PROVIDED SCREWS (NOTE! LOGO TAG FACES REAR OF LAMP).
5. INSTALL BULBS (PROVIDED)
6. LOAD UPPER DIFFUSER WITH FROSTED SIDE UP AND SECURE CABLE INTO CABLE CLIP TO COMPLETE.
pg. 1
BELMONT FLOOR
ASSEMBLY
1.
3.
5.
2.
4.
6.
pg. 2
Advertisement
Related Manuals for Pablo BELMONT
Summary of Contents for Pablo BELMONT
- Page 1 BELMONT FLOOR BELMONT FLOOR ASSEMBLY ASSEMBLY TOP DIFFUSER SHADE ASSEMBLY SOCKET ASSEMBLY BOTTOM DIFFUSER LEGS 1. ASSEMBLE LEGS (3 LOWER SECTIONS AND 3 UPPER SECTIONS). 2. ATTACH LEGS TO SOCKET ASSEMBLY (NOTE! REAR LEG INDICATED BY CABLE CLIP). 3. INSERT LOWER DIFFUSER VERTICALLY, ONCE INSIDE, ROTATE UNTIL FROSTED SIDE IS FACING DOWN AND DROP INTO PLACE MAKING SURE IT NESTS PROPERLY.
- Page 2 BULB TYPES 2X A19 9.5W (120V) LED 2X BT-15 72W (120V) HALOGEN OR LED BELMONT LENGTH OF CORD SUPPLIED 8FT (244CM) FLOOR CARE INSTRUCTIONS TO REMOVE DUST AND SMALL DEBRIS: CLEAN WITH A SOFT HAIR BRUSH OR USE A VACUUM.
