- Page 1 SUPERLIGHT ASSEMBLY & INSTALLATION INSTRUCTIONS MONTAGE- & INSTALLATIONSANLEITUNG INSTRUCTIONS D’ASSEMBLAGE ET D’INSTALLATION INSTRUCCIONES DE MONTAJE E INSTALACIÓN ISTRUZIONI PER L’ASSEMBLAGGIO E L’INSTALLAZIONE pg. 1...
- Page 2 SUPERLIGHT SUPERLIGHT TABLE ASSEMBLY PLACE THE BASE ON THE TABLE SO THE HOLE IS LOCATED OFF OF THE EDGE. SCREW BASE WEIGHT TO POST USIN GPROVIDED 4MM HEX KEY. USE PROVIDED FLAT WRENCH TO HOLD STEM PIN PLACE TO TIGHTEN.
- Page 3 SUPERLIGHT SUPERLIGHT FLOOR BASE ASSEMBLY UNPACK BOTH EXTENSION POLES. REMOVE TAPE HOLDING CORD CLIP TO LOWER POLE. SCREW LOWER AND UPPER LAMP POLE TOGETHER. ENSURE CORD CLIP IS CONNECTED TO LOWER POLE. CORD CLIP IS ON LOWER POLE SCREW ASSEMBLED LAMP POLE INTO FLOOR BASE AS SEEN IN TABLE ASSEMBLY.
- Page 4 SUPERLIGHT SUPERLIGHT WALL MOUNT ASSEMBLY INSTRUCTIONS PARTS LIST: III. USE THE WALL MOUNT BODY AS A TEPLATE FOR MARKING THE WALL ANCHOR LOCATION. I. SCREWS PLACE THE WALL MOUNT BODY IN THE DESIRED LOCATION MAKE SURE IT IS ALIGNED VERTICALLY.
- Page 5 SUPERLIGHT SUPERLIGHT SURFACE MOUNT ASSEMBLY INSTRUCTIONS SURFACE MOUNT / CLAMP MOUNT DRILL 7/8” (2.2 CM) DIAMITER HOLE INTO TABLE SURFACE. MAXIMUM TABLE THICKNESS IS 1.375” (3.5 CM). FEED CORD THROUGH GROMMMET HOLE. SCREW LAMP TO GROMMET. THREAD WASHER AND NUT ONTO GROMMET AS SHOWN AND TIGHTEN TO SECURE.
- Page 6 STECKER EINSTECKEN UND DREHEN. AUSTRALIA KNOPF DRÜCKEN, UM STECKER HERAUSZUZIEHEN. LAMPENKABEL AN DAS NETZTEIL ANSCHLIESSEN. ES DARF NUR DAS MITGELIEFERTE PABLO-NETZTEIL VERWENDET WERDEN. LÄNGE DES MITGELIEFERTEN KABELS 274 CM. PFLEGE MIT EINEM WEICHEN FEUCHTEN TUCH ABWISCHEN. KEINEN AMMONIAKHALTIGEN REINIGER VERWENDEN.
- Page 7 SUPERLIGHT SUPERLIGHT SWTICH FUNCTION PRESS SWITCH BRIEFLY TO CYCLE THROUGH HIGH AND OFF. PRESS AND HOLD SWITCH FOR FULL RANGE DIM CONTROL. 6 HOUR AUTO OFF SETTING WHILE LIGHT IS TURNED OFF, PRESS AND HOLD SWITCH FOR 6 SECONDS UNTIL THE LIGHT FLASHES ONCE. THEN PRESS THE SWITCH AGAIN TO TURN ON.
- Page 8 SUPERLIGHT ADJUSTMENT EINSTELLUNG AJUSTEMENT AJUSTE REGOLAZIONE pg. 14 pg. 15...
- Page 9 INFO@PABLODESIGNS.COM INFO@PABLODESIGNS.EU 888 MARIN STREET SAN FRANCISCO, CA 94124 PABLODESIGNS.COM PABLODESIGNS.EU pg. 16...
